Device Layout
1
Power LED
2 LAN LED
3 WAN LED
4 2.4GHz LED
5 5GHz LED
6 USB 2.0 LED
1
2
4
6
5
4
3
7
Power (DC-IN) Port
8 Power Button
9 USB 2.0 Ports
10 Reset Button
11 Internet & LAN Ports
12 WPS Button
1
7
8
9
10
On
O
Please Note: Your Wi-Fi Connect has a Power Button
to turn it on and off.
2
3
11
12
6
5
4
