Acura Embedded AcuPanel 17v2 User Manual

Rugged panel pc
Hide thumbs
1
2
3
4
5
6
7
8
9
Table of Contents

Advertisement

Quick Links

Download this manual
Enlarged version
Contents
ACURA EMBEDDED SYSTEMS INC.
Rugged Panel PC
Specifications........................................................................................ 2
AcuPanel 17v2
Knowing AcuPanel 17v2........................................................................ 3
Rear Top................................................................................................ 3
User Manual
Rear Bottom .......................................................................................... 4
Rear Panel of AcuPanel17v2........................ .................................... 5
Revision 1.1
Mechanical Dimensions......................................................................... 5
Power Input Connector.... ......................................................................6
PS/2 Keyboard/Mouse Port ...................................................................7
Panel Mounting.......................................................................................7
About BIOS Setup .................................................................................9
Default Configuration ............................................................................10
Entering Setup ......................................................................................10
Legends.................................................................................................11
BIOS Setup Utility..................................................................................12
Main.......................................................................................................12
Advanced..............................................................................................13
IDE Configuration .................................................................................13
Intel IGD Configuration..........................................................................14
Save & Exit............................................................................................15
Acura Embedded Systems Inc.
Published March 5 2015

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AcuPanel 17v2 and is the answer not in the manual?

Questions and answers

Related Manuals for Acura Embedded AcuPanel 17v2

Summary of Contents for Acura Embedded AcuPanel 17v2

  • Page 1: Table Of Contents

    Contents ACURA EMBEDDED SYSTEMS INC. Chapter 1: AcuPanel 17v2 Overview Rugged Panel PC Specifications..................2 AcuPanel 17v2 Knowing AcuPanel 17v2................ 3 Rear Top....................3 User Manual Rear Bottom ..................4 Rear Panel of AcuPanel17v2...………………… ........5 Revision 1.1 Mechanical Dimensions................. 5 Chapter 2: Power, Wiring, PS/2 Port and Panel Mounting Power Input Connector..

  • Page 2: Chapter 1: Acupanel17V2 Overview

    Touch Screen Chapter 1: AcuPanel17v2 Overview 5-wire resistive (flush panel type) Light transmission: 81% Interface: USB System CPU: On-board Intel® Atom™ Dual Core processor E3826, 1.46GHz, 1M L2 Cache BIOS: AMI BIOS Mmemory: 2x 204-pin DDR3L SO-DIMM socket, 4GB DDR3L (Default), Support up to 8GB DDR3L-1066/1333, Non- ECC and un-buffered Storage Device:...

  • Page 3: Knowing Acupanel 17V2

    Certifications CE approval FCC Class A Line-in Used to connect an audio device as sound source. Knowing AcuPanel 17v2 Mic-in Used to connect an external microphone. Rear Top Line-out Used to connect a headphone or a speaker. LAN 1 and LAN 2 Used to connect the system to a local area network.

  • Page 4: Rear Panel Of Acupanel17V2

    Rear Panel of AcuPanel17v2 Chapter 2: Power, Wiring, PS/2 Port, and Panel Mounting POWER INPUT CONNECTOR 1 Negative 2 DC+ iN 3 GND 4 x VESA Mount Hole • AcuPanel17v2''s Power Wiring Diagram VESA Mounting Holes These are mounting holes for VESA mount (100x100mm). Mechanical Dimensions Computer connecter : pin1- DC+ 12~30V...

  • Page 5: Ps/2 Keyboard/Mouse Port

    PS/2 Keyboard/Mouse Port 3. Slide the Panel PC through the hole until it is properly fitted against the panel. Connector type: PS/2, Mini-DIN-6, 2.0mm pitch 2x4 8-pin header, 2.54mm pitch 4. Position the mounting clamps along the rear edges of the Panel PC. The first and second clamps must be positioned and secured diagonally prior to mounting the rest of the clamps.

  • Page 6: Chapter 3: Bios Setup

    This chapter describes how to use the BIOS setup program for the Normally, CMOS setup is needed when the system hardware is not AcuPanel 17v2. The BIOS screens provided in this chapter are for consistent with the information contained in the CMOS RAM, reference only and may change if the BIOS is updated in the future.

  • Page 7: Legends

    Legends that field. To display the submenu, move the highlight to that field and press BIOS Setup Utility Once you enter the AMI BIOS Setup Utility, the Main Menu will appear on the screen. The main menu allows you to select from several setup functions and one exit.

  • Page 8: Advanced

    Advanced The Advanced menu allows you to configure your system for basic operation. Some entries are defaults required by the system board, while others, if enabled, will improve the performance of your system or let you set some features according to your preference. Setting incorrect field values may cause the system to malfunction.

  • Page 9: Save & Exit

    Salesperson This field is used to configure the memory size of the fixed graphics, the Acura Embedded Systems Inc. Mailing address: options are 128MB and 256MB. Unit #1, 7711-128th Street, Surrey, BC V3W 4E6, CANADA Ph: (604) 502-9666 Fax: (604) 502-9668 Save &...
