AUTOMATIC TECHNOLOGY AUSTRALIA PTY LTD
GDO-8 v1 EasyRoller
®
II
ROLL UP GARAGE DOOR OPENER
WARNING
OWNERS COPY
It is vital for the safety of persons to follow all
instructions. Failure to comply with the installation
instructions and the safety warnings may result in
serious personal injury and/or property and remote
Installation Instructions
control opener damage.
Please save these instructions for future reference.
Advertisement
Table of Contents
Related Manuals for Automatic Technology Australia GDO-8 v1 EasyRoller II
Summary of Contents for Automatic Technology Australia GDO-8 v1 EasyRoller II
-
Page 1: Installation Instructions
AUTOMATIC TECHNOLOGY AUSTRALIA PTY LTD GDO-8 v1 EasyRoller ® ROLL UP GARAGE DOOR OPENER WARNING OWNERS COPY It is vital for the safety of persons to follow all instructions. Failure to comply with the installation instructions and the safety warnings may result in... -
Page 3: Table Of Contents
Automatic Technology Australia Pty Ltd to the extent that such may be lawfully excluded hereby expressly disclaims all conditions or warranties, statutory or otherwise which may be implied by laws as conditions or warranties of purchase of an Automatic Technology Australia Pty Ltd Roll Up Garage Door Opener. -
Page 4: Safety Warnings
IMPORTANT SAFETY INSTRUCTIONS Warning - It is vital for the safety of persons to follow all instructions. Failure to comply with the following Safety Rules may result in serious personal injury and/or property damage. ADDITIONAL SAFETY protection The unit is rated to IP24, however, it should be installed STRONGLY recommend the fitting of a Photo Electric so that it is protected from the elements. -
Page 5: Product Features
FEATURES Thank you for purchasing the ATA ALPS (AUTOMATIC LIMITS OVER LOAD INDICATOR EasyRoller Automatic Garage Door POSITIONING SYSTEM) When the maximum opening and Opener. This opener is designed to suit ALPS system automatically closing capacity of the opener is vertical operating continuous curtain calculates the doors’... -
Page 6: Operating Controls
OPERATING CONTROLS PROG INPUT is used for the OPERATE button (blue) is used OPEN LIMIT LED (green) the connection of the ATA Universal during installation to test the open, very helpful during Programmer for the purpose of stop and close cycles for the installation. - Page 7 OPERATING CONTROLS PROGRAMMER INPUT FORCE MARGIN SET BUTTON P.E. BEAM INPUT PLUS BUTTON (FOR LIMITS SETTING & FORCE MARGIN) DOOR STATUS LED (YELLOW) OPEN LIMIT LED (GREEN) DATUM ADJUST SCREW MINUS BUTTON (FOR LIMITS SETTING & FORCE MARGIN) DOOR CODE BUTTON (BLACK) CLOSE LIMIT LED (RED) CODING LED (RED) MANUAL RELEASE HANDLE...
-
Page 8: Package Contents
PACKAGE CONTENTS ITEM QUANTITY GDO-8 EASYROLLER DRIVE UNIT ® KEY RING TRANSMITTER PTX-4 ALKALINE BATTERY A23 12V WEIGHT BAR (NOT INCLUDED IN SOME MODELS) PAN HEAD SCREW M4x50mm (NOT INCLUDED IN SOME MODELS) NILOCK HEX NUT M4 (NOT INCLUDED IN SOME MODELS) FLAT WASHER I.D 3/16 x 1/2 (NOT INCLUDED IN SOME MODELS) LOCKING BAR COVERS INSTALLATION MANUAL... -
Page 9: Side Room Requirements
BEFORE INSTALLATION IMPORTANT SAFETY INSTRUCTIONS FOR FIG. 1 INSTALLATION Warning: Incorrect installation can lead to severe injury. Follow ALL installation instructions. SIDE ROOM REQUIREMENTS Fig. 1 shows the minimum and recommended side room that is required to mount the opener. The distance between the edge of the door curtain and the inside of the bracket must be at least 40mm. -
Page 10: Mounting The Opener
MOUNTING THE OPENER 4. FIXING DRIVE UNIT TO THE DOOR FIG. 4 The EasyRoller Drive Assembly can be fixed to the roll up garage door in a variety of ways. Described below is one method of fixing. Make sure there is enough side room to slide the drive assembly onto shaft. -
Page 11: Fixing Curtain To Drum
SETTING LIMITS 5. FIXING OF DOOR CURTAIN TO DRUM FIG. 7 WHEEL The door curtain has to be secured to the drum wheel with suitable fasteners. 1. With the door in the fully closed position, mark the curtain (Fig. 7) on both ends of the door. 2. -
Page 12: Setting Limits Via Transmitter
SETTING LIMITS 6.3 SETTING LIMITS VIA REMOTE CONTROL FIG. 10 NOTE: The opener is factory preset for installation on the RIGH HAND SIDE. When the opener is mounted on the left side of the door the opener will travel in reverse. 1. -
Page 13: Setting Obstruction Force Margin (Iss)
SETTING SAFETY OBSTRUCTION FORCE 8. SAFETY OBSTRUCTION TEST FIG. 12 Please take care when testing the Safety Obstruction Force. Due to Excessive forces failure to follow this warning may cause SERIOUS PERSONAL INJURY and/or property damage. The test below should be repeated at regular intervals (approximately every two months). -
Page 14: Coding Transmitters
CODING TRANSMITTERS 9. SETTING TRANSMITTERS CODES FIG. 14 Make sure to insert the battery into the transmitters. The memory in the openers receiver can store up to eight remote control transmitters. 10.1 STORING THE TRANSMITTERS CODE 1. Press and hold the Door Code button (Fig. 14). Press and hold 2. -
Page 15: Connecting Photo Electric Beam
PE BEAM AND FINAL SET UP 13. FITTING THE SAFETY PHOTO FIG. 16 ELECTRIC BEAM SENSOR (OPTIONAL) Locate the Photo Electric Beam (P.E.) normally closed contact type in a strategic location within doorway. We recommend 150mm above the floor level and as close as possible to the door opening, inside the garage. -
Page 16: Door Status Indicators
PARAMETERS DOOR STATUS INDICATORS OPEN LED CLOSE LED DOOR STATUS DOOR OPENER STATE BEEPER GREEN LED YELLOW OPEN CLOSE OPENING FLASHING FLASHING CLOSING DOOR TRAVEL STOPPED FLASHING FLASHING DOOR OBSTRUCTED WHEN OPENING FLASHING BEEPS WHILE DOOR OBSTRUCTED WHEN CLOSING FLASHING DOOR IS MOVING ALTERNATING ALTERNATING... -
Page 17: Factory Default Settings
DEFAULT SETTINGS AND SPECIFICATIONS FACTORY DEFAULT SETTINGS DEFAULT STEP MAXIMUM MAXIMUM MOTOR RUN TIME 30 Secs. — — OBSTRUCTION FORCE MARGIN TECHNICAL SPECIFICATIONS INPUT VOLTAGE: 230V - 240V AC 50Hz CONTROLLER VOLTAGE: 24V DC STANDBY POWER: 2.8 Watts MOTOR POWER: 100 Watts MOTOR TYPE: 24V DC Permanent Magnet... -
Page 18: Trouble Shooting Guide
TROUBLE SHOOTING SYMPTOM POSSIBLE CAUSE REMEDY Switch on mains power. Door will not operate. Mains power not switched on. Remove obstruction. Door is obstructed. Unlock door or remove jam. Door is locked or motor jammed. Door requires service/repair by qualified Door tracks/hardware damaged. -
Page 19: Parts List
SPARE PARTS LIST... -
Page 20: Warranty
Trade Practices Act 1974 (Cth). 2. Subject to all of the matters set out below, Automatic Technology Australia Pty Ltd ("ATA") warrants: (a) roll-up door opener drive units for twelve (12) months or 2500 cycles, whichever occurs first; and (b) all components and accessories for twelve (12) months, from the date of purchase (specified in the sales docket receipt) as free of any defects in material and workmanship.
