Sprint Wi-Fi Connect Technical Manual page 5

Position Your Wi-Fi Connect
For the best wireless signal transmission between
your Wi-Fi Connect and the network devices
connected to it, ensure that you:
• Place your Wi-Fi Connect in a centralized area for a
maximum wireless coverage for the network devices.
• Keep your Wi-Fi Connect away from metal
obstructions and away from direct sunlight.
• Keep your Wi-Fi Connect away from 802.11g or
20MHz only Wi-Fi devices, 2.4GHz computer
peripherals, Bluetooth devices, cordless phones,
transformers, heavy-duty motors, fluorescent
lights, microwave ovens, refrigerators, and other
industrial equipment to prevent signal interference
or loss.
• Screw the three detachable antennas into the
threaded antenna posts on your Wi-Fi Connect.
• Orient the antennas as shown in the
illustration below.
45°
90°
45°
visit sprint.com/inhomecoverage for guides, tutorials and more
Mount to the Stand
To mount your Wi-Fi Connect to the stand:
1. Align and insert the stand's mounting hooks
into the mounting holes on the back of your
Wi-Fi Connect.
2. Slide the mount until it locks into position.
5
