Summary of Contents for Stoelting CBD117
- Page 1 Model CBD OPERATORS MANUAL Manual No. 513852 Rev.2...
- Page 3 DO NOT ATTEMPT to operate the machine until instructions and safety precautions in this manual are read completely and are thoroughly understood. If problems develop or questions arise in connection with installation, operation, or servicing of the machine, contact Stoelting. Clearbowl Service Information: 888.429.5920 (U.S.
-
Page 4: Safety Information
CAUTION If you need to replace a part, use genuine Stoelting The signal word “CAUTION” indicates a potentially parts with the correct part number or an equivalent hazardous situation, which, if not avoided, may result part. -
Page 5: Table Of Contents
TABLE OF CONTENTS Section Description Page Description and Specifi cations Description ....................1 Specifi cations ..................... 2 Installation Instructions Safety Precautions ..................3 Shipment and Transit .................. 3 Machine Installation ..................3 Defrost Timer ....................3 Initial Set-Up and Operation Operator’s Safety Precautions .............. -
Page 7: Description And Specifi Cations
CBD machines. This manual applies to all CBD model machines in single and double tank confi gurations. Figure 1-1 Model CBD117-37 Figure 1-2 Model CBD127-37 Operators Manual #513852 Rev.2 CBD Model Machines... -
Page 8: Specifi Cations
SPECIFICATIONS Model CBD117 CBD127 Dimensions Machine Machine width 9-7/8’’ (25,1 cm) 17-3/8’’ (44,1 cm) height 21-7/8’’ (55,6 cm) 21-7/8’’ (55,6 cm) depth 18-3/4’’ (47,6 cm) 18-3/4’’ (47,6 cm) Weight 55 lbs (24,9 kg) 75 lbs (34,0 kg) Electrical 1 Phase, 115 VAC, 60Hz... -
Page 9: Installation Instructions
10 days and request inspection. The customer must place claim for damages and/or shortages in shipment with the carrier. Stoelting, Inc. cannot make Clean and sanitize the machine before the fi rst any claims against the carrier. - Page 10 TIMER DISPLAY The display shows the day and time, program number, and defrost icon (asterisk symbol to the left of the pro- gram number). When the program number is even, the Auto defrost mode is active and the asterisk icon is lit. When Switch Switch the program number is odd, the machine is in normal...
- Page 11 Move the Run switch to Program (P). A “1” is shown on the display to the right of the minute value and signifi es the start of a defrost mode. Press the 1...7 button to select the day of the week.
- Page 12 Operators Manual #513852 Rev.2 CBD Model Machines...
-
Page 13: Initial Set-Up And Operation
SECTION 3 INITIAL SET-UP AND OPERATION 3.1 OPERATOR’S SAFETY PRECAUTIONS 3.2 OPERATING CONTROLS AND INDICATORS SAFE OPERATION IS NO ACCIDENT; observe these Before operating the machine, it is required that the op- rules: erator know the function of each operating control. Refer to Figure 3-1 for the location of the operating controls on Know the machine. -
Page 14: Assembly Of Machine
Spigot Lock Slush Density Refrigeration The Spigot Lock is a lever located behind the Indicator Indicator spigot handle that locks the spigot handle in the open or closed position. When the spigot is in the desired position, push the lever clockwise to lock it in place. -
Page 15: Sanitizing
Press the gear onto the back of the horizontal When sanitizing the machine, refer to local sanitary regu- auger and install the auger. lations for applicable codes and recommended sanitizing products and procedures. The frequency of sanitizing Place the gasket into the bottom groove on the must comply with local health regulations. -
Page 16: Removing Mix From Machine
Place the top cover onto the tank. After the mix has been removed from the machine, follow the steps below to disassemble the parts. Press the Auger Movement button and the Cold Selection button. Press the Cold Selector button multiple times to toggle between “motor on” mode, CAUTION slush, and cold drink. -
Page 17: Routine Cleaning
Prepare sanitizing solution according manufacturer’s instructions to provide a 100 ppm strength solution. Mix the sanitizer in quantities of no less than 2 gallons of 90° to 110°F (32° to 43°C) water. Check the strength of the sanitizing solution. Use a chlorine test strip and color chart to make sure the solution has 100 ppm. - Page 18 Operators Manual #513852 Rev.2 CBD Model Machines...
-
Page 19: Troubleshooting
SECTION 4 TROUBLESHOOTING 4.1 ALARMS If one of the Slush Density Indicator LEDs blinks, follow the instructions below to troubleshoot the alarm. Slush Density Refrigeration NOTE Indicator Indicator Turn the Main Power switch Off then On again after resolving an alarm. Auger WARNING Movement... - Page 20 Operators Manual #513852 Rev.2 CBD Model Machines...
-
Page 21: Replacement Parts
SECTION 5 REPLACEMENT PARTS 5.1 DECALS Part Description Quantity 324987 Decal - Pull Here 1 per tank 5.2 TANK AND COVER 493128 724058 396697 Part Description Quantity 493128 Cover - Tank 1 per tank 396697 Gasket - Tank 1 per tank 724058 Tank - 1.5 Gallon 1 per tank... -
Page 22: Handle Assembly And Auger Parts
5.3 HANDLE ASSEMBLY AND AUGER PARTS 538620 674222 674208 405580 538621 221457 405585 221458 624700 647215 674209 396696 314225 428096 724062 442129 142081 442128 175558 Part Description Quantity 142081 Base - Tank Clamp 2 per tank 175558 Locking Screw - Tank Clamp 2 per tank 221457 Bushing - Transmission Shaft... - Page 23 CLEAR BOWL SERIES EQUIPMENT 1. Scope: PW Stoelting, L.L.C. (“Stoelting”) warrants to the first user (the “Buyer”) that the compressors of clear bowl series equipment supplied or manufactured by Stoelting will be free from defects in materials and workmanship under normal use and proper maintenance appearing within five (5) years, and that...
