KAP2020 USB
Rack mountable 4 channel mixer with USB playback
M A N U A L
V E R S I O N
1 . 0
0 3 / 0 8 / 1 2
Due to continuous product development, please ensure that you have downloaded
the latest instruction manual for this product from the Kam website at www.kam.co.uk
For the latest updates and information on the entire Kam range visit:
www.kam.co.uk
Kam products are manufactured by: Lamba plc, Unit 1, Southfields Road, Dunstable, Bedfordshire, United Kingdom LU6 3EJ
Telephone: (+44) (0)1582 690600 • Fax: (+44) (0)1582 690400 • Email: mail@lambaplc.com • Web: www.lambaplc.com
Due to continuous product development, specifications and appearance are subject to change. © Copyright Lamba plc 2012. E&OE.
M
A
D
E
I
N
C
H
I
N
A
Advertisement
Table of Contents
Related Manuals for KAM KAP2020 USB
Summary of Contents for KAM KAP2020 USB
- Page 1 For the latest updates and information on the entire Kam range visit: www.kam.co.uk Kam products are manufactured by: Lamba plc, Unit 1, Southfields Road, Dunstable, Bedfordshire, United Kingdom LU6 3EJ Telephone: (+44) (0)1582 690600 • Fax: (+44) (0)1582 690400 • Email: mail@lambaplc.com • Web: www.lambaplc.com...
- Page 2 Thank you for purchasing this Kam product, we are sure that it will serve you for many years to come. To optimise the performance of this product, please read these operating instructions carefully to familiarise yourself with the basic operations of this unit. Please retain them for future reference.This unit has been tested at the factory before being shipped to you.
- Page 3 Unpacking Warning: After unpacking, and before plugging the AC cord in the wall outlet, check whether the AC mains voltage and frequency is the same as this product (AC220-250V~ 50Hz). If the specified voltage or your AC plug should not match the local conditions, do NOT plug the AC cord into the wall outlet and contact you dealer immediately. Back Panel Mains input and fuse holder.
- Page 4 16. Talkover threshold control. The setting of this control determines at which microphone level the automatic talkover starts to reduce the master output level. In addition, the amount of reduction can be determined with the top panel TALKOVER control (34). 17.
- Page 5 31. Crossfader Curve switch. Allows the transition characteristic of the crossfader between the X and Y signal to be switches between smooth a flat and steep mixing curve. 32. Output level control. Determines the main output level present at outputs (3) and (4). 33.
- Page 6 Powering up Following a proper power-up sequence protects your equipment – specifically speakers – and your ears. Follow the below procedure: • Turn down all output volume controls of any equipment in your audio system. • Switch on your audio sources first (Turntables, CD Players, PC’s with soundcards, Tape decks, etc.) •...
- Page 7 Technical Data Mains Input EU version…...……………………………..……………AC220-250V~ 50Hz Power consumption…………………………………………………………….……max. 18W Fuse …………………………………………………..250v ac 500ma 20mm slow blow fuse Frequency response…………………………….……………………..20Hz-20kHz ±1.0 dBu S/N………………………………………………………………...……………………….>77dB THD+N………………………………………………………… ……………..< 0.07% @ 1kHz Dimensions…...…………………..….. W 254× H178x D 104mm (85mm mounting depth) Weight ……………………………………………………………………………………..3.2 kg Standards This product complies with the following standards: EU safety...................EN 60065:2001 +A1...
