Summary of Contents for Alfresco VERSAPOWER
- Page 2 VERSAPOWER™ SERIAL NUMBER LABEL: NOTES:...
-
Page 3: General Safety Precautions
ALFRESCO™ Gourmet Grills A division of Superior Equipment Solutions, Inc. 7039 East Slauson Avenue Commerce, CA. 90040 3020914 Ph.: (888) 383-8800 Fax: (323) 726-4700 Web: www.alfrescogrills.com GENERAL SAFETY PRECAUTIONS: WARNING WARNING ELECTRICAL PARTS FLAMMABLE GAS AND COMPONENTS DISCONNECT ALL PROPANE... - Page 4 GRILL TO REDUCE THE RISK OF FIRE, BURN HAZARD OR OTHER INJURY. KEEP THIS MANU- AL FOR FUTURE REFERENCE. When properly cared for, your ALFRESCO™ VERSAPOWER™ Cooking System will give safe, reliable service for many years. However, extreme care must be used since the unit produces intense heat, which can increase accident potential.
- Page 5 (Safety, cont.) When lighting a burner, always pay close attention to what you are doing. Be certain you are de- pressing the igniter button for the burner you intend on using. When using the unit: do not touch the unit’s burner grated or immediate surrounding area as these ...
-
Page 6: Battery Installation
3. Reinstall cap into the module, tightening the cap completely. 4. Re-install the grease tray and close it completely by pushing forward until it stops. NOTE: The VERSAPOWER™ Cooking System has only one igniter module in the center of the unit that operates both burners. (see figure # 1). - Page 7 Igniter Cap Figure # 1 GAS CONNECTION—LIQUID PROPANE (LP) NEVER CONNECT THE VERSAPOWER™ COOKING SYSTEM TO AN UNREGULATED GAS SUPPLY. Before proceeding, ensure the unit is fitted for LP gas. Connecting to an improper gas type will result in poor performance and increased risk of damage or injury. Total gas consumption (per hour) with all burners set on “HI”...
- Page 8 20 Lb. LP cylinder. The LP gas pressure regulator and hose sup- plied with this unit must be used without alteration. If this assembly needs to be replaced use only the type specified by ALFRESCO™ for this appliance. The VERSAPOWER™ Cooking System requires a 90,000 BTU minimum regulator / hose assembly.
-
Page 9: Natural Gas Connection
Use a minimum 1/2” ID flex hose to prevent gas starvation. NATURAL GAS CONNECTION: Ensure that the service pipe supplying the VERSAPOWER™ Cooking System is fitted with a shut off valve conveniently positioned and easily accessible as an emergency gas shutoff. -
Page 10: Leak Testing
LEAK TESTING: GENERAL: Although all gas connections on your ALFRESCO™ VERSAPOWER™ Cooking System are leak tested at the factory prior to shipment, a complete gas tightness check must be performed at the installation site due to possible mishandling in shipment, or excessive pressure unknowingly being applied to the unit. - Page 11 Do not use the unit until all connections have been checked and do not leak. Only those parts recommended by the manufacturer should be used on the unit. Substitution can void the VERSAPOWER™ Cooking System warranty. IMPORTANT NOTE: ALWAYS CHECK FOR LEAKS AFTER EVERY LP TANK CHANGE.
-
Page 12: Burner Adjustments
30” grills require one battery, all others require two. See page 6 for battery replacement instructions. BURNER ADJUSTMENTS: NOTE: VERSAPOWER™ Cooking System has two burners, a center and a perimeter one. The follow- ing instructions apply to the perimeter burners. PERIMETER BURNER AIR ADJUSTMENT: Each unit’s burners are tested and adjusted at the factory prior to shipment;... -
Page 13: Adjustment Steps
AIR SHUTTER ADJUSTMENT: A sheet metal cup at the inlet of the perimeter burner called the “AIR SHUTTER” regulates the amount of air that enters into the burner for combustion. The air shutter is locked in place by a set-screw, which must be loosened prior to lighting the burner for adjustment. -
Page 14: Stainless Steel Care
However, some care is required to ensure that the stainless steel can live up to this reputation. DAY TO DAY CARE: To maintain the original appearance of your ALFRESCO™ VERSAPOWER™ Cooking System, a regu- lar cleaning routine should be carried out using the following guidelines: 1. -
Page 15: Stainless Steel
If the grate is allowed to cool before cleaning, then cleaning will be harder. STAINLESS STEEL: The VERSAPOWER™ Cooking System is made from commercial quality type 304 non-rusting and non- magnetic stainless steel, and the cleaning information shown on Page 14 should be followed. -
Page 16: Troubleshooting
This is especially applicable in ocean front locations, or locations subject to sea mists. ALFRESCO™ strongly recommends that you cover your unit when not in use. - Page 17 (Troubleshooting, cont.) 1. The smell of gas in conjunction with the burner flames appearing yellow. 2. The unit does not reach temperature. 3. The burners make popping noises. UNIT WON’T LIGHT: First determine if the spark igniters are functioning properly. You should hear a rapid snapping sound when the igniter button is depressed.
-
Page 18: How To Obtain Service
HOW TO OBTAIN SERVICE For service, please contact our Alfresco™ Gourmet Grills authorized service agency at: (866) 203-5607 Please provide: Model Number Serial Number (located under the drip pan) Gas Type Date of installation A brief description of the problem. -
Page 19: Duration Of Warranty
This warranty covers the following: ALFRESCO™ GOURMET GRILLS (All Models) DURATION OF WARRANTY Alfresco Gourmet Grills, (a division of SES, Inc.) warrants all grill components to the original purchaser to be free of factory defects in material and workmanship for a period of two (2) years from the original date of purchase.
