evertz 7700DA6-L Manual

Sd-sdi video distribution amplifier with loop thru
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
1. OVERVIEW ............................................................................................................................... 1
2. INSTALLATION ........................................................................................................................ 3
3. SPECIFICATIONS .................................................................................................................... 4
3.1.
SERIAL VIDEO INPUT ............................................................................................................... 4
3.2.
SERIAL VIDEO OUTPUT ........................................................................................................... 4
3.3.
PHYSICAL ................................................................................................................................. 4
3.4.
ELECTRICAL ............................................................................................................................. 4
4. STATUS LEDS ......................................................................................................................... 5
5. JUMPERS AND USER ADJUSTMENTS.................................................................................. 6
5.1.
BY THE GLOBAL FRAME STATUS .......................................................................................... 6
5.2.
CONNECTING LOOP THRU ...................................................................................................... 6
5.3.
LOCAL CONTROLS OR THROUGH THE VISTALINK
5.4.
SELECTING THE RECLOCKING RATE .................................................................................... 7
5.5.
CONFIGURING THE MODULE FOR FIRMWARE UPGRADES ................................................ 7
®
6.1.
6.2.
®
6.3.
®
6.4.
®
7700DA6-L SD-SDI Video Distribution Amplifier with Loop Thru

TABLE OF CONTENTS

? ............................................................................................................. 8
®
MONITORED PARAMETERS ............................................................................... 8
TRAPS .................................................................................................................. 9
INTERFACE ....................................... 7
®
Revision 1.2
7700 MultiFrame Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 7700DA6-L and is the answer not in the manual?

Questions and answers

Related Manuals for evertz 7700DA6-L

Summary of Contents for evertz 7700DA6-L

  • Page 1: Table Of Contents

    7700 MultiFrame Manual 7700DA6-L SD-SDI Video Distribution Amplifier with Loop Thru TABLE OF CONTENTS 1. OVERVIEW ..........................1 2. INSTALLATION ........................3 3. SPECIFICATIONS ........................4 3.1. SERIAL VIDEO INPUT ....................... 4 3.2. SERIAL VIDEO OUTPUT ......................4 3.3. PHYSICAL ..........................4 3.4.
  • Page 2 7700 MultiFrame Manual 7700DA6-L SD-SDI Video Distribution Amplifier with Loop Thru Figures Figure 1-1: 7700DA6-L Block Diagram ......................... 2 Figure 2-1: 7700DA6-L Rear IO Module ........................ 3 Figure 5-1: LED and Jumper Locations ......................... 6 Tables Table 6-1: VistaLINK Monitored Parameters ....................... 8 ®...

  • Page 3: Revision History

    Aug 14 Information contained in this manual is believed to be accurate and reliable. However, Evertz assumes no responsibility for the use thereof nor for the rights of third parties, which may be affected in any way by the use thereof. Any representations in this document concerning performance of Evertz products are for informational use only and are not warranties of future performance, either expressed or implied.
  • Page 4 7700 MultiFrame Manual 7700DA6-L SD-SDI Video Distribution Amplifier with Loop Thru This page left intentionally blank Revision 1.2...

  • Page 5: Overview

    SMPTE 310M support is selected by setting a rate select jumper. The 7700DA6-L occupies one card slot and can be housed in the 1RU 7701FR frame which holds up to three single or dual slot modules, the 3RU 7800FR frame which has a 15 slot capacity, the portable 3RU 350FR frame which has a 7 slot capacity, or a standalone enclosure which holds a single module.

  • Page 6: Figure 1-1: 7700Da6-L Block Diagram

    7700 MultiFrame Manual 7700DA6-L SD-SDI Video Distribution Amplifier with Loop Thru VistaLINK Cable Drivers ® Interface Control / Local Indication Local Control Indication SDI In 6 SDI Reclock Equalizer SMPTE 310M* Outputs 143MB/s to 540Mb/s Reclock (Signal Loop Thru Present) *Note: Non-Reclocking Mode will operate 19.4Mb/s to 540Mb/s...

  • Page 7: Installation

    7700DA6-L SD-SDI Video Distribution Amplifier with Loop Thru INSTALLATION The 7700DA6-L comes with a companion rear plate that occupies one slot in the frame. For information on inserting the module into the frame see section 3 of the 7700FR chapter.

  • Page 8: Specifications

    7700 MultiFrame Manual 7700DA6-L SD-SDI Video Distribution Amplifier with Loop Thru SPECIFICATIONS 3.1. SERIAL VIDEO INPUT Standard: SMPTE 259M A, B, C, D, DVB-ASI, M2S, SMPTE 310M (19.4Mb/s jumper selected) Connector: BNC per IEC 61169-8 Annex A Equalization: Automatic to 250m @ 270Mb/s with Belden 8281 (or equivalent) Return Loss: >...

  • Page 9: Status Leds

    7700DA6-L SD-SDI Video Distribution Amplifier with Loop Thru STATUS LEDS The 7700DA6-L has seven LED Status indicators on the front card edge to show operational status of the card at a glance. Figure 5-1 shows the location of the LEDs.

  • Page 10: Jumpers And User Adjustments

    5.2. CONNECTING LOOP THRU The LOOP BNC connector is used to connect multiple 7700DA6-L modules to the same input video signal. This is accomplished by connecting the LOOP connector of the source module to the IN connector of the next module. This is repeated for the desired number of modules. The last module in the looped chain MUST HAVE the LOOP connector terminated with 75Ω.

  • Page 11: Selecting Whether The Module Will Be Controlled From The

    7700 MultiFrame Manual 7700DA6-L SD-SDI Video Distribution Amplifier with Loop Thru 5.3. SELECTING WHETHER THE MODULE WILL BE CONTROLLED FROM THE LOCAL CONTROLS OR THROUGH THE VISTALINK INTERFACE ® The CONTROL jumper J19 selects whether the module will be controlled from the local jumpers or through the VistaLINK interface.

  • Page 12: Vistalink ® Remote Monitoring/Control

    (GUI), third party or custom manager software may be used to monitor and control Evertz VistaLINK enabled products. ® 2. Managed devices (such as 7700DA6-L), each with a unique address (OID), communicate with the NMS through an SNMP Agent. Evertz VistaLINK enabled 7700 series modules reside in the 3RU ®...

  • Page 13: Vistalink ® Controlled Parameters

    7700 MultiFrame Manual 7700DA6-L SD-SDI Video Distribution Amplifier with Loop Thru 6.3. VISTALINK CONTROLLED PARAMETERS ® Parameter Description Video Standard Sets the current video standard that you wish to lock to. Sets the reclocker mode. If 'none', the reclocker is never Bypass Mode bypassed.
  • Page 14 7700 MultiFrame Manual 7700DA6-L SD-SDI Video Distribution Amplifier with Loop Thru This page left intentionally blank Page - 10 Revision 1.2...
