- Page 1 Rosmore Slide Control INCLUDES USER, INSTALLATION & MAINTENANCE INSTRUCTIONS Please read these instructions carefully before you start using the appliance Keep this booklet handy for future reference This appliance is for use in GREAT BRITAIN or IRELAND only...
-
Page 2: Table Of Contents
UC Living Rosmore SLIDE CONTROL Instructions CONTENTS PAGE User Instructions SECTION ONE Introduction Consumer Protection Health and Safety Introduction SECTION TWO Operation SECTION THREE Fuel Bed Cleaning and Layout Coal Layout Pebble Layout SECTION FOUR Important information INSTALLATION INSTRUCTIONS SECTION FIVE Specification... -
Page 3: Section One Introduction
‘hazardous waste and should be disposed of at a site licensed for the disposal of industrial waste. INTRODUCTION The UC Living Rosmore SLIDE CONTROL is a decorative fuel effect appliance with a radiant heat conserver box for improved efficiency. The UC Living Rosmore SLIDE CONTROL is designed and tested to the requirements of EN The UC Living Rosmore SLIDE CONTROL should be installed and serviced by a competent person i.e. -
Page 4: Section Two Operation
The UC Living Rosmore SLIDE CONTROL incorporates a single gas control, which selects ignition pilot, and main burner low and high settings. The UC Living Rosmore SLIDE CONTROL incorporates a safety device in the form of an Oxygen Depletion System, which constantly monitors the oxygen in the room and will cause the fire to switch off if the oxygen level reduces, for instance due to insufficient ventilation or a blocked flue. -
Page 5: Section Three Fuel Bed Cleaning And Layout
UC Living Rosmore SLIDE CONTROL Users Instructions SECTION THREE Fuel Bed Cleaning and Layout Important: - Refer to the ‘Health & Safety Notice located on page 3 of this booklet before cleaning or replacing any refractory material. The fuel bed components are delicate and they should be handled with great care. - Page 6 UC Living Rosmore SLIDE CONTROL Users Instructions SECTION THREE Fuel Bed Cleaning and Layout Cont. Place the first row of 3 x A and 3 x B overlay loose coals as shown between the front coals and base matrix. Make...
- Page 7 UC Living Rosmore SLIDE CONTROL Users Instructions SECTION THREE Fuel Bed Cleaning and Layout Cont. Add 2 x type B coals and 1 x type A as shown. Add the final 3 x B coals as shown. The layout is now finished.
-
Page 8: Section Four Important Information
Servicing It is advised that the UC Living Rosmore fire is serviced annually this is more likely to provide trouble-free operation. A competent person must carry this out, i.e. Gas Safe Registered Installer in accordance with the current Gas Safety (Installation and Use) Regulations 1998 (as amended). -
Page 9: Installation Instructions
Failure to do so could lead to prosecution. This UC Living Rosmore SLIDE CONTROL is for use ONLY with the GAS STATED ON THE DATA BADGE this may be G20 for Natural Gas or G31 for Propane Gas. -
Page 10: Section Seven Siting The Appliance
UC Living Rosmore SLIDE CONTROL Installation Instructions SECTION SIX Regulations and Warnings Continued The following are the relevant Codes of Practice and British Standards: - BS 5871 BS 8303 1986 BS 5440 part 1 1990 BS 1251 1987 BS 6891 1988 BS 6461 parts 1 &... -
Page 11: Class Two Fabricated Metal
UC Living Rosmore SLIDE CONTROL Installation Instructions SECTION SEVEN Siting the Appliance Continued CLASS TWO FABRICATED METAL A double-walled or insulated metal flue box built to the requirements of BS 715 with an insulated flue having a minimum diameter of 125 mm (5 ins) and a minimum effective overall height of 3 metres (10 ft). - Page 12 UC Living Rosmore SLIDE CONTROL Installation Instructions SECTION EIGHT Fireplace Requirements Continued Hole in the Wall Installation Please read these instructions carefully if you intend an Installation without a hearth. This appliance must be installed in accordance with all relevant sections of approved document “J”...
-
Page 13: Clearance To Side Of Fire
UC Living Rosmore SLIDE CONTROL Installation Instructions SECTION EIGHT Fireplace Requirements Continued CLEARANCE TO SIDES OF FIRE Minimum width between vertical sides of combustible surround should not be less than 700mm provided fire is central to surround and sides do not project more than 150 mm. When vertical side forward projection is increased by 12.5 mm add 50 mm to inside width of surround. -
Page 14: Preparing The Appliance For Gas Connection
UC Living Rosmore SLIDE CONTROL Installation Instructions SECTION NINE To Install the Appliance Continued PREPARING THE APPLIANCE FOR A GAS CONNECTION If it is intended to be a concealed connection the 8mm supply should be positioned in the opening first. -
Page 15: Gas Connection From The Front
UC Living Rosmore SLIDE CONTROL Installation Instructions SECTION NINE To Install the Appliance continued GAS CONNECTION FROM THE FRONT Connections may be made from the front of the appliance from either the left, right or centre above the gas valve in 8-mm diameter pipe. If a left-hand connection is required the tube should be routed below the gas control and onto the inlet elbow. -
Page 16: Checking Gas Soundness
UC Living Rosmore SLIDE CONTROL Installation Instructions SECTION NINE To Install the Appliance Continued CHECKING GAS SOUNDNESS After completing the gas connection to the appliance, check for gas soundness in accordance with current codes of practice. CONNECTING CONTROL LEVER Flip the slide control lever... -
Page 17: Checking Operation Of Fire
UC Living Rosmore SLIDE CONTROL Installation Instructions SECTION NINE To Install the Appliance Continued CHECKING OPERATION OF FIRE Remove the screw from the pressure test point on the inlet elbow and fit pressure gauge. Turn on gas to the appliance. Purge the air from the appliance by holding the control lever down to allow the air in the pipe-work to be purged and the spark generator to ignite the pilot. -
Page 18: Maintenance Instructions
UC Living Rosmore SLIDE CONTROL Maintenance Instructions SECTION TEN Maintenance Instructions GENERAL Servicing should be carried out annually by a competent person such as a Gas Safe -registered person in accordance with the current Gas Safety (Installation and Use) Regulations 1998 (as amended), this should ensure the safe and correct operation of the appliance. -
Page 19: Replacement Of Burner And Or Silencer
UC Living Rosmore SLIDE CONTROL Maintenance Instructions SECTION TEN Maintenance Instructions continued REPLACEMENT OF BURNER AND OR THE SILENCER NOTE: The silencer must not be modified and must be correctly positioned in its bracket. The burner can be slid to the right side for a pebble fuel bed to ensure maximum aeration. - Page 20 This information may be asked for when you contact the helpdesk. Model : UC Living Rosmore Slide Control Serial No This information can be found on the label attached to the packaging and on the data badge, which is located on the appliance flange, top right behind trim.
-
Page 21: Service Log
Engineer Name Gas Safe Registration No. We may introduce modifications to products from time to time, and consequently the details given in this booklet are subject to alteration without notice. UC Living 27 Fernbank Road Bangor BT19 6GA Telephone 353 4854325 E-mail : info@ucliving.co.uk... - Page 22 LT6587 Iss 1 (10/13)
- Page 23 UC Living Fires UC Living Rosmore Slide Control THIS IS YOUR EXTENDED FIVE YEAR PARTS WARRANTY PLEASE READ IT CAREFULLY AND ENSURE YOUR INSTALLER HAS FILLED IN THE FIRST PORTION, KEEP IT IN A SAFE PLACE SO THAT IT IS AVAILABLE...
- Page 24 LT6587 Iss 1 (10/13)
- Page 25 PRODUCT DETAILS Model: Serial No. UC Living Rosmore Slide Control Date of Purchase This information can be found on the label attached to the packaging and on the data badge, which is located on the appliance flange, top right behind trim.
- Page 26 LT---- Iss- (--/--)
- Page 27 LT6587 Iss 1 (10/13)
- Page 28 LT6587 Iss 1 (10/13)
- Page 29 LT6587 Iss 1 (10/13)
- Page 30 LT6587 Iss 1 (10/13)
- Page 31 LT6587 Iss 1 (10/13)
- Page 32 UC Living Rosmore Slide Control Coal Product Serial No ID Label Prefix Fire Box Labels: Restrictor Plate Spillage (Text) Data Badge Fire Box Grommet Burner Tray / Box Assembly Slide Control Trim Covers And Instructions Warning Label (Fire Guard) Fuel Bed Comprises of:...
