Connecting Headphones
EN
Connecting Headphones
The GPZ 7000 does not have a built in
speaker. There are three ways you can listen
to audio:
1. Headphones connected to the detector
2. The WM 12 speaker
3. Headphones connected to the WM 12
Detector Audio
To connect headphones directly to the
detector, plug the headphone plug into the
socket on the headphone module at the rear
of the detector.
If using waterproof accessory headphones,
you will need to remove the headphone
module from the control box and connect
the headphones to the exposed headphone
socket, remembering to tighten the retaining
rings.
NOTE
The GPZ 7000 is not waterproof
WM 12 Audio
NOTE
If you are using the WM 12 to listen to
audio, attach the WM 12 to the same
side of your body as the detector,
using the supplied belt clip. This will ensure the
most reliable wireless signal.
To listen to audio via the WM 12, insert the
headphone plug into the WM 12 headphone
socket.
The WM 12 must be wirelessly linked with
the detector using a wireless connection
process to hear audio.
See 'Connecting the WM 12' for WM 12
connection instructions, or refer to your user
manual on CD for more detailed information.
NOTE
The WM 12 can be used without
headphones, as it has a built-in
speaker.
8
WM 12 Connection and Charging
WM 12 Connection and
Charging
Ensure that your WM 12 battery is fully
charged before you go detecting.
Connecting WM 12
It is only necessary to perform the wireless
connection procedure once. After initial
connection, the detector and WM 12 will
connect automatically when the WM 12 is
turned on.
To connect the WM 12 to your detector,
navigate to 'Connect WM 12' in the Settings
menu and select it to start the guide
sequence.
The Connect
WM 12
Function
During the guide sequence, a random
available channel will be displayed. To change
the channel, press the left or right Arrow
buttons. Press Select to confirm the channel.
Use the Wireless function on the Settings
page to enable or disable wireless. Disabling
wireless when you are not using the WM 12
is recommended to conserve detector
battery life.
The Wireless
Function
NOTE
The WM 12 Connection LED may
flash red occasionally when the
WM 12 appears to be working
correctly. This indicates a deterioration in radio
communications and is for information only.
Charging WM 12 Battery
The WM 12 contains a rechargeable Li-Ion
battery, which can be charged by the Li-Ion
battery charger or a standard USB port.
1. Connect the supplied USB cable to the
WM 12.
2. Connect the other end of the USB cable
to the BC 10 battery charger or directly to
a USB port on your PC.
9
EN
