- Page 1 MV6000-UM.qxp 4/5/05 16:13 Page 1 Owner's Manual Mobile DVD/CD Player Models: MV6000 MV6000C For operational or technical assistance, after reading this manual, please call us toll free at (800) 638-3600 or visit www.magnadyne.com...
- Page 2 MV6000-UM.qxp 4/5/05 • Compatible with PAL and NTSC Systems. This player can play discs recorded in either PAL or NTSC format. • CD, DVD, CD-R, CD-RW, MP3 Compatible. • L/R stereo analog audio connection to existing head unit aux. inputs.
-
Page 3: Table Of Contents
This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Magnadyne Corporation and other rights owners. Use of this copyright protection technology must be authorized by Magnadyne... -
Page 4: Disc Notes
MV6000-UM.qxp 4/5/05 Disc Formats Supported by this Player: (Single-sided disc only) Discs which cannot be played with this player: • DVD-ROM • DVD-R/DVD-RAM • CDV • CD-G Disc Handling • Dirt, dust, scratches and warping disc will cause non operation. -
Page 5: Screen And Dvd/Cd Functions
MV6000-UM.qxp 4/5/05 1. PWR / STOP Button ( ton to turn the unit On/Off. Press to stop disc play. 2. MODE Button ( ): Press this button to change the play source between DVD/CD player and an auxiliary input source. -
Page 6: Adjusting The Monitor
MV6000-UM.qxp 4/5/05 Adjusting the Monitor: Press the Menu button to activate the monitor adjustment menu. The following will be dis- played on the screen: 1. Use the MENU button on the remote to activate the menu screen. 2. Press the MENU button again to select the desired monitor adjustment item. -
Page 7: Transmitter Frequency Selection
MV6000-UM.qxp 4/5/05 Transmitter Frequency Selection: Mono/ Stereo Switch 90.5MHz 90.1MHz 89.7MHz MONO ST The MovieVision viewing screen transmits a signal that is received by the MovieVision head- phones and can also be received by the vehi- cle’s car radio. There are 3 frequencies available for use but only one can be used at a time. -
Page 8: Wiring Diagram
MV6000-UM.qxp 4/5/05 Video Output Video Input Audio Input (Right) Audio Input (Left) 16:13 Page 8 Wiring Diagram Black Wire Ground Yellow Wire 12 V Memory Red Wire Ignition Green Wire See Dome Light Section for Connection White Wire See Dome Light Section for Connection... -
Page 9: Wiring Instructions
MV6000-UM.qxp 4/5/05 Power Harness Wiring: The 3 wire harness provides battery and igni- tion 12 volts as well as a chassis ground. Route the power harness to the point in the vehicle that you will make the connections. Red Wire: The red wire in the harness should... -
Page 10: Remote Control
MV6000-UM.qxp 4/5/05 Installing the Batteries: 1. Open the battery compartment cover. 2. Insert the two AAA size batteries. Make sure that the positive and negative terminals of the batteries are oriented correctly. 3. Close the battery compartment cover. 16:13 Page 10... -
Page 11: Remote Control Functions
MV6000-UM.qxp 4/5/05 1. POWER: Turns the unit On/Off. 2. EJECT: Ejects the disc. 3. MUTE: Mutes the sound. 4. SUBTITLE: Changes the SUBTITLE language on multi-subtitle language DVD disc. 5. ANGLE: Changes the view angle on multi-angle DVD disc. 6. DISPLAY: Displays statistical disc information during playback. -
Page 12: Headphones
MV6000-UM.qxp 4/5/05 1. VOL Knob: Rotate to increase and decrease the volume level. 2. Headphone Receptacle: A second set of per- sonal-type headphones (must have 3.5 mini male type plug) can be connected in this recep- tacle. 3. Preprogrammed Buttons: 3 pre-programmed buttons to tune the headphone radio to the exact MovieVision signal. -
Page 13: Headphone Operation
MV6000-UM.qxp 4/5/05 The correct operation, care and maintenance of the headphones is critical to their ability to provide the user with a lifetime of operation. Misuse, abuse and neglect of the headphones will result in poor performance and premature failure. -
Page 14: Basic Operation
MV6000-UM.qxp 4/5/05 Turn the Unit On 1. Turn the car ignition on to the accessory posi- tion. 2. Press the POWER button. Loading a DVD/CD Disc 1. Insert the disc with printed side facing up into the disc slot. The player will automati- cally search the disc. - Page 15 MV6000-UM.qxp 4/5/05 Skipping Track Press SKIP on the remote control dur- ing playback. Press to skip to next track to skip back one track. Mute Mutes the sound, while the disc continues play- ing. When MUTE is pressed again, sound will resume to previous level.
-
Page 16: Advanced Operation
MV6000-UM.qxp 4/5/05 Repeat Play/Repeat Paragraph Play: Repeat Play (REPEAT, 31) Press the REPEAT button to repeat a disc, track or chapter. 1. Press REPEAT button repeatedly to scan selection of repeat modes. 2. Pressing REPEAT will have different effects on various kinds of discs. - Page 17 MV6000-UM.qxp 4/5/05 Random Playing (RANDOM, 30) Press the RANDOM button during playback to play tracks in random order. Press RANDOM again to revert to normal playback. Note: This function is effective only on a CD. Zoom Press the ZOOM button during playback of DVD to enlarge an area on the screen.
-
Page 18: Initial Dvd Setup
MV6000-UM.qxp 4/5/05 INITIAL SETUP: 1. Turn the unit on without any disc inside the unit. 2. Press the SETUP button on the remote to view the Setup Menu - Main Page. 3. The Setup Menu - Main Page categories are:... -
Page 19: Initial Dvd Setup
MV6000-UM.qxp 4/5/05 PREFERENCES SETUP Submenu: -- PREFERENCES PAGE -- SUBTITLE DISC MENU PARENTAL PASSWORD DEFAULTS SMARTNAVI MAIN PAGE BACK TO MAIN PAGE 1. Use the NAVIGATIONAL to scroll between the menu items. 2. Make a selection by pressing the ENTER button. -
Page 20: Specifications
MV6000-UM.qxp 4/5/05 Supply Voltage ..12V DC, Negative Ground Current Consumption . Less than 3A Signal System ..Composite Video 1.0Vp-p 75Ω Compatible Discs ..DVD-Video Disc:... -
Page 21: Troubleshooting
• Press POWER to turn “Off” the unit, then press it again to turn “On” the unit. DVD player showing “REGION ERROR”: • The DVD player and the discs all have a “REGION CODE”. If the region number on the disc does not correspond to the region num- ber of the DVD player the unit cannot play the disc. -
Page 22: Replacement Parts
9 a.m. and 5 p.m. weekdays. If UPS is unable to deliver, your order will be returned and additional shipping charges will be required. 16:14 Page 22 Replacement Parts Order Form We Accept Checks, Money Orders, Visa and Master Card Make Checks Payable to: Magnadyne Corporation FIRST NAME STATE ZIP CODE MASTER CARD EXP. MONTH... -
Page 23: Warranty
DVD Remote Control Magnadyne Corporation or its authorized agents will within 1 year from the date of sale to you, repair, replace or refund the retail sales price of said product or any part thereof, at the option of the... - Page 24 MV6000-UM.qxp 4/5/05 16:14 Page 24 © Copyright 2005 MV6000-UM Magnadyne Corporation Rev. B 4-5-05...
