Page 1: Operating Instructions
Operating Instructions TM1-TS WiFi 01/13 Revision 1.1 Ref: TM1-TSWIFI... -
Page 3: Table Of Contents
Contents Page Setting Up Your WiFi Timeclock Display Symbols Explained Understanding the Modes Selecting the Mode 5/2 Day / 7 Day Programming 12-13 Switching Time Override Countdown Timeclock Programming Locking the Keypad Holiday Clean Screen Factory Reset Optional Feature Setup 17-18 Wiring Diagrams... -
Page 4: Setting Up Your Wifi Timeclock
Setting up your WiFi Timeclock Step 1: Download and install the network utility from our web site: www.heatmiser.co.uk/wifi Step 2: Connect the timeclock to your pc with the USB cable provided, this will power the timeclock from the USB port & will allow you to test the Wi-Fi connection. - Page 5 Your Wi-Fi timeclock needs a fixed IP address in order for local and remote access to operate, so you will need to set this up manually. Log into your wireless router and navigate to the LAN settings page. You should see an option for DHCP setup. This should detail the IP range that can be assigned to devices connecting to the network.
- Page 6 Step 6: You need to enter the IP address of your gateway and DNS. In most cases, this is the IP address of your wireless router. If you are using the Multi-Link on the system, the gateway of the timeclock will need to be the IP address of the Multi-Link.
- Page 7 Security Types & Compatability Explained The Wi-Fi Timeclock operates on the 802.11b standard. If your router is a G model, you should ensure it is setup to work in B&G mode otherwise you will not be able to connect to your timeclock. There are currently 4 methods of securing your wireless connection in common use These are :...
- Page 8 10 or 26 digit hex password and won’t accept anything else. Your timeclock utility can deal with both options. The following restrictions apply: A hex password can only be made up of the numbers 0 to 9 and the letters a to f, lower case only. Hex passwords can only be 10 characters or 26 characters in length.
- Page 9 As a brief outline, you should first create a new service within your router, specifying the port number and the IP address to forward to, the port numbers needed are explained below. Remote access via smartphone/tablet To access your WiFi timeclock remotely via smartphone or tablet, you need to forward port 8068 to the IP address of your WiFi timeclock.
- Page 10 Connecting to the Timeclck from your Web Browser To connect to your timeclock, open your preferred browser and enter the IP address that you gave the timeclock during setup and press enter. You will now be asked for a password and username, these are both “admin”...
- Page 11 Connecting to the Timeclock from your Smartphone or Tablet application To connect to your timeclock, launch the app on your smart- phone or tablet, there are now three sections to fill in. Lan IP – This is the static IP address you have assigned to the WiFi timeclock.
-
Page 12: Display Symbols Explained
Wi-Fi Display Guide V1.0 Shown on the PRT-ETS WiFi Model. Displayed when the floor temperature rises above the floor limit temperature. Indicates the current room temperature. Indicates the current floor temperature (PRT-ETS WiFi Only). Indicates the thermostat is in Away Mode. Indicates the thermostat has successfully connected to the Wi-Fi Router. -
Page 13: Understanding The Modes
Understanding the Modes The TM1-TS WiFi has three modes of operation. • 5/2 Day Time-clock (Provides 4 On/Off switching times for the weekday and 4 On/Off switching times for the weekend) • 7 Day Time-clock (Provides 4 On/Off switching times for each day of the week) •... -
Page 14: 5/2 Day / 7 Day Programming
Setting The Clock To set the clock, follow these steps: • Press Prog • Press Clock • Enter the Time (In 24hr Format) • Press Clock • Enter the day and month • Press Clock • Enter the Year • Press Done The clock can also be set via the Browser or app. -
Page 15: Switching Time Override
TM1-TS WiFi will highlight Tuesday. • When complete, press Done to Store and Exit. Switching Time Override The TM1-TS WiFi has an override function allowing you to override the output into the opposite state. • Press Hold. • If the output is already On – press Off. -
Page 16: Countdown Timeclock Programming
You will then see the output status change and the output indication will flash to show it has been overridden from the programmed setting. The output will remain in the override state until the next programmed time. To cancel, repeat the steps above. -
Page 17: Locking The Keypad
Locking the Keypad The TM1-TS WiFi has a keylock facility. To enable this press the bottom right corner of the display and hold for 10 seconds. When activated, you will see To cancel, repeat the steps above. Holiday (5/2 Day / 7 Day Programmable Mode Only) The Holiday function turns the output off for the number of days programmed. -
Page 18: Clean Screen
Clean Screen Pressing Clean Screen will disable all buttons, allowing you 15 seconds to wipe the screen clean. Factory Reset The timeclock has a factory reset function. This will reset all settings back to their factory default. To perform a factory reset, follow these steps: Turn off the timeclock by pressing and holding the off button. -
Page 19: Optional Feature Setup
THE FOLLOWING SETTINGS ARE OPTIONAL AND IN MOST CASES NEED NOT BE ADJUSTED Optional Features Explained Feature 06 - Not used on this model. Feature 12 – Mode Select: This function allows you to select between 5/2 Mode, 7 Day mode or Countdown timer. Adjusting the Optional Settings To adjust the settings, follow these steps: •... - Page 20 Feature Table Feature Description Setting Comms # Not used on this model Mode Select 00 = 5/2 Day 01 = 7 Day 02 = Countdown...
-
Page 21: Wiring Diagrams
Heatmiser TM1-TS WiFi Model WI-FI TIMECLOCK TIMED SWITCHED LIVE OUTPUT MAINS SUPPLY TIMER RECOMENDATIONS WIFI TM1 Name MAX CABLE SIZE 1.5mm Wi-Fi TM1 20/09/2011 MAX LOAD 3 AMP Date BACK BOX DEPTH 35MM Drawn by Alan Mee...
