PARTS LIST

TMFE5, Electric Fryers
MODEL
IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED
INCLUDE MODEL AND SERIAL NUMBER
Some items are included for illustrative purposes only and in certain instances may not be available.
Fig No Part No
1 2R-Y5092
2 2M-Z13007
3 2E-Y5166
4 2D-301007
5 E3-Y7254
6 2C-2555
7 E3-Y5940
8 E3-301043
9 2C-H1578
10 E3-9280
11 2N-Z2920
12 E3-9288
13 2R-Z13078
14 E1-Z1390
15 E3-Y7359
16 2R-9572
17 E3-301060-PS
18 2P-9274
19 2A-Y1105
20 2T-Z7268
21 E1-7363
22 E3-301059
23 2T-Z3209
24 2K-Y6764
25 E3-301044
26 E3-9262
27 E3-Y1621
28 E3-9270
29 E3-9269
30 E3-7674
31 2I-9277
32 E3-9276
33 2P-Y3453
34 2P-5737
35 2B-301042
36 2B-301041
37 E3-301046
38 2M-Z7219
39 2M-Z8942
NI 2M-Z8943
Qty Description
4 BLACK PLASTIC LEG
1 FACEPLATE TMFE15
1 CIRCUIT BREAKER
1 KETTLE ASSEMBLY
1 PANEL-BACK
8 NUT-ACORN
2 LOWER ELEMENT CLAMP
1 HANDLE-CLAMP ASSEMBLY
8 SCREW-8-32X1
1 CLAMP-ELEMENT
1 ELEMENT 5500 WATT
2 BUSHING-SPLIT
1 KNOB-THERM
1 SWITCH GUARD
1 BRACKET-THERMO
1 KNOB-HARRY DAVIE
1 RELEASE ROD/PAWL KIT
1 SPRING-RELEASE
2 PIN ROLL
1 THERMOSTAT
4 CLAMP-THERMOSTAT
1 PILOT-LIGHT ASSEMBLY
1 THERMOSTAT-SAFETY
1 BUSHING-STRAIN
1 CORD-ASSEMBLY NEMA 6-30P
1 BACK-ELEMENT HOUSING
1 CLIP-GROUND
3 PLATE-ELEMENT SUPPORT
4 BEARING, PIVOT
2 ANGLE-CAPILLARY
1 GASKET
1 ARM-PAWL
4 WIRE-SPACER
6 CLIP-CAPILLARY
1 BASKET, RIGHT
1 BASKET, LEFT
1 BOTTOM ASSEMBLY
1 SIGN-STICKER
1 LABEL-FRYER BURN WARNING
1 WALL SIGN-FRYER WARNINGS
is a registerd trademark of Toastmaster, A Middleby Company. All rights reserved.
9
May 7, 200, Rev. A
