Rosmore
Owner's Book
INCLUDES USER, INSTALLATION & MAINTENANCE
INSTRUCTIONS
Please read these instructions carefully before you start using the
appliance
Keep this booklet handy for future reference
This appliance is
for use in GREAT BRITAIN or IRELAND only
LT----Iss - (--/--)

Advertisement

Table of Contents
loading

Related Manuals for UC Living Rosmore

Summary of Contents for UC Living Rosmore

  • Page 1 Rosmore Owner's Book INCLUDES USER, INSTALLATION & MAINTENANCE INSTRUCTIONS Please read these instructions carefully before you start using the appliance Keep this booklet handy for future reference This appliance is for use in GREAT BRITAIN or IRELAND only LT----Iss - (--/--)

  • Page 2: Table Of Contents

    UC Living Rosmore Instructions CONTENTS CONTENTS PAGE User Instructions SECTION ONE Introduction Consumer Protection Health and Safety Introduction SECTION TWO Operation SECTION THREE Fuel Bed Cleaning and Layout Coal Layout SECTION FOUR Important information INSTALLATION INSTRUCTIONS SECTION FIVE Specification SECTION SIX Regulations and Warnings...

  • Page 3: User Instructions

    ‘hazardous waste and should be disposed of at a site licensed for the disposal of industrial waste. INTRODUCTION The UC Living Rosmore is a decorative fuel effect appliance with a radiant heat conserver box for improved efficiency. The UC Living Rosmore is designed and tested to the requirements of EN 509 The UC Living Rosmore is available in Natural Gas or LPG(Propane Gas Only).

  • Page 4: Section Two Operation

    UC Living Rosmore Users Instructions SECTION ONE Introduction Continued The UC Living Rosmore incorporates a single gas control, which selects ignition pilot, and main burner low and high settings. The UC Living Rosmore incorporates a safety device in the form of an Oxygen Depletion System, which constantly monitors the oxygen in the room and will cause the fire to switch off if the oxygen level reduces, for instance due to insufficient ventilation or a blocked flue.

  • Page 5: Section Three Fuel Bed Cleaning And Layout

    UC Living Rosmore Users Instructions SECTION THREE Fuel Bed Cleaning and Layout Important: - Refer to the ‘Health & Safety Notice located on page 3 of this booklet before cleaning or replacing any refractory material. The fuel bed components are delicate and they should be handled with great care.
  • Page 6 UC Living Rosmore Users Instructions SECTION THREE Fuel Bed Cleaning and Layout Cont.  Place the first row of 3 x A and 3 x B overlay loose coals as shown between the front coals and base matrix. Make sure that they are stable and DO NOT let them fall down in the gaps between the peaks on the matrix.
  • Page 7 UC Living Rosmore Users Instructions SECTION THREE Fuel Bed Cleaning and Layout Cont.  Add 2 x type B coals and 1 x type A as shown.  Add the final 3 x B coals as shown. The layout is now finished.

  • Page 8: Section Four Important Information

    Servicing It is advised that the UC Living Rosmore fire is serviced annually this is more likely to provide trouble-free operation. A competent person must carry this out, i.e. Gas Safe Registered Installer in accordance with the current Gas Safety (Installation and Use) Regulations 1998 (as amended).

  • Page 9: Installation Instructions

    (as amended). Failure to do so could lead to prosecution.  This UC Living Rosmore is for use ONLY with the GAS STATED ON THE DATA BADGE this may be G20 for Natural Gas or G31 for Propane Gas CHECK YOU HAVE THE CORRECT APPLIANCE FOR THE GAS YOU ARE USING.

  • Page 10: Section Seven Siting The Appliance

    UC Living Rosmore Installation Instructions SECTION SIX Regulations and Warnings Continued  During initial firing an odour may be evident. This is the binder used during the manufacture of the fibre components and there are no harmful effects produced. The following are relevant Codes of Practice and British Standards: -...

  • Page 11: Class Two Fabricated Metal

    UC Living Rosmore Installation Instructions SECTION SEVEN Siting the Appliance Continued  CLASS TWO FABRICATED METAL A double-walled or insulated metal flue box built to the requirements of BS 715 with an insulated flue having a minimum diameter of 125 mm (5 ins) and a minimum effective overall height of 3 metres (10 ft).

  • Page 12: Hole In The Wall Installations

    UC Living Rosmore Installation Instructions SECTION EIGHT Fireplace Requirements Continued Hole in the Wall Installation Please read these instructions carefully if you intend an Installation without a hearth. This appliance must be installed in accordance with all relevant sections of approved document “J”...

  • Page 13: Clearance To Shelf

    UC Living Rosmore Installation Instructions SECTION EIGHT Fireplace Requirements Continued CLEARANCE TO SHELF Minimum clearance from hearth to underside of combustible shelf should be 700mm provided shelf depth 150mm or less. This height may be reduced to 640mm for a shelf depth of 100mm or less When the shelf depth is increased by increments of 12.5 mm greater than 150mm, add 25mm...

  • Page 14: Gas Concealed Connection

    UC Living Rosmore Installation Instructions SECTION NINE To Install the Appliance GAS CONCEALED CONNECTION If the supply is to be a concealed connection it would be advisable to route 8mm O/D half hard copper tube to the rear right side of the fireplace opening, taking into account the requirements of BS 6891 1988 dealing with enclosed pipes.

  • Page 15: Checking Gas Soundness

    UC Living Rosmore Installation Instructions SECTION NINE To Install the Appliance Continued Fix the fire casing back into the opening using the cable fixing CLAMP SCREW system as shown in do not cut off loose ends of cable after fixing, coil and tuck carefully behind burner tray.

  • Page 16: Completion Of Installation

    UC Living Rosmore Installation Instructions SECTION NINE To Install the Appliance Continued If an extractor fan is situated in the room this test should be repeated with the fan running. If there is a connected room with an extractor fan, the test should be repeated with all the doors to that room opened and the extractor fan running.

  • Page 17: Fuel Bed Cleaning

    UC Living Rosmore Maintenance Instructions SECTION TEN Maintenance Instructions continued FUEL BED CLEANING Important: - Refer to the ‘Health & Safety Notice located on page 3 of this booklet before cleaning or replacing any refractory material. The fuel bed components are delicate and they should be handled with great care.

  • Page 18: Replacement Of Injector

    UC Living Rosmore Maintenance Instructions SECTION TEN Maintenance Instructions Continued REPLACEMENT OF INJECTOR Repeat operations 1-2 for removal of burner and or silencer. Disconnect gas connection to injector. Unscrew the locking nut fixing injector to mounting bracket. Clean or replace as necessary.
  • Page 19 UC Living Fires UC Living Rosmore THIS IS YOUR EXTENDED FIVE YEAR PARTS WARRANTY PLEASE READ IT CAREFULLY AND ENSURE YOUR INSTALLER HAS FILLED IN THE FIRST PORTION, KEEP IT IN A SAFE PLACE SO THAT IT IS AVAILABLE GAS SAFE WHEN YOUR ENGINEER CARRIES OUT THE ANNUAL SERVICE.
  • Page 20 For future reference we suggest you record the following details here, and keep the receipt as proof of purchase. This information may be asked for when you contact the helpdesk. Model: UC Living Rosmore Serial No. This information can be found on the label attached to the packaging and on the data badge, which is located on the appliance flange, top right behind trim.

  • Page 21: Service Log

    Service Log The following information must be complete and supported by receipts as part of the conditions of the extended three year parts warranty and the appliance must be registered by completing and returning the registration document (last page of this booklet) to Paragon Fires. Date of First annual service: Engineer Name Corgi Registration No.
  • Page 22 For future reference we suggest you record the following details here, and keep the receipt as proof of purchase. This information may be asked for when you contact the helpdesk. Model: UC Living Rosmore Serial No. This information can be found on the label attached to the packaging and on the data badge, which is located on the appliance flange, top right behind trim.
  • Page 23 TELEPHONE No. PRODUCT DETAILS Model: Serial No. UC LIVING ROSMORE Date of Purchase This information can be found on the label attached to the packaging and on the data badge, which is located on the appliance flange, top right behind trim.
  • Page 24 Blank Page LT---- Iss - (--/--)
  • Page 25 LT---- Iss - (--/--)
  • Page 26 LT---- Iss - (--/--)
  • Page 27 LT---- Iss - (--/--)
  • Page 28 UC Living Rosmore Coal Product Serial No ID Label Prefix Fire Box Labels: Restrictor Plate Spillage (Text) Data Badge Fire Box Grommet Burner Tray / Box Assembly Warning Label (Fire Guard) Fuel Bed Comprises of: Base Matrix (4720) Bag Of Coals (6543)
