  • Page 1 AcuPanel 12 User Manual AcuPanel 12 User Manual Version 7.1 Acura Embedded Systems Inc.

  • Page 2: Safety Instructions

    All Rights Reserved - Printed in Acura Embedded Systems Inc Disclaimer Acura Embedded Systems Inc shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages resulting from using this material, or the performance or use of this product.

  • Page 3: Table Of Contents

    AcuPanel 12 User Manual INDEX Table of Contents ................ 2 2.2. Installation Procedures ............9 2.2.1. Connecting the power cord ...........10 Chapter 1 General Information ..........3 2.2.2. Connecting the keyboard and mouse ........10 2.2.3. Switching on the power ............11 1.1. Introduction ................3 1.2.

  • Page 4: Chapter 1 General Information

    AcuPanel 12 User Manual Chapter 1 General Information 1.1. Introduction AcuPanel12 is an embedded Intel® Cedar Trail Dual Core 1.6 Ghz +Chipset: Intel® NM10 processor based Panel PC with a bright 10.4”/12.1" LCD display. The powerful Intel® NM10 chipsets bring the most dynamic applications to life without sacrifices to any industrial reliability.

  • Page 5: Touch Screen

    AcuPanel 12 User Manual • Viewing Angle: 12.1" 80° (left), 80° (right), 80° (up), 80° (down) • Lamp Life Time: 50,000 hours 1.3.3. Touch Screen • Touch Screen type: 5-wire Analog resistive type • Light Transmission: 80% • Durability (Touch lifetime): 35 million 1.3.4.

  • Page 6: Certifications

    AcuPanel 12 User Manual 1.3.9. Certifications 1.4. Physical Dimensions Your panel PC is equipped with fanless and no-ventilation-hole design and is durable to suit any critical environment. The following drawing shows you detailed information for the dimensions.
  • Page 7 AcuPanel 12 User Manual Dimensions (units in mm)

  • Page 8: Assembling The Panel Pc

    AcuPanel 12 User Manual 1.4.1. Assembling the panel PC The procedure for assembling the panel PC is identified by following drawing. Please follow the instruction below for panel mounting.

  • Page 9: Enclosed Parts

    AcuPanel 12 User Manual 1.4.2. Enclosed Parts SPEC ITEM PARTS M6*1.0+15PF-SUS RJ45, L=1.8M (Optional) DSUB, L=1.8M (Optional) USB, L=1.8M (Optional) DC Extension, L=1.8M...

  • Page 10: Chapter 2 System Setup

    Lets you connect the AC power adapter in supplying continuous power to AcuPanel12. 2.2. Installation Procedures AcuPanel 12 is designed and pre-configured for easy setup and use. This section describes the installation steps you should follow to get the system running as quickly as possible.

  • Page 11: Connecting The Power Cord

    AcuPanel 12 User Manual 2.2.1. Connecting the power cord To connect the power cord: 1. Connect the DC extension cable plug to the computer’s Power Supply Connector. 2. Connect the DC extension cable wires to the corresponding positive and negative terminals on the DC power supply.

  • Page 12: Switching On The Power

    AcuPanel 12 User Manual 2.2.3. Switching on the power The Power button is found on the left bottom on the rear side of the Panel PC. Press the Power button to start AcuPanel12 and check that the Power LED lights on to green on the front panel.

  • Page 13: Using The Usb Ports

    AcuPanel 12 User Manual 3. Turn on any other peripheral devices which are connected to the panel PC, and then turn on the panel PC. 4. Refer to the manual(s) which accompanied any serial device(s) for instructions on configuring the operating environment to recognize the device(s).

  • Page 14: Touchscreen

    AcuPanel 12 User Manual 3.5. Touchscreen AcuPanel12 is designed using Color Active Matrix LCD technology with a high quality touch sensitive surface. The touch screen is a display that can detect the presence and location of a touch within the display area by a finger, hand or other passive objects, such as a stylus. It enables one to interact with what is displayed directly on the screen, rather than indirectly with a mouse.

  • Page 15: Chipset Features

    AcuPanel 12 User Manual 4.4.Chipset Features This option lists all the features for chipset configuration. 4.5.Boot Features This option lists all onboard bootable devices. 4.6.Security Management Setup Set Administrator/User Password, These options let you create, change or disable the passwords.

  • Page 16: Save & Exit Setup

    AcuPanel 12 User Manual 4.7.Save & Exit Setup This option lets you saves all changes to CMOS while running the BIOS setup program and exit from the system setup program. WARNINGS THIS EQUIPMENT IS SUITABLE FOR USE IN CLASS I, DIVISION 2, GROUPS (AS APPLICABLE) OR NON-HAZARDOUS LOCATIONS ONLY.

  • Page 17: Technical Support

    AcuPanel 12 User Manual With the unique set of products, Acura Embedded Systems remains committed to its goal of providing trouble-free and customer-friendly service. A special customer service unit has been set up specifically to cater to our esteemed customers' needs.
