- Page 2 © 2003 SYMBOL TECHNOLOGIES, INC. All rights reserved. Symbol reserves the right to make changes to any product to improve reliability, function, or design. Symbol does not assume any product liability arising out of, or in connection with, the application or use of any product, circuit, or application described herein.
- Page 3 • inter-connect up to four CRD8800-4000S serial cradles to the CRD8800-4000E cradle, providing a total of 20 slots available for host communications and charging. About This Guide Specific topics in this guide include: •...
- Page 4 For detailed information on any PPT 8800 Series terminal, refer to the PPT 8800 Series Quick Reference Guide or the PPT 8800 Series Product Reference Guide. Requirements • for power connection For U.S Customers Power Supply, p/n 50-14000-109 AC Cord, p/n 23844-00-00 For International Customers Power Supply, p/n 50-14000-109 AC Cord, appropriate for your country...
-
Page 5: Parts Of The Cradle
Q u i c k R e f e r e n c e Parts of the Cradle FRONT Communication LED Terminal Slot BACK DC Power Port Ethernet Port Expansion Port There are three connection ports on the rear of the CRD8800- 4000E: Ports Function... -
Page 6: Power Connection
Power Connection To connect power to the cradle: Power Supply AC Cord... -
Page 7: Connecting To An Ethernet Hub
Q u i c k R e f e r e n c e Connecting to an Ethernet Hub To connect the cradle to an Ethernet hub: Ethernet Cable To Ethernet hub Note: For Ethernet communication setup, refer to the termi- nal’s Product Reference Guide. - Page 8 Terminal Battery Charging 1. Ensure the cradle is connected to a power source. See Power Connection on page 2. Insert the terminal into the cradle. The terminal starts to charge automatically. Note: To ensure the quickest charging time, turn the terminal off while charging.
- Page 9 R e f e r e n c e Inter-Connecting Cradles Up to four Four-Slot Serial cradles (CRD8800-4000S) may be inter-connected (daisy-chained) with the CRD8800-4000E using an RJ-45/10 to RJ-45/10 inter-cradle cable. The required cables are as follows: Host Cradle...
-
Page 10: Communication Led Indicator
4. Plug one end of inter-cradle cable (p/n 70349-001) into the EXPANSION port on the back of the first CRD8800-4000S cradle. 5. Plug the other end of the inter-cradle cable into the Serial port on the back of the next CRD8800-4000S cradle. 6. -
Page 11: Troubleshooting
Q u i c k R e f e r e n c e Troubleshooting Symptom Cause Suggested Action Terminal battery is Terminal was re- Replace the terminal in the cradle. not charging. moved from the cra- The standard battery usually fully dle too soon. - Page 12 Symptom Cause Suggested Action Attempt by the termi- Terminal removed Wait one minute and reinsert the nal to ActiveSync from the cradle while terminal in the cradle. This allows failed. the LED was blinking the cradle to attempt another syn- green.
-
Page 13: Regulatory Information
R e f e r e n c e Regulatory Information All Symbol devices are designed to be compliant with rules and regulations in locations they are sold and will be labeled as required. Any changes or modifications to Symbol Technologies equipment, not expressly approved by Symbol Technologies, could void the user's authority to operate the equipment. - Page 14 CE Mark which indicates compliance to applicable Directives and European Normes (EN). Statement of Compliance Symbol Technologies, Inc., hereby declares that this device is in compliance with all the applicable Directives, 89/336/EEC, 73/23/EEC. A Declaration of Conformity may be obtained from http://www2.symbol.com/doc/...
- Page 15 Product result from normal wear and tear, misuse, negligence, improper storage, water or other liquids, battery leakage, use of parts or accessories not approved or supplied by Symbol, or failure to perform operator handling and scheduled maintenance instructions supplied by Seller; (iii) which...
-
Page 16: Service Information
Distributor Operations +44 118 945 7360 Customer support is available 24 hours a day, 7 days a week. For the latest version of this guide go to: http://www.symbol.com/manuals. 72-59203-01 Revision A — July 2003 Symbol Technologies, Inc. One Symbol Plaza, Holtsville, N.Y. 11742-1300...
