IN STR U CT IO N MAN U AL
®
M E T REA U
KEY P AD S
ME T- 6N 6- BUTTON K EYP AD WI TH N AVIGATI ON
ME T- 7 & MET-1 3 KE YPADS
ME T- 6NE 6-BUTTON ETHE RN ET KE YPAD WITH NA VIGATION
ME T- 7E & ME T- 13E ETHE RN ET KE YPADS
ME T- 7X & ME T- 13X ETHE RN ET EX PAN SION KEYP ADS
DA S- ME T6SRC 6- SOURCE AUDI O KE YPAD
DA S- ME T- NUM NUMERI C AUDI O KE YP AD
