KAM KCM350 Instruction Manual

REAR PANEL CONNECTIONS

20. AC CONNECTION
21. RCA MASTER OUTPUTS - Left & Right line level Unbalanced RCA
22. RCA BOOTH OUTPUTS - Left & Right line level Unbalanced RCA
23. REC OUT - Left & Right line level Unbalanced RCA connectors. The Record Out (REC
OUT) level is dictated by the CHANNEL FADER LEVEL (8), it is not influenced by the
MASTER VOLUME CONTROL (16).
24. DEDICATED LINE INPUTS - Channels 1, 2, 3 & 4 each feature a dedicated, stereo,
unbalanced RCA audio input suitable for use only with devices like CD, Video & Tape
players which produce a 'line level' signal.
25. SWITCHABLE PHONO/LINE INPUTS -
input which can be switched between 'line level' and 'phono level' operation via the INPUT
SELECTION SWITCHES (26). PHONO inputs are designed for use only with turntables
which produce a low voltage 'phono' level signal.
26. INPUT SELECTION SWITCHES - used to set signal input type for channels 2,3 & 4.
27. GROUND TERMINALS - Connect each of your turntable ground leads to either
of the three ground terminals.

SPECIFICATIONS

INPUT Mic 2mV / 3k Ohm : Phono 3mV / 47 Kohm :
OUTPUT Amp 1V /1k Ohm : Rec 400mV / 1k Ohm
Headphone >8 Ohm stereo
FREQUENCY RANGE 25Hz~20KHz
Channel EQ -26dB /+12dB
THD 0.05% -:- S/N RATIO 78dB
POWER SUPPLY Internal
DIMENSIONS 373 x 295 x 90mm -:- WEIGHT
Due to continuous product development, specifications are subject to change.
when this product is no longer functional take it to a recycling plant for envirnmentally friendly disposal
Channels 2, 3 & 4 each feature a stereo RCA
Line 200mV / 47 Kohm
5 Kgs
K C M 3 5 0
Instruction Manual
