Page 1
A850 Vari-Focal HD Security Camera For use with Swann 4400 Series HD DVRs INSTRUCTION MANUAL...
Page 2
Introduction Congratulations on your purchase of this A850 limit the use of cameras and to comply with the Vari-Focal HD Security Camera. A highly versa- applicable laws and regulations. Important safety instructions tile surveillance camera with manually adjust- able zoom and focus to suit any environment.
Page 3
Choosing a location for your Camera With a vari-focal camera, you have some flexibility on Even though the camera is weather and water- where the camera can be mounted. Some things to resistant, prolonged exposure to adverse weather consider when choosing a location - conditions such as sunlight or excessive moisture, What you want to monitor and where you’ll get the may eventually damage the internal components of...
Connecting your Camera Video & Power Cable Connect the video output and power input connection on the camera to the corresponding connections on the video & power cable. Connect the video connection on the Connect power other end of the video & power cable adapter to the power input to one of the video inputs on the DVR.
Mounting your Camera The camera has three points of articulation. The most obvious is the hex screw secured elbow joint in the centre of the stand (2). This one is pretty obvious and straight forward – using an Allen key, loosen the hex screw and adjust to the position you want (up or down).
Swann. The exclusions in this warranty. Where applicable by end user is responsible for all freight charges in- local laws, regulations and legal rights will take curred to send the product to Swann’s repair cen-...
FCC Verification This equipment has been tested and found to comply with the limits for Class B digital device, pursu- ant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:...
