- Page 1 SPC-3C1H-HDTL CHDBT-1H3CL 1 by 4 HDMI over HDMI & CAT5e/6/7 Splitter Operation Manual Operation Manual...
- Page 2 SAFETY PRECAUTIONS Please read all instructions before attempting to unpack, install or operate this equipment and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: • Always follow basic safety precautions to reduce the risk of fi re, electrical shock and injury to persons.
-
Page 3: Table Of Contents
CONTENTS 1. Introduction ..........1 2. Applications ........... 1 3. Package Contents ........ 1 4. System Requirements ......1 5. Features ..........2 6. Operation Controls and Functions ..3 6.1 Front Panel ........3 6.2 Rear Panel .........4 6.3 IR Cable Pin Assignment....5 7. -
Page 4: Introduction
1. INTRODUCTION The HDMI over HDMI and CAT5e/6/7 Splitter can split and distribute a single HDMI input and 2-way IR control to up to three CAT5e/6/7 outputs and includes a simultaneous HDMI bypass output. It supports resolutions up to 1080p Full HD, 4Kx2K timing, 3D and multi-channel digital audio formats. -
Page 5: Features
5. FEATURES • HDMI with 3D & 4Kx2K supported, HDCP and DVI compliant • Simultaneous HDMI and CAT5e/6/7 outputs • Supports data rate from 250Mbps up to 3Gbps • Supports wide range of PC resolutions from VGA to WUXGA(RB) and HDTV resolutions up to 4Kx2K (3840x2160@24/25/30Hz and 4096x2160@24Hz). -
Page 6: Operation Controls And Functions
6. OPERATION CONTROLS AND FUNCTIONS 6.1 Front Panel DC 24V SYNC LINK EDID SERVICE HDMI IN HDMI OUT POWER HDMI IN: Connect with source equipment such as DVD/Blu-ray or PS3 player. SYNC: This LED will illuminate when the HDMI input port connected to an active source. -
Page 7: Rear Panel
6.2 Rear Panel CAT5e / 6 / 7 OUT IR IN IR OUT MODE LINK MODE LINK MODE LINK IR IN: Connect with IR Extender to receive IR signal from Transmitter side and blast out at Receiver side. Ensure that remote controller being used is within the direct line-of-sight of the IR Extender. -
Page 8: Ir Cable Pin Assignment
6.3 IR Cable Pin Assignment IR Blaster Power 3.3 V IR Blaster Signal IR Extender IR Signal Power 3.3 V Grounding... -
Page 9: Connection Diagram
7. CONNECTION DIAGRAM 3D TV/Display Blu-ray or PS3 Player HDMI HDMI DC 24V SYNC LINK EDID SERVICE HDMI IN HDMI OUT POWER CAT5e / 6 / 7 OUT IR IN IR OUT 1.5m MODE LINK MODE LINK MODE LINK 60° IR BLASTER IR2 Blaster Power... -
Page 10: Specifications
8. SPECIFICATIONS Video Bandwidth 340Mbps/10.2Gbps Input ports 1 x HDMI, 1 x IR IN, 1 x USB (Service only) Output ports 1 x HDMI, 1 x IR OUT, 3 x CAT5e/6/7 Resolution Up to 4Kx2K (3840x2160@24/25/30Hz/4096x 2160@24Hz) HDMI Input & Output Up to 10m@1080p 8/12-bit Cable Distance CAT5e/6/7 Output... -
Page 11: Cat5E/6/7 Cable Specifi Cation
PhD Solutions Product Warranty Should you feel your product does not function adequately due to defects in materials or workmanship, PhD Solutions (hereby referred to as “the warrantor”) will, for the length of the period indicated below: Repair the product with new or refurbished parts. - Page 12 Return to Supplier When shipping the unit, carefully pack and send it prepaid (preferably in the original packaging) with a tracking number and adequate insurance. Please include a document or letter detailing the reason for return and include a daytime telephone number and/or email address where you can be contacted. If repair is required during the limited warranty period, the purchaser will be required to provide a sales receipt or other proof of purchase, indicating date and location of purchase as well as the price paid for the product.
- Page 13 Premium High Definition Solutions Home page: http://www.phdsolutions.co...
