JUKI MEB-3200 Safety Notes

Be sure to read these instructions
MEB-3200
Precautions to protect against accidents
resulting in personal injury or death
The gas spring which is a safety device to help reduce the sewing machine weight can lose its function by inappropriate
maintenance work, etc.
In the case the gas spring does not function properly, the raised machine can drop by carrying out threading of the machine with
looper thread, or adding of oil to the oil tank, inviting a risk of accidents resulting in personal injury or death.
To protect against such accidents, be sure to read this "Precautions to protect against accidents resulting in personal injury or
death" carefully. In addition, be sure to stop using the sewing machine if the gas spring does not function properly and replace
the gas spring with a new one immediately.
Explanation of the pictorial indications
Represents the action that is
"prohibited"
DANGER
:
Never carry out operations described below. If you do any of the following operations, human
body including hands, fingers or arms can be caught in the machine, resulting in serious injuries such
as finger severing in the worst case.
Never lift up the sewing machine
too heavy for you.
In this state, the gas spring has outgassed
resulting in functional decline. Replace the gas
spring with a new one immediately.
Never raise/lower
more workers.
If raising/lowering the sewing machine by two or
more workers, the risk that the workers' bodies
such as a hand, finger or arm are caught in the
machine will increase. If the sewing machine is too
heavy for one worker to carry out the work alone,
the gas spring should be replaced with a new one
to restore the gas spring to the normal state.
alone if it is
by two or
the sewing machine
Represents the "instruction" that has to
be carried out without exceptions
Do not support the sewing machine by hand
without having locked the hinge stopper.
Be sure to lift up the sewing machine until the
hinge stopper is locked at the threading
position to secure the sewing machine.
Locking direction
Threading
position
Never hold the side face of the bed
raising/lowering the sewing machine.
Be sure to
hold the
near side
rib at the
periphery
of the bed.
No.00
40098365
Hinge stopper in
unlocked state
Hinge
stopper
when
Rib at the
periphery of
the bed
