Summary of Contents for Automatic Technology Australia GDO-5-AS
-
Page 1: Installation Instructions
ROLL UP GARAGE DOOR OPENER OWNERS COPY Warning: Failure to comply with the Installation instructions and the Safety warnings may result in Serious Personal injury and/or Installation Instructions Property and Remote Control Opener damage. -
Page 2: Additional Safety
Automatic Technology Australia Roll Up Garage Door Opener in... -
Page 3: Operation
Automatic Opener Each or all codes can be deleted and Automatic Technology Australia in are of the latest technology and highest changed at any time. The codes can also aiding in the installation of the opener is quality. -
Page 4: Operating Controls
OPERATING CONTROLS 1. LIGHT CODE button (White) is 8. CLOSE LIMIT ADJUST SCREW 15. P.E. Input is for connection of used for storing or erasing the transmit- (Red) is used to fine adjust the close Photo Electric Beams (optional extra) ter button (code) you wish to use to turn limit stop position. - Page 5 OPERATING CONTROLS FORCE MARGIN SET BUTTON CLOSE DRIVE BUTTON (RED) OPEN LIMIT LED (GREEN) DOOR CODE BUTTON (BLUE) OPEN DRIVE BUTTON (GREEN) LIGHT CODE BUTTON O/S/C BUTTON (YELLOW) ENGAGE / DISENGAGE HANDLE RESET BUTTON OPEN LIMIT ADJUST SCREW (GREEN) AUTO CLOSE TIME BUTTON CLOSE LIMIT ADJUST SCREW (RED) CLOSE LIMIT LED (RED) OPEN LIMIT CAM (GREEN)
-
Page 6: Package Contents
PACKAGE CONTENTS ITEM QUANTITY DRIVE UNIT………………………………………………………………………………………….. CONTROL BOX……………………………………………………………………………………... KEY RING TRANSMITTER PTX-4……………...………………………………………………... (3.1) ALKALINE BATTERY A23 12V……………………………………………………………………. WEIGHT BARS (NOT INCLUDED IN SOME COUNTRIES)…………………………………..WEIGHT BARS ACCESSORY PACK (NOT INCLUDED IN SOME COUNTRIES)………..… (5.1) PAN HEAD SCREW M5x40………………………………………………………………………….. (5.2) HEX NUT M5………………………………………………………………………………………..(5.3) SPRING WASHER I.D 5………………………………………………………………………………... -
Page 7: Sequence Of Installation
SEQUENCE OF INSTALLATION SIDE ROOM REQUIREMENTS MINIMUM SIDE ROOM FIG. 1 135mm Fig. 1 shows the minimum side room that is required. The distance between the edge of the door curtain and the inside of 85mm the bracket is 85mm, and the distance between the edge of the door curtain and the outside of bracket is 135mm. -
Page 8: Left Or Right Hand Installation
FIG. 3 3. MOUNTING OF CONTROL BOX FIG. 4 1. Determine the position for the control box on the wall. Considering that it must be: a) out of reach of children, 1.5 mtr above the ground and b) close enough to the drive unit to run the 1.8 mtr connecting wires. - Page 9 INSTALLATION 5. FIXING DRIVE UNIT TO THE DOOR FIG. 6 (RIGHT HAND INSTALLATION) The Automatic Openers Drive Unit can be fixed to the Roll Up Garage Door in a variety of ways. Below we will describe one method of fixing. Make sure there is enough side room (135mm from end of door shaft to the wall) to slide Drive Unit onto shaft.
-
Page 10: Setting Limit Switches
INSTALLATION 6. FIXING OF DOOR CURTAIN TO DRUM FIG. 9 WHEEL The door curtain has to be secured to the drum wheel with suit- able fasteners. 1. With the door in the fully closed position, mark the curtain (Fig. 9) on both ends of the door. 2. -
Page 11: Installation
INSTALLATION NOTE: If the door has not reached the desired limit position by FIG. 12 more then 30mm, then it is recommended that the green limits cam be adjusted again before the green fine adjustment screw is adjusted. CLOSE LIMIT ADJUSTMENT Press in and hold the Red Close button. - Page 12 INSTALLATION OPEN LIMIT ADJUSTMENT FIG. 14 Press in and hold the Green Open Button (Fig. 14) The door should start opening. Release the Green Open button when the door reaches the desired open limit stop position. If the Green LED (Fig. 14) is illuminated and the desired limit stop position has been reached then the limit adjustment is complete.
-
Page 13: Important Note
INSTALLATION 8. SETTING OF OPEN AND CLOSE SAFETY OBSTRUCTION FORCE FIG. 16 The Safety Obstruction Force is calculated automatically and set in memory on the Automatic Opener. This applies to both the Open Force and Close Force. Warning: When step 8.1 is initiated the Garage Door will do a full open and close cycle automatically. -
Page 14: Testing Open Cycle
INSTALLATION 8.5 SAFETY OBSTRUCTION TEST FIG. 18 TESTING CLOSE CYCLE 1. Open the door by pressing the Yellow O/S/C button 4 (Fig. 18). 2. Place a length of timber 100mm X 50mm on the floor directly under the door (Fig. 17). 3. -
Page 15: Setting Of Courtesy Light Time
INSTALLATION 10. SETTING THE TRANSMITTER TO FIG. 20 OPERATE THE COURTESY LIGHT The Transmitter can be programmed to operate the Courtesy Light on the Door Opener. 1. Press and hold Light Code button 10 on the Control Panel (Fig. 20). 2. -
Page 16: Setting Auto Close Time
INSTALLATION FIG. 23 13. FITTING OF SAFETY PHOTO ELECTRIC BEAM (OPTIONAL) Locate the Photo Electric Beam (P.E.) normally closed contact type in a strategic location within doorway. Remove shunt from P.E connector (Fig. 23) and connect the plug from the P.E. wiring harness to P.E. -
Page 17: Factory Default Settings
INSTALLATION Factory Default Settings FUNCTION DEFAULT STEP MAXIMUM MAXIMUM MOTOR RUN TIME — 30 Sec. — COURTESY LIGHT TIME 10 Min. 10 Sec. 3 Min. OBSTRUCTION FORCE MARGIN AUTO CLOSE TIME 4 Min. 5 Sec. 0 Sec = Off Door Status Indicators DOOR OPENER STATE OPEN CLOSE... -
Page 18: Spare Parts List
SPARE PARTS LIST WHEN ORDERING SPARE PARTS PLEASE QUOTE THE ORDER CODE NUMBER TO YOUR YOUR INSTALLER/DISTRIBUTOR... -
Page 19: Troubleshooting
TROUBLE SHOOTING SYMPTOM POSSIBLE CAUSE REMEDY Door will not operate Main Power not turned on Turn on Mains Power Door is obstructed Remove obstruction Door in locked or motor jammed Unlock door and Inspect door and remove jam Door will not reverse when Door needs to be re-initialised Fully close the door and press the Reset obstructed... -
Page 20: Warranty And Exclusion Of Liability
WARRANTY AND EXCLUSION OF LIABILITY Subject to all of the matter set out below, Automatic Technology Australia Pty Ltd (“ATA”) WARRANTS for twenty four (24) months from the date of purchase (specified in the receipt sales docket) that the Garage Door Opener System contained in the accompanying packaging (the “Product”) is free of any defects in material and workmanship rendering it unmerchantable.
