Dromida Kodo DIDE0005 User Manual

Rotor Blade Guards
Spare Blades
(2 black, 2 white)
RADIO
For Mode 2 operation, slide the mode
switch to the MD2 position and hold the
controller with the throttle on the left side.
CHARGING THE FLIGHT BATTERY
Plug the charger into a USB to AC adapter
or USB port on a computer as shown
and connect the battery. The red LED
will flash slowly while charging and be
steady when the charge is complete.
• NEVER leave the battery unattended while
charging.
• DO NOT allow the USB port to power down
while the charger is connected to the battery.
• ALWAYS unplug the charger from the USB port
and the battery when charging is complete.
RADIO SETUP
Remove the screw on the battery compartment cover. Take the cover off and insert 2 AAA batteries.
AAA Batteries (2)
KODO Quadcopter
™
Radio Controlled Quadcopter
Flight Battery
USB Card
Reader
2G Memory Card
For Mode 1 operation, slide the mode
switch to the MD1 position and hold the
controller with the throttle on the right side.
Radio
USB Charge Cord
