- Page 1 MIXING AMPLIFIERS MIXING AMPLIFIERS MA200 The MA200 is developed by Audioprof nv Lanteernhofstraat 90 BE-2100 Deurne BELGIUM OWNER’S MANUAL info@apart-audio.com www.apart-audio.com...
- Page 2 19” Brackets are shipped along with your amplifier. PHANTOM MUTE The MA200 is the all in one device to built larger professional industrial sound applications. You can insert an extra Hi-Q Pre Amp 1.5mV equalizer (such as the APart PXQ2215) into the signal path or add extra power amps (APart PA240P), using the pre...
-
Page 3: Technical Specifications
MIXING AMPLIFIERS MIXING AMPLIFIERS Technical Specifications Front panel Frequency response 40Hz 25kHz (+1/-3 dB) Distortion <0,3% @ -6dB, 1kHz Bass control +/- 10dB, 100 Hz Treble control +/- 10dB, 10 kHz amplifier: better than 95dB, 22Hz 22kHz line: better than 80dB, 22Hz 22kHz mic: better than 65dB, 22Hz 22kHz LED indicators... -
Page 4: Safety Information
6,3AT, slow blow fuse. Use a screw driver to flip out the fuse compartment and to replace it by the same type. When this fuse blows frequently, you should check the speaker load or bring the MA200 to a qualified service •... - Page 5 Please use a balanced, shielded line cable. Connect the HOT signal to +, the COLD to and the shield to G (when connecting the shield only at the MA200 side, you might avoid a ground loop, which creates hum and buzz).
- Page 6 Phantom on / off jumper The MA200 has been shipped with these jumpers in the OFF position. For each microphone input a jumper is available. When you put a jumper to the ON position, phantom power will be supplied to the microphone input involved so you can use condenser microphones.
