LENNOX HEARTH PRODUCTS
WARNING: IF THE INFORMATION IN THIS MANUAL
IS NOT FOLLOWED EXACTLY, A FIRE OR EXPLO-
SION MAY RESULT CAUSING PROPERTY DAM-
AGE, PERSONAL INJURY OR LOSS OF LIFE.
FOR YOUR SAFETY: Do not store or use gasoline
or other flammable vapors or liquids in the vicin-
ity of this or any other appliance.
FOR YOUR SAFETY: What to do if you smell gas:
• DO NOT light any appliance.
• DO NOT touch any electrical switches.
• DO NOT use any phone in your building.
• Immediately call your gas supplier from a
neighbor's phone.
Follow your gas suppliers instructions.
• If your gas supplier cannot be reached, call the
fire department.
Installation and service must be performed by a
qualified installer, service agency or the gas
supplier.
LSS-40 MODEL SHOWN
OTL Report No. 116-F-02-05
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
HOMEOWNER'S CARE AND
OPERATION INSTRUCTIONS
DIRECT VENT
SPECTRA SERIES
VENTED GAS FIREPLACE HEATERS - DIRECT VENT MODELS
P/N 875,020M REV. A 12/2002
MODELS
LSS-35CN
LSS-35CP
RETAIN THESE INSTRUCTIONS
FOR FUTURE REFERENCE
AVERTISSEMENT: ASSUREZ-VOUS DE BIEN SUIVRE
LES INSTRUCTIONS DONNÉ DANS CETTE NOTICE POUR
RÉDUIRE AU MINIMUM LE RISQUE D'INCENDIE OU
POUR ÉVITER TOUT DOMMAGE MATÉRIEL, TOUTE
BLESSURE OU LA MORT.
POUR VOTRE SÉCURITÉ: Ne pas entreposer ni utiliser
d'essence ni d'autre vapeurs ou liquides inflammables
dans le voisinage de cet appareil ou de tout autre
appareil.
POUR VOTRE SÉCURITÉ: Que faire si vous sentez une
odeur de gaz:
• Ne pas tenter d'allumer d'appareil.
• Ne touchez à aucun interrupteur. Ne pas vous servir
des téléphones se trouvant dans le batiment où
vous vous trouvez.
• Evacuez la piéce, le bâtiment ou la zone.
• Appelez immédiatement votre fournisseur de gaz
depuis un voisin. Suivez les instructions du
fournisseur.
• Si vous ne pouvez rejoindre le fournisseur de gaz,
appelez le service dos incendies.
L'installation et service doit être exécuté par un qualifié
installeur, agence de service ou le fournisseur de gaz.
LSS-40CN
LSS-40CP
1
Advertisement
Table of Contents
Related Manuals for Lennox Signature LSS-40CP
Summary of Contents for Lennox Signature LSS-40CP
-
Page 1: Operation Instructions
• Si vous ne pouvez rejoindre le fournisseur de gaz, appelez le service dos incendies. L'installation et service doit être exécuté par un qualifié installeur, agence de service ou le fournisseur de gaz. NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE. LSS-40CN LSS-40CP... -
Page 2: Table Of Contents
CONGRATULATIONS! In selecting this LENNOX Signature Series Direct-Vent Gas Appliance you have chosen the finest and most dependable fireplace to be found anywhere. A beautiful, prestigious, alternative to a wood burning fireplace. Welcome to a Family of tens of thousands of satisfied LENNOX Fireplace Owners. -
Page 3: Operation/Care Of Your Appliance
Maximum manifold pressure is 3.5 in. w.c. (0.87 kPa) for natural gas and 10 in. w.c. (2.49 kPa) for LP/Propane gas. Do not use these appliances if any part has been under water. Immediately call a qualified, profes- sional service technician to inspect the appliance and to replace any parts of the control system and any gas control which have been under water. -
Page 4: Transmitter Operation
Step 6. ON the initial use of a transmitter, a recognition operation is required between the receiver/valve and transmitter. Change the switch from LOCAL to REMOTE. Press the fan or flame button on the transmitter within 30 seconds. The LED will blink indicating the transmitter will now work with the receiver/valve. -
Page 5: Troubleshooting
To Change Batteries 1. Remove cover on the backside of the trans- mitter. Install 3 AAA batteries as shown inside the cover and reattach the cover. 2. Once steps 1 thru 3 in OPERATION are completed, receiver/valve and transmitter are now ready. -
Page 6: Glass Cleaning
Comfort Valve System Control Sequence Of Operation With Transmitter Figure 6 NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE. Glass Cleaning It will be necessary to clean the glass periodi- cally. During start-up it is normal for conden- sation to form on the inside of the glass. This can cause lint, dust and other airborne par- ticles to cling to the glass surface. -
Page 7: Maintenance Schedule
Maintenance Schedule Annually (Before the onset of the Burning Season) Maintenance Task Inspecting/Cleaning Burner, Logs and Controls Check Flame Patterns and Flame Height Inspecting/Cleaning Pilot and Burner Checking Vent System Appliance Checkout Replacing Rockwool Ember Materials Periodically (After the Burning Season) Maintenance Task Check Flame Patterns and Flame Height Checking Vent System... -
Page 8: Front Glass Enclosure Panel, Removal And Installation
Front Glass Enclosure Panel, Removal and Installation. WARNING: NEVER OPERATE THE AP- PLIANCE WITHOUT THE GLASS ENCLO- SURE PANEL IN PLACE AND SECURE. DO NOT OPERATE APPLIANCE WITH THE FRONT GLASS PANEL CRACKED, BRO- KEN OR MISSING. REPLACEMENT PAN- ELS ARE AVAILABLE THROUGH YOUR LOCAL LENNOX DEALER AND MUST BE INSTALLED BY A LICENSED OR QUALI- FIED SERVICE TECHNICIAN. -
Page 9: Adjustment
Adjustment CAUTION: THE AIR SHUTTER ADJUSTMENT ROD ( SEE FIGURE 8 ) AND NEARBY APPLI- ANCE SURFACES ARE HOT. EXERCISE CAU- TION TO AVOID INJURY WHILE ADJUSTING FLAME APPEARANCE. To adjust the flame, restate the air shutter adjustment rod toward the back or toward the front of the fireplace (rod located in the lower control area). -
Page 10: Log Placement
Log Placement WARNING: LOGS GET VERY HOT AND WILL REMAIN HOT UP TO ONE HOUR AFTER GAS SUPPLY IS TURNED OFF. HANDLE ONLY WHEN LOGS ARE COOL. TURN OFF ALL ELECTRICITY TO THE APPLIANCE BEFORE YOU INSTALL GRATE AND LOGS. WARNING: THE SIZE AND POSITION ON THE LOG SET WAS ENGINEERED TO GIVE YOUR APPLIANCE A SAFE, RELIABLE... -
Page 11: Rockwool Placement
Glowing Embers (Rockwool) Placement Refer to the detailed glowing embers place- ment instructions provided in the LOG PLACE- MENT GUIDE accompanying this document. Honeywell RF Control Millivolt Appliance Pilot Checkout Pilot Inspection To obtain proper operation, it is imperative that the pilot and burner's flame characteristics are steady, not lifting or floating ( see Figure 11 ). -
Page 12: Accessory Components
ACCESSORY COMPONENTS Cast Iron Kits These cast iron face kits are designed to be used in conjunction with the grillwork kits. Together, when installed, these kits complete the front aspect of the Spectra LSS Series gas fireplaces. A detailed set of instructions (P/N 750,150M) is included with each kit. l i r Grillwork Kits (Top &... - Page 13 ACCESSORY COMPONENTS CONTINUED Rectangular Face Kits These rectangular face kits are designed to be used with the Spectra LSS series gas fireplace. When installed, these kits complete the front aspect of these fireplaces. A detailed set of instructions (P/N 750,152M) is included with each kit. Arched Face Kits These arched face kits are designed to be used with the Spectra LSS series gas fireplace.
-
Page 14: Replacement Parts List
c i f c i f i f i i f i t o l REPLACEMENT PARTS LIST , e r t e l t e l t f e e l f i t n GAS CONTROLS NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE. - Page 15 REPLACEMENT PARTS LSS35 LSS40 Gas Train Assembly - Bottom View NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
- Page 16 LENNOX reserves the right to make changes at any time, without notice, in design, materials, specifications, prices and also to discontinue colors, styles and products. Consult your local distributor for fireplace code information. Printed in U.S.A. © 2002 by LENNOX P/N 875,020M REV.
