7803 Stand Assembly Instructions
1.
Surface Preperation
Gently place the unit's head face down on the
ground. Use a towel or other soft material to avoid
scratching or damaging the unit. Make sure the
surface area is flat.
2.
Installing Tube
Insert power cord into the top of
Tube and pull through the bottom.
Align the Lock Release Button
with the hole located on the Pole
(A). Push the Pole onto the head
until the Lock Release Button
snaps into place.
Top
Bottom
Lock Release
Button
