Page 2
Bäste kund, Tack för att ni valt Pullman-Ermator som leverantör. Vi önskar er lycka till med er nya våtsugare W250P/W350P och hoppas att den motsvarar era förväntningar. Vi tillverkar produkter sedan 1966 för professionell stofthantering och har genom åren erhållit en gedigen kompetens inom området.
Page 3
Uppackning Var noga med att kontrollera att allt finns med vid uppackning av maskinen. Förpackningen skall, förutom själva maskinen, innehålla följande: Sugslang. • Handrör. • Golvmunstycke. • Fogmunstycke. • Fattas något av dessa skall ni genast ta kontakt med återförsäljaren. Säkerhetsföreskrifter Handhavande Varning...
Funktion Med startvredet startas motorn. Därvid sugs stoftblandad luft med stor hastighet, via sugslang, genom inloppet. I kärlet dämpas hastigheten varvid det grövre stoftet avskiljs, dels genom centrifugalkraft och dels genom sin egenvikt. Luft och restpartiklar passerar sedan filtret där avskiljning sker (W350P). Drift Innan användning skall utbildning, information och anvisningar genomföras i handhavandet av maskinen och det avskilda dammet.
Page 5
Service Vid rengöring och service av maskinen måste maskinen stängas av och stickproppen dras ur • eluttaget. Undvik rengöring med hjälp av högtryckstvätt. Om detta är nödvändigt, se till att ej rikta strålen • mot maskinens öppningar, speciellt motorns inlopp/utlopp för kylluften. Innan den använda maskinen flyttas från arbetsområdet, skall den rensugas eller avtvättas.
Page 6
Felsökning W250P samt W350P är konstruerade och anpassade för en krävande miljö och uppgift, men användaren bör dock beakta att aggregaten innehåller precisionstillverkade komponenter som bör skyddas mot hårda slag och stötar. Filter, tätningar, infästningar och anslutningar är omsorgsfullt anpassade och utvalda för operatörens arbetsmiljö. Det är därför naturligtvis av stor vikt att operatör och servicepersonal behandlar aggregatet med insikt och kunskap, detta för att maskinen skall tjäna...
Page 7
Pullman-Ermator will not take any responsibility. Before start using the machine, please carefully read the safety regulations. Read the complete instruction book before start using the Pullman-Ermator W250P/W350P. All spare part used for the Pullman-Ermator W250P/W350P must be recognized by Pullman- Ermator AB. Revision 2...
Unpacking When unpacking the machine, please check that the following accessories are included: The hose with end fittings. • Steel tube. • Floor nozzle. • Crevice tool. • If some of above mention parts are missing, please contact your local distributor or our sales representative.
Function The motor is started by the switch. Dust laden air is then sucked through the inlet valve at high speed via the suction hose. The air is slowed down by the cyclone and coarse dust particles are separated out, partly by centrifugal force ans partly by gravity. Air and finer particles then pass through the fine filter where separation is made.
Service When cleaning and servicing the machine. You must switch off the machine and pull out the plug from the outlet. Avoid cleaning with high pressure cleaner. If neccessary do not point att the openings on the • machine, especially the opening for the cooling air. Before moving the machine from the working area, the machine must be cleaned.
Problem solving W250P/W350P are manufactured and made for a severe environment and tasks, but the user must notice that the machine contents of components which must be protected from hits and blows. Filter, sealings connections are carefully chosen to serve the operator. Therefore must the machine be treated with knowledge as to work correctly for many years.
TEKNISKA DATA TECHNICAL PERFORMANCE W250P – W350P W250P W350P MÄRKSPÄNNING 230 VAC, 1-fas 230 VAC, 1-fas Voltage EFFEKTUTTAG 1300 W 1300 W Power PUMPEFFEKT 450 W 650 W Power MAX LYFTHÖJD Height MAX SUGKAPACITET 150 l/min 290 l/min Capacity MAX LUFTMÄNGD 190 m³/h...
Declare under our sole responsibility that the machine Certifie sous sa propre responsabilité que le produit ciaprès Versichern auf eigener verantwortung, dass das Produkt Forsikrer under eget ansvar at maskinen W250P Nr./No: 0600778a0001 - W350P Nr./No: 0600764_0001 - Tillv.år/Manufact.year/Baujahr: 2006- som omfattas av denna försäkring är i överensstämmelse med standarder:...
