Symbol STB3408 Quick Reference Manual

Regulatory Information
All Symbol devices are designed to be compliant with rules and regulations in locations they are sold
and will be labeled as required.
Any changes or modifications to Symbol Technologies equipment, not expressly approved by Symbol
Technologies, could void the user's authority to operate the equipment.
Antennas: use only the supplied or an approved replacement antenna. Unauthorized antennas,
modifications, or attachments could cause damage and may violate regulations.
Radio Modules
The STB3478 contains an approved radio module. This module is identified below.
Symbol Bluetooth™ Radio, Type: 21-64381.
Bluetooth Devices
The STB3478 is an approved Bluetooth device. Bluetooth ID: BT01785.
Health and Safety Recommendations
Ergonomic Recommendations
Caution: In order to avoid or minimize the potential risk of ergonomic injury follow the
recommendations below. Consult with your local Health & Safety Manager to ensure that you are
adhering to your company's safety programs to prevent employee injury.
• Reduce or eliminate repetitive motion
• Maintain a natural position
• Reduce or eliminate excessive force
• Keep objects that are used frequently within easy reach
• Perform tasks at correct heights
• Reduce or eliminate vibration
• Reduce or eliminate direct pressure
• Provide adjustable workstations
• Provide adequate clearance
• Provide a suitable working environment
• Improve work procedures.
FCC RF Exposure Guidelines
Safety Information
The device complies with Internationally recognized standards covering Specific Absorption Rate
(SAR) related to human exposure to electromagnetic fields from radio devices.
Reducing RF Influence – Use Properly
It is advisable to use the device only in the normal operating position and it is recommended that no
part of the human body be allowed to come too close to the antenna during operation of the
equipment.
To satisfy FCC RF exposure requirements, a mobile transmitting device must operate with a minimum
separation distance of 20 cm or more from a person's body.
Power Supply
Use only a Symbol-approved power supply 50-14000-101 output rated 9 Vdc and minimum 1 A. The
power supply is certified to EN60950 with SELV outputs. Use of alternative power supply will
invalidate any approval given to this device and may be dangerous.
Benutzen Sie nur eine Symbol Technologies genehmigt Stromversorgung 50-14000-101 in den
Ausgabe: 9 Vdc und minimum 1 A. Die Stromversorgung ist bescheinigt nach EN60950 mit SELV
Ausgaben. Bei Verwendung eines anderen Netzteils werden alle für das Gerät gewährten
Genehmigungen außer Kraft gesetzt, und der Betrieb kann gefährlich sein.
Radio Frequency Interference Requirements-FCC
Radio Transmitters (Part 15)
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference,
and (2) this device must accept any interference received, including
interference that may cause undesired operation.
Radio Frequency Interference Requirements-Canada
Radio Transmitters
This device complies with RSS 210 of Industry & Science Canada. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference and (2) this device must
accept any interference received, including interference that may cause undesired operation.
Label Marking: The Term "IC:" before the radio certification only signifies that Industry Canada
technical specifications were met.
Marking and European Economic Area (EEA)
Bluetooth for use through the EEA have the following restrictions:
• Maximum radiated transmit power of 10mW EIRP in the frequency range 2.400-2.4835 GHz
• Belgium outside usage, the equipment is restricted to 2.460 -2.4835 GHz frequency range
• Italy requires a user license for outside usage.
Statement of Compliance
Symbol Technologies, Inc., hereby, declares that this device is in compliance with the essential
requirements and other relevant provisions of Directives 1999/5/EC, 89/336/EEC and 73/23/EEC.
Declaration of Conformities may be obtained from http://www2.symbol.com/doc/.
Other Countries
• Mexico - Restrict Frequency Range to: 2.450 – 2.4835 GHz.
• Israel - Restrict Frequency Range to: 2.418 – 2.457 GHz.
• Sri Lanka - Restrict Frequency Range to: 2.400 – 2.430 GHz.
Introduction
The cordless scanner cradle acts as a stand, host communication interface, and charger for the
LS 3478 cordless scanner. It can sit on a desktop or be mounted on a wall.
There are two configurations of the cradle:
• STB3478-C0007WW: charging cradle with radio for desk/wall mounting
• STB3408-C0007: charging cradle only for desk/wall mounting.
The STB3478 cradle receives data from the scanner via a Bluetooth radio, and sends that data
to the host through an attached cable. The cradle also charges the scanner's internal battery
pack when the scanner is inserted. The scanner can be charged from an external power supply
or using a powered host cable.
This document provides basic instructions on setting up and using the cradle. Unless otherwise
noted, "cradle" refers to both configurations of the cradle. Any discussion of transmission of
information refers specifically to the STB3478 cradle.
Equipment Supplied
The cradle package includes:
• Cradle
• Four rubber feet (for desk mounting).
Accessories
The following equipment may be needed:
• Three 1.5" #8 Philips head screws (for wall mounting, if applicable, not available from
Symbol)
• Power supply for desk/wall mounting configuration (Symbol p/n 50-14000-101).
Save the shipping container for storing or shipping. Inspect all equipment for damage. If
anything is damaged or missing, call an authorized Customer Support Representative
immediately.
Related Documentation
LS 3478 Cordless Scanner Product Reference Guide, p/n 72-67139-xx.
LS 3478 Cordless Scanner Quick Start Guide, p/n 72-67137-xx.
This documentation is available at: http://www.symbol.com/manuals
Cradle Parts (Front)
Mounting
Mounting
Screw Hole
Screw Hole
Pairing Bar
Code
Mounting
Screw Hole
Latch
Latch
Charging/
Communication
Contacts
