ACURA EMBEDDED SYSTEMS INC.
Rugged Panel PC
AcuPanel 15
User Manual
Revision 1.3
Acura Embedded Systems Inc.
Published January 29 2013
Content
Contents
Disclaimer ............................................................................................... iii
Regulatory Compliance Statements.........................................................iii
Declaration of Conformity....................................................................... .iii
Safety Information .................................................................................. iii
Installation Recommendations................................................................ iv
Safety Precautions...................................................................................iv
Ordering Information ...............................................................................iv
Technical Support and Assistance ..........................................................v
Conventions Used in this Manual ........................................................... v
Package Contents ...................................................................................v
AcuPanel 15 Overview.......................................................................... 1
Specifications........................................................................................ 1
Knowing Your AcuPanel 15................................................................... 3
Rear Top............................................................................................ 3
Rear Bottom ...................................................................................... 4
Rear ................................................... .................................... 5
Mechanical Dimensions......................................................................... 6
Before You Begin .................................................................................. 7
Precautions .......................................................................................... 7
Jumper Settings .................................................................................... 7
Locations of the Jumpers and Connectors ............................................8
Top View ........................................................................................... 8
Bottom View ..................................................................................... 9
Jumpers and DIP Switch Settings..........................................................10
CMOS Clear Select .......................................................................... 10
AT/ATX Selection ..............................................................................10
Dimming Type Select .........................................................................11
Dimming Signal Level Select ............................................................ 11
Panel Resolution Select .................................................................... 12
LCD Panel VDD Power Select ...........................................................13
Advertisement
Table of Contents
Related Manuals for Acura Embedded AcuPanel 15
Summary of Contents for Acura Embedded AcuPanel 15
-
Page 1: Table Of Contents
Conventions Used in this Manual ............v Package Contents ...................v Revision 1.3 Chapter 1: Product Introduction AcuPanel 15 Overview................1 Specifications..................1 Knowing Your AcuPanel 15..............3 Rear Top.................... 3 Rear Bottom ..................4 Rear …………………………………………… ........5 Mechanical Dimensions................. 6 Chapter 2: Jumpers and Connectors Before You Begin .................. - Page 2 Content Touch 4/5 Wire Select................13 Chapter 3: System Setup COM3 RI Pin Power Select ..............14 COM4 RI Pin Power Select ..............14 Installing a SATA Hard Drive ..............34 Connector Pin Definitions ................15 Installing a CFast Card ................36 External I/O Interface ................15 Installing a SODIMM ................38 12V-30V DC Power Input ..............15 Installing a SATA DOM ................40...
-
Page 3: Preface
The information in this document is subject to change without prior notice and remain CE compliant, only CE-compliant parts may be used. Maintaining does not represent commitment from Acura Embedded Systems Inc. However, CE compliance also requires proper cable and cabling techniques. -
Page 4: Installation Recommendations
7. The openings on the enclosure are for air convection to protect the equipment from overheating. DO NOT COVER THE OPENINGS. AcuPanel 15 8. Make sure the voltage of the power source is correct before connecting the - 15" SXGA LED Backlight Touch Panel PC, Intel® Atom™ D2550 equipment to the power outlet. -
Page 5: Technical Support And Assistance
Technical Support and Assistance Before continuing, verify that the package you received is complete. Your package For the most updated information of Acura Embedded Systems Inc’s products, should have all the items listed in the table. visit Acura Embedded Systems Inc.'s website at www.acuraembedded.com. -
Page 6: Chapter 1: Product Introduction
Chapter 1: Product Introduction Key Features Chapter 1: Product Introduction ▪ 4:3 15" SXGA Fanless LED Panel Computer ▪ Intel® Atom™ D2550, Dual Core, Low Consumption CPU ▪ Flush Panel by 5-wire Touch Screen ▪ AcuPanel15 Overview Dual GbE/ 2nd display-VGA/ Line-in/ Line-out/ Mic-in/ PS2 KB/MS ▪... - Page 7 Chapter 1: Product Introduction ▪ COM #3: RS232 w/ RI or 5V selection ▪ COM #4: RS232 w/ RI or 12V selection ▪ System memory: 2x 204-pin DDR3 SO-DIMM socket, 1G DDR3 (Default), support up to 4GB DDR3-800/1066, Non-ECC and un-buffered Audio ▪...
-
Page 8: Knowing Your Acupanel 15
Chapter 1: Product Introduction Knowing Your AcuPanel 15 Antenna holes for optional 3.5G/ WiFi/ Bluetooth The 3 external antenna holes are used to mount and connect optional 3.5G/ Rear Top WiFi/ Bluetooth antennas. CFast Card Socket Used to insert a CFast card. -
Page 9: Rear Bottom
Used to connect USB 2.0/1.1 devices. COM 1 and COM 2 These COM ports support RS232/422/485 compatible series device by BIOS setting. AcuPanel 15 has 2.5kV isolated protection. PS/2 KB/MS Used to connect a PS/2 keyboard and a PS/2 mouse Mic-in... -
Page 10: Rear
Chapter 1: Product Introduction Rear (AcuPanel15) The digital I/O connector support 4 isolated protection digital input channels and 4 isolated protection digital output channels. Isolation voltage: 2500 VDC VESA Mounting Hole VESA Mounting Hole 4x Digital Input (Source Type) - Input Voltage (Dry Contact) Logic 0: Close to GND Logic 1: Open - Input Voltage (Wet Contact) -
Page 11: Mechanical Dimensions
Chapter 1: Product Introduction AcuPanel15... -
Page 12: Chapter 2: Jumpers And Connectors
Chapter 2: Jumpers and Connectors Follow the guidelines below to avoid damage to your computer or yourself: Chapter 2: Jumpers and Connectors ▪ Always disconnect the unit from the power outlet whenever you are working inside the case. ▪ If possible, wear a grounded wrist strap when you are working inside the This chapter describes how to set the jumpers and connectors on the motherboard. -
Page 13: Locations Of The Jumpers And Connectors
Chapter 2: Jumpers and Connectors Locations of the Jumpers and Connectors Top View JP10 JP11 CN10 USB1 USB2 LAN1 LAN2 CN13 JP12 JP13 CN14 CN15 CN16 VGA1... -
Page 14: Bottom View
Chapter 2: Jumpers and Connectors Bottom View DDR3 SODIMM DIMM1 DIMM2 CFast card socket... -
Page 15: Jumpers And Dip Switch Settings
Chapter 2: Jumpers and Connectors Jumpers and DIP Switch Settings CMOS Clear Select AT/ATX Selection Connector type: 1x3 3-pin header, 2.54mm pitch Connector type: 1x3 3-pin header, 2.54mm pitch Connector location: JP8 Connector location: JP1 Settings Settings 1-2 On Normal 1-2 On AT Mode 2-3 On... -
Page 16: Dimming Type Select
Connector type: 1x3 3-pin header, 2.54mm pitch Connector type: 1x3 3-pin header, 2.54mm pitch Connector location: SW2 Connector location: JP6 SW2-1 SW2-2 Settings Model Settings Model AcuPanel 15 2-3 On 5.0 V AcuPanel 15 PWM Mode Analog Mode Default: PWM Definition VCC3 Power for Dimming... -
Page 17: Panel Resolution Select
Chapter 2: Jumpers and Connectors Panel Resolution Select Connector type: 4-pin On/Off Switch Connector location: SW1 SW1-1 SW1-2 SW1-3 SW1-4 Resolution/Color/Backlight On Model 800 x 600/6 bits/High AcuPanel 15 1024 x 768/8 bits/High 1280 x 1024/8 bits/High 1920 x 1080/8 bits/High... -
Page 18: Lcd Panel Vdd Power Select
Connector type: 1x3 3-pin header, 2.54mm pitch Connector location: JP5 Connector location: JP7 Model Settings Settings 1-2 On 5 wire 2-3 On 4 wire AcuPanel 15 1-2 On 3.3V 1-2 On: default 2-3 On 1-2 On: default Definition VCC3 Power for VDD VCC5... -
Page 19: Com3 Ri Pin Power Select
Chapter 2: Jumpers and Connectors COM3 RI Pin Power Select COM4 RI Pin Power Select Connector type: 1x3 3-pin header, 2.54mm pitch Connector type: 1x3 3-pin header, 2.54mm pitch Connector location: JP9 Connector location: JP10 Settings Settings 1-2 On RING 1-2 On RING 2-3 On... -
Page 20: Connector Pin Definitions
Chapter 2: Jumpers and Connectors VGA Port Connector type: DB-15 port, 15-pin D-Sub Connector Pin Definitions Connector location: VGA1 External I/O Interface 12V-30V DC Power Input Definition Connector type: DC 4-pin DIN power jack with shield Definition Connector location: CN13 Green Blue DDC Data... -
Page 21: Ps/2 Keyboard/Mouse Port
Chapter 2: Jumpers and Connectors PS/2 Keyboard/Mouse Port COM2 Port: Serial Port RS232/422/485 Connector type: PS/2, Mini-DIN-6, 2.0mm pitch 2x4 8-pin header, 2.54mm pitch AcuPanel 15 Connector location: JP4 (Isolation protection with RS232/422/485) Connector type: 9-pin D-Sub Connector location: CN16... -
Page 22: Com3 Port And Connector: Serial Port Rs232
Chapter 2: Jumpers and Connectors RS422 COM1 Port: Serial Port RS232/422/485 Definition AcuPanel 15 COM2_TXD- (Isolation protection with RS232/422/485) COM2_TXD+ COM2_RXD+ Connector type: 9-pin D-Sub COM2_RXD- Connector location: CN15 COM2_GND COM2_RTS- COM2_RTS+ COM2_CTS+ COM2_CTS- (Could be a +12V Power Pin) -
Page 23: Com4 Port And Connector: Serial Port Rs232
Chapter 2: Jumpers and Connectors RS422 COM3 Port and Connector: Serial Port RS232 Definition (Ring or +5V Power for Pin 9) COM1_TXD-: Transmit Data Negative COM1_TXD+: Transmit Data Positive Connector type: 9-pin D-Sub COM1_RXD+: Receive Data Positive 2x5 10-pin header, 2.0mm pitch COM1_RXD-: Receive Data Negative Connector location: CN9 COM1_GND... -
Page 24: Usb Ports
Chapter 2: Jumpers and Connectors COM4 Port and Connector: Serial Port RS232 USB Ports Connector type: Dual USB port (Ring or +12V Power for Pin 9) Connector location: USB1 and USB2 Connector type: 9-pin D-Sub 2x5 10-pin header, 2.0mm pitch Connector location: CN10 USB1 Definition... -
Page 25: Lan2 Port
Chapter 2: Jumpers and Connectors LAN2 Port LAN1 Port Connector type: RJ45 port with LEDs Support Wake on LAN (WOL) Connector location: LAN2 Connector type: RJ45 port with LEDs Connector location: LAN1 LINK LINK Status Link Status Status Link Status Yellow blinking Data activity Steady green... -
Page 26: Internal Connectors
Chapter 2: Jumpers and Connectors Internal Connectors LVDS Channel 1 LVDS Channel 2 Connector type: 2x10 20-pin header, 1.25mm pitch Connector type: 2x10 20-pin header, 1.25mm pitch Connector location: CN4 Connector location: CN5 Definition Definition Definition Definition LVDS_CLK1+(Odd) LVDS_CLK2+(Even) LVDS_DAT1-(Odd) LVDS_DAT5-(Even) LVDS_CLK1-(Odd) LVDS_CLK2-(Even) -
Page 27: Panel Backlight Connector
Chapter 2: Jumpers and Connectors Panel Backlight Connector Touch Sensor Connector Connector type: 1x7 7-pin header JST, 2.5mm pitch Connector type: 1x5 5-pin header JST, 2.5mm pitch Connector location: J7 Connector location: J9 Definition Definition 4-wire 5-wire VCC5 Left LL (L) UL (Y) BKLEN Sense (S) -
Page 28: Usb Connector
Chapter 2: Jumpers and Connectors USB Connector Bluetooth Connector Connector type: 1x6 6-pin header JST, 2.5mm pitch Connector type: 1x10 10-pin header, 1.0mm pitch Connector location: J8 Connector location: J6 Definition Definition Definition HUBUSB DM1- HUBUSB_DP3+ HUBUSB DP1+ HUBUSB_DM3- 3.3V HUBUSB DM2- HUBUSB DP2+... -
Page 29: Sata Connector
Chapter 2: Jumpers and Connectors SATA Connector SATA DOM Power Connector Connector type: Standard Serial ATAII 7P (1.27mm, SATA-M-180) Connector type: 1x2 2-pin header, JST 2.5mm pitch Connector location: CN3 Connector location: J2 Definition Definition TX0+ TX0- RX0- RX0+... -
Page 30: Line-In/Mic-In Connector
Chapter 2: Jumpers and Connectors Line-in/Mic-in Connector Speaker-out Connector Connector type: 2x4 8-pin header, 2.54mm pitch Connector type: 1x4 4-pin header, 2.54mm pitch Connector location: JP11 Connector location: J12 Line-in Mic-in Definition Definition Definition LINE IN_LP MIC_L3 OUT-L+ LINE IN_JD MIC_JD OUT-L- OUT-R+... -
Page 31: Gpio Connector
Chapter 2: Jumpers and Connectors GPIO Connector Connector type: 2x5 10-pin header, 2.0mm pitch DB15 male 10-pin Connector location: JP2 Internal Connector Definition Definition GPIO22 (GPO) GPIO20 (GPI) GPIO23 (GPO) GPIO21 (GPI) External Connector Definition Definition GPIO20 (GPI) GPIO21 (GPI) GPIO22 (GPO) GPIO23 (GPO) -
Page 32: Dio Connector
Chapter 2: Jumpers and Connectors DIO Connector Connector type: 2x8 16-pin header, 2.0mm pitch DB15 male 15-pin Connector location: CN2 Internal Connector External Connector Definition Definition Definition Definition DI1~DI4: Isolated digital input pins DO1~DO4: Isolated digital output pins COM: Common pin for connecting inductive loads of isolated output channels DO1~DO4 GND: Isolated ground... -
Page 33: Power/Hdd Led Indicator Connector
Chapter 2: Jumpers and Connectors Power/HDD LED Indicator Connector Backlight Control Input Connector Connector type: 1x5 5-pin header JST, 2.0mm pitch Connector type: 1x4 4-pin header JST, 2.0mm pitch Connector location: J10 Connector location: J5 Definition Definition HDD_GND HDD_PWR Tact Switch input PWR_GND PIR IN VCC3... -
Page 34: Backlight Control Input Connector
Chapter 2: Jumpers and Connectors Dimming Control Button Connector SIM Card Slot Connector location: CN8 Connector type: 1x5 5-pin header JST, 2.0mm pitch Connector location: J4 Definition Definition Definition UIM_PWR Decreased input UIM_RST UIM_VCCP Increased input UIM_CLK UIM_DAT Light sensor input VCC3... -
Page 35: Mini-Pcie Slot
Chapter 2: Jumpers and Connectors Mini-PCIe Slot Connector location: CN6 Definition Definition Definition Definition WAKE0# +3.3V_MINI +1.5V_MINI SMB_CLK +1.5V_MINI PCIE_TX3- SMB_DAT PCIE_TX3+ PCIE_CLKREQ SIM_PWR SIM_DAT USB6- USB6+ GPP_CLK1- SIM_CLK GPP_CLK1+ SIM_RST +3.3V_MINI +3.3V_MINI SIM_VCCP MINICARD1_DIS# PCIE_RST# +1.5V_MINI PCIE_RX2- +3.3V_MINI PCIE_RX2+ +3.3V_MINI... -
Page 36: Mini-Pcie Slot
Chapter 2: Jumpers and Connectors Mini-PCIe Slot Connector location: CN7 Definition Definition Definition Definition WAKE0# +3.3V_MINI +1.5V_MINI SMB_CLK PCIE_TX3- SMB_DAT +1.5V_MINI PCIE_TX3+ USB6- GPP_CLK1- USB6+ GPP_CLK1+ +3.3V_MINI +3.3V_MINI MINICARD1_DIS# PCIE_RST# +1.5V_MINI PCIE_RX2- +3.3V_MINI PCIE_RX2+ +3.3V_MINI... -
Page 37: Cfast Card Slot
Chapter 2: Jumpers and Connectors CFast Card Slot Power Button Connector Connector type: Standard CFast connector Connector type: 1x2 2-pin header, JST 2.0 mm pitch Connector location: J13 Connector location: J11 S7 PC1 PC17 Definition Definition Definition PWRBT SATA_TX1+ SATA_TX1- CFAST_LED1_C CFAST_LED2_C SATA_RX1-... -
Page 38: Block Diagram
Chapter 2: Jumpers and Connectors Block Diagram AcuPanel 15 LVDS CON Panel 19” SXGA 128X1024 CH7511 Display Port DP to LVDS LVDS CON Maximum resolution:1920x1080 DDI PORT1 EEJ!QPSU1 VGA DB15P in (Slim Type) Co-layout with BOX HEADER Maximum resolution:1900x1200 EES4... -
Page 39: Chapter 3: System Setup
Chapter 3: System Setup Chapter 3: System Setup Installing a SATA Hard Drive Prior to removing the chassis cover, make sure the unit's power CAUTION! is off and disconnected from the power sources to prevent electric shock or system damage. 1. - Page 40 Chapter 3: System Setup 2. Remove the mounting screws of the drive bay. 4. Place the SATA hard drive on the drive bay. Mounting screw SATA drive SATA power cable and SATA cable Drive bay 5. Align the mounting holes that are on the sides of the SATA drive with the mounting holes on the drive bay and then use the provided mounting screws to secure the drive in place.
-
Page 41: Installing A Cfast Card
Chapter 3: System Setup Installing a CFast Card 6. Place the SATA drive in the chassis and then use the provided mounting screws to secure the drive in the chassis. 1. The CFast card socket is located on the rear top side of the chassis. Connect the SATA data cable and SATA power cable to the connectorson the SATA drive. - Page 42 Chapter 3: System Setup 4. Push the CFast card to remove the CFast card. 3. With the CFast card's label facing up, insert the card until it is completely seated in the socket. CFast card...
-
Page 43: Installing A Sodimm
Chapter 3: System Setup Installing a SODIMM 1. Remove the mounting screws around the chassis cover and then remove the cover. 2. Remove the mounting screws on the metal support plate. - Page 44 Chapter 3: System Setup 3. Gently lift the motherboard support plate upwards and locate the SODIMM socket underneath. SODIMM SODIMM socket 4. Insert the module into the socket at an approximately 30 degrees angle. Apply firm even pressure to each end of the module until it slips into the socket.
-
Page 45: Installing A Sata Dom
Chapter 3: System Setup Installing a SATA DOM 1. Remove the drive bay bracket. The SATA connector is readily accessible 2. Remove the screw. upon removing the bracket. SATA connector... - Page 46 Chapter 3: System Setup 3. The SATA DOM package includes a supporting stud. The stud is used to 4. Install the supporting stud. Make sure the stud is fastened in place. stabilize the SATA DOM module. Supporting stud Supporting stud Cable SATA DOM...
- Page 47 Chapter 3: System Setup 5. Connect one end of the provided cable to the connector on the 6. Install the module to the SATA port via the connector at the solder side module. of the module and then secure the module using the mounting screw you removed in step 2.
- Page 48 Chapter 3: System Setup 7. Connect the other end of the cable to the connector on the board.
-
Page 49: Installing A Mini Pcie Module
Chapter 3: System Setup Installing a Mini PCIe Module 3.5G module kit Sierra Wireless MC8790V The Mini PCIe module package includes the following items: RALINK 802.11b/g/n 2T3R wireless mini card module kit QCOM:Q802XKN Mini PCIe Module 802.11b/g QN-MU-A0028 wireless mini card module kit INTEL112.BNHMWG Antennas RF Cables... - Page 50 Chapter 3: System Setup If you are installing the 802.11b/g QN-MU-A0028 wireless mini card 2. Tighten screws onto the mounting holes to secure the bracket. module (half-size), before proceeding with the installation, please assemble the Wi-Fi module bracket first by following the instructions below: 1.
-
Page 51: Installing The Half-Size Mini Pcie Module
Chapter 3: System Setup Installing the Half-Size Mini PCIe Module 1. Insert the Mini PCIe module into the Mini PCIe slot at a 45 degrees 2. Secure the module with mounting screws. angle until the gold-plated connector on the edge of the module completely disappears inside the slot. -
Page 52: Installing The Full-Size Mini Pcie Module
Chapter 3: System Setup Installing the Full-Size Mini PCIe Module 1. Insert the Mini PCIe module into the Mini PCIe slot at a 45 degrees 2. Secure the module with mounting screws. angle until the gold-plated connector on the edge of the module completely disappears inside the slot. - Page 53 Chapter 3: System Setup 3. Attach one end of the RF cables onto the module. 4. Push the antenna hole cover. RF cable RF cable...
- Page 54 Chapter 3: System Setup 5. Remove the antenna hole covers. 6. Insert the antenna jack end of the cable through the antenna hole. Antenna jack end of the cable...
- Page 55 Chapter 3: System Setup 7. Insert the ring onto the antenna jack end of the cable. 8. Connect external antennas to the antenna jacks. Antenna jack Ring Antenna jack Ring RF cable Mini PCIe module Antenna Antenna...
-
Page 56: Installing A Bluetooth Module
Chapter 3: System Setup Installing a Bluetooth Module 1. Remove the sticker on one side of the square rubber pad, then place that side on the back of the Bluetooth module. The Bluetooth module package includes the following items: Bluetooth module QCOMQBTM400-01(V7) Square rubber pad Module's backside 2. - Page 57 Chapter 3: System Setup 3. Remove the mounting screws of the drive bay. 4. Remove the drive bay and locate the Bluetooth connector and mounting hole on the mainboard. Bluetooth connector Mounting hole Mounting screw...
- Page 58 Chapter 3: System Setup 5. Remove the sticker on the square rubber pad 6. Align the mounting hole on the Bluetooth module to the mounting hole on the mainboard, then tighten screws to secure it. Once the module is secured, connect the cable to the Bluetooth connector. Bluetooth Sticker connector...
- Page 59 Chapter 3: System Setup 7. Install the drive bay back to its original position. 8. Attach one end of the RF cable onto the module. Attach RF cable to the module 9. Mount the other end of the cable to the Bluetooth mounting hole located at the rear top panel of the chassis.
-
Page 60: Placing Panel Mount Hole Blocks
Placing Panel Mount Hole Blocks 2. Insert the hole block into the opening until it is pushed in completely. The AcuPanel 15 comes with panel mount hole blocks to cover the panel mount openings on the chassis to prevent dust invasion. You can also choose to cover the panel mount holes when VESA mount is used. -
Page 61: Installing The Power Adapter Bracket
Chapter 3: System Setup Installing the Power Adapter Bracket 1. Locate the mounting screws for the bracket on the back side of the 2. Remove the mounting screws and store them in a safe place for later chassis. use. - Page 62 Chapter 3: System Setup 3. Wire the power adapter cabling into the cable opening on the bracket, then place the adapter inside the bracket. Cable opening Power adapter cable...
- Page 63 Chapter 3: System Setup 4. Turn the bracket over to the back side, and place the cable tie into the 5. Wrap the power adapter cable, then secure the cable firmly by tying the two tie mounts. cable tie. Tie mount Cable tie...
-
Page 64: Plugging The Dc Power Cable
Chapter 3: System Setup Plugging the DC Power Cable 6. With the bracket still facing backwards, align the mounting holes on the bracket to the mounting holes on the back of the chassis, then tighten screws to secure it. Once secured, plug the power adapter cable 1. -
Page 65: Panel Mounting
Panel PC must not exceed 6mm. If the distance between the front bezel and panel mount hole is too wide, it will not fit the panel mount kit. 371.00 Clamp 297.00 Panel Do not overtighten the screws to prevent damaging the CAUTION! Panel PC. AcuPanel 15... -
Page 66: Chapter 4: Bios Setup
When to Configure the BIOS This chapter describes how to use the BIOS setup program for the AcuPanel 15. ▪ This program should be executed under the following conditions: The BIOS screens provided in this chapter are for reference only and may change if the BIOS is updated in the future. -
Page 67: Entering Setup
Chapter 4: BIOS Setup Entering Setup Legends When the system is powered on, the BIOS will enter the Power-On Self Test Function (POST) routines. These routines perform various diagnostic checks; if an error is encountered, the error will be reported in one of two different ways: Moves the highlight left or right to select a menu. -
Page 68: Bios Setup Utility
Chapter 4: BIOS Setup BIOS Setup Utility Intel RC Version Displays the Intel Reference Code version. Once you enter the AMI BIOS Setup Utility, the Main Menu will appear on the screen. The main menu allows you to select from several setup functions and one exit. -
Page 69: Advanced
Chapter 4: BIOS Setup CPU Configuration This section is used to configure the CPU. Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc. Advanced Advanced The Advanced menu allows you to configure your system for basic operation. CPU Configuration Some entries are defaults required by the system board, while others, if Intel(R) Atom (TM) CPU Enabled for Windows XP and... - Page 70 Chapter 4: BIOS Setup IDE Configuration This section is used to configure the IDE devices. USB Configuration This section is used to configure USB devices. Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc. Advanced Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc. Not Present SATA Port0 Advanced...
- Page 71 Chapter 4: BIOS Setup Super IO Configuration Serial Port 0 Configuration This section is used to configure serial ports 0 to 4. This section is used to configure serial port 0. Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc. Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
-
Page 72: Serial Port 1 Configuration
Chapter 4: BIOS Setup Onboard Serial Port Max Baud Rate Serial Port 1 Configuration This field configures the maximum baud rate of the serial port 0, the options This section is used to configure serial port 1. are 115200 bps and 921600 bps. Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc. -
Page 73: Serial Port 2 Configuration
Chapter 4: BIOS Setup Onboard Serial Port Max Baud Rate Serial Port 2 Configuration This field configures the maximum baud rate of the serial port 1, the options This section is used to configure serial port 2. are 115200 bps and 921600 bps. Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc. -
Page 74: Serial Port 3 Configuration
Chapter 4: BIOS Setup Onboard Serial Port Max Baud Rate Serial Port 3 Configuration This field configures the maximum baud rate of the serial port 2, the options This section is used to configure serial port 3. are 115200 bps and 921600 bps. Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc. - Page 75 Chapter 4: BIOS Setup Onboard Serial Port Max Baud Rate H/W Monitor This field configures the maximum baud rate of the serial port 3, the options This section is used to configure the hardware temperature, fan speed and are 115200 bps and 921600 bps. voltages.
-
Page 76: Chipset
Chapter 4: BIOS Setup Chipset Host Bridge Displays the memory information This section is used to configure the system based on the specific features of the chipset. Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc. Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc. Main Advanced Chipset... - Page 77 Chapter 4: BIOS Setup Backlight On/Off Reverse Please configure this option only when changing the panel, otherwise the display may not work. Intel® IGD Configuration This section is used to configure the Intel® IGD Graphic configurations. Backlight Dimming Control Select The options are Tact Switch, Manual and Light sensor.
- Page 78 Chapter 4: BIOS Setup South Bridge Restore AC Power Loss Power Off Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc. When power returns after an AC power failure, the system's power is Main Advanced Chipset Save & Exit Boot Security off.
-
Page 79: Boot
Chapter 4: BIOS Setup Boot Quiet Boot Enabled Displays OEM logo instead of the POST messages. This section is used to configure the boot features. Disabled Displays normal POST messages. Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc. GateA20 Active Main Advanced... - Page 80 Chapter 4: BIOS Setup Hard Drive BBS Priorities Sets the order of the legacy devices in this group. Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit Boot Option #1 [SATA SM: 4GB SATA . . .] Sets the system boot order : Select Screen : Select Item...
-
Page 81: Security
Chapter 4: BIOS Setup Security Save & Exit Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc. Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc. Save & Exit Main Advanced Chipset Boot Security Main Advanced Chipset Boot Security Save &... - Page 82 Chapter 4: BIOS Setup Save Changes and Reset Boot Override To save the changes and reset, select this field then press <Enter>. A dialog To bypass the boot sequence from the Boot Option List and boot from a box will appear. Confirm by selecting Yes. particular device, select the desired device and press <Enter>.
-
Page 83: Appendix A: Gpi/O Programming Guide
Control the GPO pin (7/8) level from I/O port A04h bit (2/3). The bit is Set/Clear indicated output High/Low design. This appendix provides definitions and its default setting for the ten GPI/O pins in the AcuPanel 15. The pin definition is shown in the following table: GPIO programming sample code... -
Page 84: Appendix B: Digital I/O Programming Guide
Digital I/O (Digital Input/Output) pins are provided for custom system design. This appendix provides definitions and its default setting for the fifteen Digital I/O pins in the Acupanel 15. The pin definition is shown in the following table: GPI/O mode... - Page 85 Appendix B: Digital I/O Programming Guide GPIO programming sample code #define DIO_PORT 0xA05 #define DIO_PORTI 0xA01 #define DO9 (0x01 <<4) #define DO10 (0x01 <<5) #define DO11 (0x01 <<6) #define DO12 (0x01 <<7) #define DO9_HI outportb(GPIO_PORT, 0x10) #define DO9_LO outportb(GPIO_PORT, 0x00) #define DO10_HI outportb(GPIO_PORT, 0x20) #define DO10_LO...
-
Page 86: Appendix C: Watchdog Programming Guide
Appendix C: Watchdog Programming Guide Appendix C: Watchdog Programming Guide AcuPanel 15 Watch Dog Function Configuration Sequence Description: Start Step1. See "SetupWDT" procedure #Setup Watchdog Timer Environment Step2. See "TimeBaseWDT" procedure #Initial Watchdog Timer. Users can select second or minute. - Page 87 Appendix C: Watchdog Programming Guide =============================================== 2fh, al SetupWDT PROC dx, 2eh TimeBaseWDT ENDP al, 087h dx, al =============================================== TimeCountWDT PROC al, 73h ;WDT Time-out register. 2eh, al al, 01h dx, al al, 03h ;Here!! Set count 3. 2fh, al al, 55h TimeCountWDT ENDP dx, al...
-
Page 88: Appendix D: Power Consumption
Appendix D: Power Consumption Appendix D: Power Consumption Power Consumption Management AcuPanel 15 +12V +24V +30V Purpose The purpose of the power consumption test is to verify the power dissipation 3.2A 1.65A 1.26A Full-Loading Mode of the system and the load of the power supply. -
Page 89: Appendix E: Troubleshooting
1. I cannot make voice calls using 3.5G mini-PCIe card as network connection. Answer: AcuPanel 15' 3.5G connection only supports data transmission and does not support voice transmission. 2. The second VGA display is not working under DOS operating system.
Need help?
Do you have a question about the AcuPanel 15 and is the answer not in the manual?
Questions and answers
