SportDOG SD-1825CAMO Programming Manual

Remote transmitter
Hide thumbs
1
2
3
4

Advertisement

Quick Links

Download this manual

PROGRAM THE REMOTE TRANSMITTER

NOTE: The Transmitter is factory set to mode 1. The mode of the Remote Transmitter can be changed
to fit your type or style of training.
TO CHANGE THE MODE:
1. Referring to the following tables, adjust the Intensity
Dial and Toggle Switch to the mode you want to use.
2. Turn the Remote Transmitter over and remove the belt
clip (if attached).
3. Using a pen or the tine on the buckle of your collar
strap, depress and release the mode button. When
the mode button is pressed, the Transmitter Indicator
Light will be solid in color. When it is released, it will
flash the mode selected.
For example, if mode 5 is desired, adjust the Intensity Dial to Level 5. Once the mode button has been
depressed, the Transmitter Indicator Light will be solid, and once the mode button is released, the
Transmitter Indicator Light will flash 5 times. However, if you select mode 8 (ID Code) in the UP position
or mode 2 in the DOWN position, the light will remain solid in color once the mode button is released.
TOGGLE SWITCH IN
THE UP POSITION
TOGGLE SWITCH IN
THE DOWN POSITION

Advertisement

loading
Need help?

Need help?

Do you have a question about the SD-1825CAMO and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SportDOG SD-1825CAMO

Summary of Contents for SportDOG SD-1825CAMO

  • Page 1: Program The Remote Transmitter

    PROGRAM THE REMOTE TRANSMITTER NOTE: The Transmitter is factory set to mode 1. The mode of the Remote Transmitter can be changed to fit your type or style of training. TO CHANGE THE MODE: 1. Referring to the following tables, adjust the Intensity Dial and Toggle Switch to the mode you want to use.
  • Page 2 TOGGLE SWITCH IN THE UP POSITION MODE UPPER BUTTON LOWER BUTTON SIDE BUTTON TOGGLE NUMBER FUNCTION FUNCTION FUNCTION SWITCH OF DOGS (up/down) Continuous Momentary Tone only Dog 1 / stimulation (Level set stimulation (Level set Dog 2 by intensity dial) by intensity dial) Continuous Low Continuous...
  • Page 3 TO MANUALLY PROGRAM THE REMOTE TRANSMITTER’S ID CODE FOLLOW THESE STEPS: 1 . Turn the intensity dial to level 8, flip the toggle switch up, and then press and release the mode button on the back of your Remote Transmitter. This does not change the mode, so the current mode will still be active after the ID change is complete.
  • Page 4 TOGGLE SWITCH IN THE DOWN POSITION MODE UPPER BUTTON LOWER BUTTON SIDE BUTTON TOGGLE NUMBER FUNCTION FUNCTION FUNCTION SWITCH OF DOGS (up/down) Medium Continuous Low Continuous High Continuous Dog 1 / stimulation stimulation stimulation Dog 2 Continuous Low Continuous Programmable Dog 1 / stimulation (Level set stimulation (Level set...
