- Page 1 SP-1X2-HD4K 1×2 HDMI Splitter Operation Manual Operation Manual...
- Page 2 DISCLAIMERS The information in this manual has been carefully checked and is believed to be accurate. Cypress Technology assumes no responsibility for any infringements of patents or other rights of third parties which may result from its use. Cypress Technology assumes no responsibility for any inaccuracies that may be contained in this document.
- Page 3 SAFETY PRECAUTIONS Please read all instructions before attempting to unpack, install or operate this equipment and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: • Always follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons.
-
Page 4: Table Of Contents
CONTENTS 1. Introduction ..........1 2. Applications ........... 1 3. Package Contents ........ 1 4. System Requirements ......1 5. Features ..........2 6. Operation Controls and Functions ..3 6.1 Front Panel .........3 6.2 Rear Panel .........3 7. Connection Diagram ......4 8. -
Page 5: Introduction
1. INTRODUCTION This high performance 1 by 2 HDMI splitter distributes one HDMI input to two simultaneous HDMI outputs and supports 4K×2K, 3D, 12-bit Deep Color as well as High Definition Lossless Audio. With its 3Gbps bandwidth it supports the latest HDMI standards so you can be sure of superior HDMI distribution. -
Page 6: Features
5. FEATURES • HDMI and DVI compatible • Fully HDCP compliant • Supports 3D • Supports HDTV resolutions up to 4K×2K@30 Hz • Supports PC Resolutions of VGA to WUXGA • Supports 1080p@60 Hz, Deep Color 12-bit • Supports LPCM 7.1CH, Dolby TrueHD, and DTS-HD Master Audio •... -
Page 7: Operation Controls And Functions
6. OPERATION CONTROLS AND FUNCTIONS 6.1 Front Panel OUTPUT 1 OUTPUT 2 CPRO-2E 4KX2K 1X2 SPLITTER HDMI OUTPUTS 1/2: Connect each of the output ports to an HDMI display for simultaneous HDMI distribution. 6.2 Rear Panel POWER DC 5V INPUT SERVICE HDMI INPUT: Connect the input port to the HDMI or DVI output of your source equipment such as DVD player or set-top box. -
Page 8: Connection Diagram
7. CONNECTION DIAGRAM Blu-ray Player HDMI Input Power Supply POWER DC 5V INPUT SERVICE OUTPUT 1 OUTPUT 2 CPRO-2E 4KX2K 1X2 SPLITTER Simultaneous HDMI Outputs Projector HDTV... -
Page 9: Specifications
8. SPECIFICATIONS Video Bandwidth 300 MHz/9 Gbps Input Port 1×HDMI (Female connector), 1×USB (Manufacturer use only) Output Ports 2×HDMI (Female connector) Output Resolutions 480i~1080p@50/60, 1080p@24/50/60, VGA~UXGA, Ultra HD (4K×2K@30) ESD Protection Human body model: ±8 kV (air-gap discharge) ±4 kV (contact discharge) Dimensions 103 mm (W)×155 mm (D)×25 mm (H) Weight... - Page 10 PhD Solutions Product Warranty Should you feel your product does not function adequately due to defects in materials or workmanship, PhD Solutions (hereby referred to as “the warrantor”) will, for the length of the period indicated below: Repair the product with new or refurbished parts.
- Page 11 Return to Supplier When shipping the unit, carefully pack and send it prepaid (preferably in the original packaging) with a tracking number and adequate insurance. Please include a document or letter detailing the reason for return and include a daytime telephone number and/or email address where you can be contacted. If repair is required during the limited warranty period, the purchaser will be required to provide a sales receipt or other proof of purchase, indicating date and location of purchase as well as the price paid for the product.
- Page 12 Premium High Definition Solutions Home page: http://www.phdsolutions.co...
