Dromida Kodo dide 0005 Quick Start Manual

Advertisement

Quick Links

Rotor Blade Guards
Spare Blades
(2 black, 2 white)

CHARGING

Plug charger into USB port or AC adapter (not included) as shown and connect the battery.
The red LED will flash slowly while the battery is
charging. The LED will be steady when the
battery is fully charged.

RADIO

Rudder
Mode 1/ Mode 2
Trim
Button
Switch
Throttle/Rudder
Throttle
ON/OFF Elevator
Stick
Trim
NOTE: For Mode 1 configuration, refer to the complete KODO instruction manual at dromida.com

PREPARING TO FLY

1. Turn on the radio with throttle at lowest position.
2. Place the Kodo on a level surface and connect
the battery. The Kodo will beep twice. Do not
move the Kodo until the LEDs stop flashing.
1
AAA Batteries (2)
KODO Quadcopter
• NEVER leave the battery unattended while charging.
• DO NOT allow the USB port to power down while the charger is connected to the battery.
• ALWAYS unplug the charger from the USB port and the battery when charging is complete.
Video
Aileron
Button
Trim
LED
Aileron/Elevator
Trim
Stick
2
Radio Controlled Quadcopter
Flight Battery
USB Card
Reader
2G Memory Card
Before taking first flight, download complete KODO
instruction manual from www.dromida.com.

SENSITIVITY ADJUSTMENT

Push down on the left stick to change
the sensitivity of the controls.
Lowest (Default)
x2
2
Moderate
x3
3
Maximum
3. Move the throttle up and listen for one beep.
4. Move the throttle down. Listen for one beep and
verify that the LEDs have stopped flashing.
3
The motors are armed and the KODO is ready to fly.
Radio
USB Charge Cord
4
