- Page 2 ALF-PZA SERIAL NUMBER LABEL: NOTES:...
-
Page 3: General Safety Precautions
ALFRESCO™ Gourmet Grills A division of Superior Equipment Solutions, Inc. 7039 East Slauson Avenue Commerce, CA. 90040 3020914 Ph.: (888) 383-8800 Fax: (323) 726-4700 Web: www.alfrescogrills.com GENERAL SAFETY PRECAUTIONS: WARNING WARNING ELECTRICAL PARTS FLAMMABLE GAS DISCONNECT ALL PROPANE AND COMPONENTS... - Page 4 READ THIS CARE AND USE MANUAL CAREFULLY AND COMPLETELY BEFORE USING YOUR PIZZA OVEN TO REDUCE THE RISK OF FIRE, BURN HAZARD OR OTHER INJURY. KEEP THIS MANUAL FOR FUTURE REFERENCE. Alfresco When properly cared for, your ™ Pizza Oven will give safe, reliable service for many years.
- Page 5 (Safety, cont.) When lighting a burner, always pay close attention to what you are doing. Be certain you are de- pressing the correct igniter button labeled for the burner you intend on using. When using the oven: do not touch the oven hearth stone, opening archway, doors or door frame surrounding areas with your bare hands as these areas become extremely hot and could cause burns.
- Page 6 LOCATING AND ASSEMBLING THE PIZZA OVEN: Alfresco When determining a suitable location for your ™ Pizza Oven, take into account concerns such as exposure to wind, rain, sprinklers, proximity to traffic paths and keeping any gas supply line runs as short as possible.
-
Page 7: Important Electrical Instructions
WARNING: To prevent harm and ensure proper operation of your oven, it is imperative that the IR burner is properly installed with respect to the gas orifices. Be certain that the orifice is inserted completely into the burner’s inlet and that the burner rests firmly on its support. The burner should not rock side-to-side nor top-to-bottom if properly installed. - Page 8 ASSEMBLY Figure # 1 Figure # 1 RIGHT DOOR ASSEMBLY Alfresco After unpacking the ™ Pizza Oven and before using for the first time, several items need to be properly installed for the oven to operate correctly. The Hearth Stones as well as the Top Stone must be located in the unit along with the Ceramic Log and it’s support tray.
- Page 9 Once the Hearth Stones are installed inside the oven, the Log Support Tray can be inserted into the slots that can be found at the bottom of the oven cavity back wall. (See figure # 2). TOP STONE The Log Support Tray can now rest on top of the Hearth Stones covering the Log Burner.
- Page 10 QCC1 in the standard for compressed gas cylinder valve outlet and inlet connections ANSI/CGA-V-I. LP GAS CONNECTION TO LP TANKS: Alfresco Your ™ Pizza Oven for use with LP gas comes equipped with its own regulator, which MUST NOT be removed.
- Page 11 LP tank and low pressure regulators close to the home. REGULATOR NOTICE WARNING Exposure to pressures above the safety limit YOUR ALFRESCO™ PIZZA OVEN’S PRESSURE of 69” WC. will permanently damage the gas REGULATOR HAS A MAXIMUM INPUT PRESSURE regulator requiring a replacement. OVER OF 14”...
- Page 12 Ensure that the service pipe supplying the oven is fitted with a shut off valve conveniently positioned and easily accessible as an emergency gas shutoff. Alfresco Your ™ Pizza Oven for use with Natural Gas comes equipped with its own regulator which MUST NOT be removed.
-
Page 13: Built-In Installations
Alfresco Your ™ Pizza oven can be converted to a built-in pizza oven by installing the ALF-PZA-BIA kit onto the unit. Built -in units require the use of non combustible masonry materials for safety. The Built-in conversion Kit consists of 3 items:... - Page 14 Figure # 8 to have the proper combustion. Dimensions shown on Figure # 9 below are shown as reference to aid in the design and planning only. ALF-PZA-BIA Kit Figure # 9...
-
Page 15: Leak Testing
LEAK TESTING: GENERAL: Alfresco Although all gas connections on your ™ Pizza Oven are leak tested at the factory prior to shipment, a complete gas tightness check must be performed at the installation site due to possible mis- handling in shipment, or excessive pressure unknowingly being applied to the unit. -
Page 16: Lighting Instructions
LIGHTING INSTRUCTIONS: BEFORE LIGHTING LP SYSTEMS... Alfresco The pressure regulator (Type QCC1) and hose assembly supplied with the ™ Pizza Oven must be used. Never substitute regulators for those supplied with the oven. If a replacement is necessary, contact the factory for proper replacement. - Page 17 It should not be left on HI setting for long times as it will make the oven very hot beyond usable cooking temperatures. BURNER AND PILOT ADJUSTMENTS: Alfresco NOTE: The ™ Pizza Oven Burners do not require air-mix adjustment and need only be checked visually for proper performance and low temperature settings only.
- Page 18 PILOT ADJUSTMENT: Begin by lighting up the Pilot according the procedure explained on Page 16: Push and turn the gas control knob to the PILOT position. Push the ignition (spark) button. 1” ~ 1½” FLAME Push the Gas Control Knob The Pilot should lit instantly.
- Page 19 1-1/2” ~ 2” MAXIMUM LOG BURNER LOW FLAME SIZE FLAME SETTING Figure # 13 Once proper adjustment is reached, reattach the knob by pushing onto the stem. LOW HEAT SETTING ADJUSTMENT (HEARTH STONE IR-BURNER): NOTE: THE LOW HEAT SETTING ON YOUR OVEN IS PRESET AT THE FACTORY. ADJUST ONLY IF AL- TITUDE OR ENVIRONMENTAL FACTORS ARE CAUSING POOR, LOW HEAT, PERFORMANCE.
- Page 20 CERAMIC PANEL WILL RESULT. WATER DAMAGE IS NOT COVERED BY DO NOT adjust the LOW setting without the burner YOUR ALFRESCO WARRANTY screen, as it is designed to hold the flame steady and in place specially when operating at LOW temperature.
-
Page 21: Cooking With Your Pizza Oven
COOKING WITH YOUR PIZZA OVEN: Alfresco Your ™ Pizza Oven has been designed to provide very fast heat-up times as well as a broad rage of operating temperatures for cooking different foods. In principle, the oven’s heat sources function as follows: (See Figure # 15) The IR Burner directly heats the Hearth Stones and this heat makes its way into the oven cavity through the Ceramic Log area. -
Page 22: Stainless Steel Care
However, some care is required to ensure that the stainless steel can live up to this reputation. DAY TO DAY CARE: Alfresco To maintain the original appearance of your ™ Pizza Oven , a regular cleaning routine should be carried out using the following guidelines: 1. - Page 23 PITTING: Another form of corrosion, which occasionally occurs in stainless steel, is pitting of the surface. The reason for this corrosive attack can usually be attributed to certain household products, for example: Bleaches: Most common domestic bleaches & sterilizing solutions contain chlorine in the form of sodium hypochlorite.
-
Page 24: Troubleshooting
This is especially applicable in ocean front locations, or locations subject to sea mists. ALFRESCO™ Gourmet Grills strongly recommends that you cover your Oven when not in use. TROUBLESHOOTING:... - Page 25 OVEN WON’T LIGHT: First determine if the spark igniters are functioning properly. A rapid snapping sound should be heard when the igniter button is depressed. If no sound is heard, check power supply. Is the power cord connected? Has the GFCI tripped? If power supply is okay, then ensure that the proper gap exists between the Pilot Head and the electrode wire, according to the procedure on page 23.
-
Page 26: Light Cover
™ Pizza Oven: G940120 - G9 Base 40 W - 120 VAC Part # 210-0317 Should you need to replace the light bulbs in your Alfresco™ Gourmet Grill, please refer to the following steps : LIGHT COVER Figure # 16... - Page 27 Replace the light cover by inserting it into the light fixture at a slight angle until it “SNAPS” into place. Alfresco Power up your ™ Pizza Oven and verify the light bulb operation by turning on the light switch.
- Page 28 (cont.) Also, do not allow any food particles or grease to be left inside your barbecue, as this will attract rodents which, in addition to being undesirable from an hygienic standpoint, are likely to cause physical damage to your oven. Rodents are known to chew on the insulation of wiring which will eventually cause permanent damage to the wiring and possibly electrical components.
-
Page 29: How To Obtain Service
IN THIS AREA ONLY ALL OTHER AREAS CALL (866) 203-5607 INQUIRIES AND INFORMATION: For all other Alfresco™ Gourmet Grill information such as power, installation, cut-out requirements, or any other product inquiries, please contact: Alfresco Gourmet Grills. (888) 383-8800 or (323) 722-7900 Customer Service Department. - Page 30 Limitations & Exclusions: 1. Alfresco’s warranty applies only to the original purchaser and may not be transferred. 2. Alfresco’s warranty is in lieu of all other warranties, expressed or implied and all other obligations or liabilities related to the sale or use of its grill products. 3. Alfresco’s warranty shall not apply and Alfresco is not responsible for damage resulting from misuse, abuse, alteration of or tampering with the appliance, accident, hostile environment, flare-up fires, improper installation, or installation not in accordance with the instructions contained in the User Manual, or the local codes.
- Page 31 NOTES:...
