- Page 1 User’s Manual HD Digital Cable Receiver DVBC-123CI User’s Manual Keep this manual for future reference www.facebook.com/denverelectronics...
-
Page 2: General Safety
User’s Manual General Safety This STB has been manufactured to meet international safety standards. Please read the following safety precautions carefully before you operate the STB. MAIN SUPPLY Use only 100-240V AC 50/60Hz. CABLE Use standard certified cables to prevent any malfunction of the STB. - Page 3 2. Refer all repairing to qualified service representatives. Packing Accessory List Please check that whether all of following items are included in the package ◆ DVBC-123CI ◆ Remote Control Unit ◆ Two AAA Size Batteries(for remote control) ◆ Facebook Leaflet...
-
Page 4: Table Of Contents
User’s Manual Contents Front Panel ------------------------------------------------------------------------------- Rear Panel --------------------------------------------------------------------------------- Remote Control Unit ------------------------------------------------------------------ STB Connection -------------------------------------------------------------------------- Installation------ -------------------------------------------------------------------------- Basic Operation -------------------------------------------------------------------------- Menu Guide ------------------------------------------------------------------------------ (1).Program Manage Settings ------------------------------------------------------------ ----------------------------------------------------------------------------- (2). Picture Setting (3). Channel Search ----------------------------------------------------------------------------13 (4).Time ----------------------------------------------------------------------------------15 setting --------------------------------------------------------------------------------------16 (5). -
Page 5: Front Panel
User’s Manual Front Panel 1. MENU To display the main menu on the screen. 2. CH + / CH- To change channels up / down. To move up or down highlight bar cursor for selecting options on the menu. 3. VOL + / VOL- To increase or decrease the volume levels. -
Page 6: Rear Panel
User’s Manual Rear Panel 1.RF IN Connect with the cable. 2.LOOP OUT It is for connection of another STB to your STB. 3.COAXIAL SPDIF output port (Coaxial type). 4. TV SCART Connect this port to that of TV via SCART cable. 5.USB For software upgrade and media play function. -
Page 7: Remote Control Unit
User’s Manual Remote Control Unit POWER Turns your STB on/off(standby). Shows favorite channels list. MUTE Turns on/off the sound temporarily. NUMERIC BUTTONS Selects a channel or inputs numerical value into an input box of a menu item. - Page 8 User’s Manual TV/RADIO Switchs between TV program and RADIO only receiving mode. RECALL Plays previous service. MENU Displays the main menu on the screen. Displays the EPG. (Electronic Program Guide). INFO Displays additional channel information. EXIT Exits the current Menu or returns to the previous Menu. ↑/↓...
- Page 9 User’s Manual Yellow button In DTV mode, press to change to different Aspect Ratios. In Teletext mode, it is the teletext colour button. Blue button In Teletext mode, it is the teletext colour button. APPL Displays the Multimedia menu. GOTO Sets the play time during media play.
-
Page 10: Stb Connection
User’s Manual STB Connection How to connect your STB to various systems There are several ways of connecting the STB to your TV, VCR and/or Hi-Fi SYSTEM. Consult your local supplier for assistance in setting-up your system best suited to your requirements. 1. -
Page 11: Basic Operation
User’s Manual Basic Operation Information Press the INFO button to show the information of the channel which you are watching now. Press the INFO button twice continuously to show more information of the channel which you are watching now. Change Channels To change channel, you have the following options: ... - Page 12 User’s Manual Audio While live playing or recorded playing, press the AUDIO button to show the Audio Language menu. Then press the ↑/↓buttons to select which language audio you want to play if have any. Press the ←/→button to switch audio trace of current audio language.
- Page 13 User’s Manual Teletext While live playing or recorded playing, press the TXT button to play the current Teletext if have any. Record While live playing, press the REC button will start to record the current program. While recording, pressing the INFO button will show the record information.
-
Page 14: Menu Guide
User’s Manual Menu Guide (1). Program Manage Settings To access the Menu, press the MENU button and select [Program], using the RIGHT/LEFT button to navigate through the menu. The Menu provides options to adjust the Program Manage Settings. Select an option and press OK or RIGHT to adjust that setting. - Page 15 User’s Manual Set Favourite Channels You can create a shortlist of favourite programs that you can easily access. Set Favourite TV or Radio program: 1. Select your desired channel then press the FAV button. A heart-shaped symbol will appear and the channel is marked as a favourite. 2.
-
Page 16: Picture Setting
User’s Manual 4. Press the YELLOW button to disable the locked channels function 5. To view the locked channels, you will be required to enter either the default password '000000' or your last set password. The master unlock password is '888888'. (b) EPG (Electronic program guide) The EPG is an on-screen TV guide that shows scheduled programs seven days in advance for every tuned channel. -
Page 17: Channel Search
User’s Manual (a) Aspect Ratio You can change the aspect ratio of the output picture in here. (b) Resolution You can change this setting if the picture resolution does not appear to be correct. This setting is to match the most common setting for HDMI. [576i]: for PAL TV system . - Page 18 User’s Manual (a)Network Search Select [Network Search] then press OK or RIGHT. The channel search screen will appear. 1. Press the RIGHT/LEFT button to select the provider in [Provider] option. 2. If [Provider] is [Other], need to set the parameters of the homing channel. ...
-
Page 19: Time Setting
User’s Manual (c)Manual Search 1. Select [Manual Search] then press OK or RIGHT. The channel search screen will appear. 2. Input the frequency into [Frequency (MHz)] box using the numeric buttons. 3. Input the symbol rate into [Symbol] box using the numeric buttons 4. -
Page 20: Option
User’s Manual (a) Time offset Set the time offset mode. [Auto] The STB get the time offset from the transport stream. [Manual] The time offset depends on the [Time Zone] option. (b) Time Zone Select the Time Zone Offset when [Time Offset] is set to Manual. (b) Sleep Set how long the STB doesn’t have any menu operation, the STB will go to standby automatically. -
Page 21: System Setting
User’s Manual If the language is not available, the default program language will be used. (d) Digital Audio Select digital audio output mode. (6). System Setting To access the Menu, press MENU select [System] using the RIGHT/LEFT buttons. The menu provides options to adjust the system settings. Press the UP/DOWN button to select an option and press RIGHT/LEFT button to adjust the setting. -
Page 22: Disc
User’s Manual To access the Menu, press the MENU button and select [Disc] using the RIGHT/LEFT buttons. The menu provides options to playback Music, Photo, video and record files. It can support AVI, MP3, WMA, JPEG and BMP formats. (a) Disc: When a USB device is attached you can select from the Music, Photo, Movie and PVR options in this menu using the RIGHT/LEFT keys and OK to select. -
Page 23: Disc
User’s Manual (d)PVR Configure -Record Device: To select which disk the program is recorded into. -Format: To format a disk. Note: All the data in the disk is removed after doing the format operation. Disc To access the Multimedia menu, you have two ways. (a)Press the MENU button and select [Disc] using the RIGHT/LEFT buttons. -
Page 24: Photo Player
User’s Manual (2) Photo Player (a)Press the RIGHT/LEFT buttons to select a JEPG/BMP file. Press OK button to play the file or enter the folder. Press RECALL button to upon the parental folder. (b)Press PLAY button to slide show. (c)Press the GOTO button to grid show. (3) Movie Player (a)Press the RIGHT/LEFT buttons to select an AVI/TS file. -
Page 25: Specification
User’s Manual (b) Press red button to switch preview playing and full screen playing. (c) Press yellow button to delete one or several recording files. (d) Press green button to rename a recording file. Note: -We cannot guarantee compatibility (operation and/or bus power) with all USB mass storage devices and assume no responsibility for any loss of data that may occur when connected to this unit. - Page 26 User’s Manual Tuner & Channel Input Connector F-Type , IEC 169-24, Female Frequency Range 48MHz—862MHz Input impedance 75 unbalanced Signal Level -76 to -35dBm Demodulation QAM16、QAM32、QAM64、QAM128、QAM256 A/V & Data In/Out TV_SCART Video Output (CVBS, RGB) Audio Output S/PDIF Coaxial type HDMI 1080I，720P，576P，576I Physical Specification...
- Page 27 User’s Manual ALL RIGHTS RESERVED, COPYRIGHT DENVER ELECTRONICS A/S Electric and electronic equipment and included batteries contains materials, components and substances that can be hazardous to your health and the environment, if the waste material (discarded electric and electronic equipment and batteries) is not handled correctly.
