Owner's Manual
Mobile DVD Player
DVD • CD • CDRW • MP3 PLAYER
PLAY/
REMOTE
PAUSE
Model: MV-DVD-PL3
For operational or technical assistance, after reading this manual,
please call us toll free at (800) 638-3600.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MV-DVD-PL3 and is the answer not in the manual?

Questions and answers

Summary of Contents for Movie Vision MV-DVD-PL3

  • Page 1 Owner's Manual Mobile DVD Player DVD • CD • CDRW • MP3 PLAYER PLAY/ REMOTE PAUSE Model: MV-DVD-PL3 For operational or technical assistance, after reading this manual, please call us toll free at (800) 638-3600.
  • Page 2: Use This Product Safely

    Compatible with PAL and NTSC Systems This player can play discs recorded in either PAL or NTSC format. • A single LSI chip now integrates all major DVD playback circuit functions including MPEG2 decoder, video D/A converter, and audio decoder. Driving Be aware of road and traffic conditions, keep the volume at a low level.
  • Page 3: Table Of Contents

    This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Magnadyne Corporation and other rights owners. Use of this copyright protection technology must be authorized by Magnadyne Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Magnadyne Corporation.
  • Page 4: Disc Notes

    Disc Formats Supported by this Player: Discs which Cannot be Played with this Player: • DVD-ROM • DVD-R/DVD-RAM • CDV • CD-G Handling and Cleaning • Dirt, dust, scratches and warping disc will cause non operation. • Do not place stickers on disc or scratch disc.
  • Page 5: Installation

    Note: 1. First remove the two screws that lock the player mechanism (see figure below). Then attach the brackets on both sides of unit with the M4x5 screws. Next, install the unit with the M5x25 screws. SCREW M5x25 SCREW M4x5 SCREW M4x5 Installation...
  • Page 6: Electric Connection

    Connecting to a VCR as an Auxiliary Source MV-DVD-PL3 Red Ignition Black Ground Yellow Battery Power Connecting to a MovieVision Systems as the Only Source MV-DVD-PL3 MV-PL3IRA Red Ignition 12V Black Ground Yellow Battery Power Connecting to a MovieVision System as the Second Source...
  • Page 7: Dvd Unit Functions

    1. POWER 2. DISC SLOT 3. EJECT 4. RESET 5. REMOTE INFRARED SENSOR Loading a DVD/VCD/CD Disc 1. Turn the car ignition on to the accessory position. 2. Press the POWER button (1). 3. Insert the disc with printed side facing up into the disc slot (2).
  • Page 8: Remote Control

    Preparing the Remote Control Inserting the Batteries: 1. Open the battery compartment cover. 2. Insert the two AAA size batteries. Make sure that the positive and negative terminals of the batteries are oriented correctly. 3. Close the battery compartment cover. Remote Control Preparing/Using the Remote Control Using the Remote Control...
  • Page 9: Remote Conrol Funtions

    1. POWER: Turns the unit ON or OFF. 2. EJECT: Ejects the disc. 3. MUTE: Mutes the sound. 4. SUBTITLE: Changes the SUBTITLE language on multi-subtitle language DVD disc. 5. ANGLE: Changes the view angle on multi-angle DVD disc. 6. DISPLAY: Displays statistical disc information during playback.
  • Page 10: Basic Operation

    Stopping Play Press the STOP button to stop the disk playback. Pressing the the disk will continue with normal play- back. Press the STOP button twice, to stop the playback and go back to initial Track/Chapter. Rapid Forward/Rapid Reverse Press FF and REW Each time the button is pressed, the speed of rapid forward/reverse changes...
  • Page 11: On-Screen Display Function

    Disc Search (GOTO) DVD: Press GOTO button twice. The screen will display the following message: TITLE 01/01 TIME 00:00:25 You can select the item you want to watch using the TIME setting by using the numeric buttons and the ENTER button. VCD (with PBC Off)/CD: Press GOTO button once, the screen will display the following message:...
  • Page 12 3. Press DISPLAY for a third time: CHAPTER ELAPSED 00:00:24 4. Press DISPLAY for a fourth time: CHAPTER REMAIN 00:01:39 5. Press DISPLAY for a fifth time and the message on the screen will be cleared. VCD: 1. Press DISPLAY for the first time: SINGLE ELAPSED 00:00:25 2.
  • Page 13: Multi-Audio Language Function

    Multi-Audio Language Function DVD: Press AUDIO during playback. Each time the button is pressed, the number of the audio soundtrack language changes in sequential order. Notes: • The language number is different according to the disc. • Some discs contain only one language soundtrack.
  • Page 14: Mp3 Disc Play

    MP3 Disc Play: MP3 disc is playing as the format of FOLDER. Example: SMART NAVI ROOT ROOT MP3 MUSIC MP3 HEAR YOUR PLAY MODE DISC folder, then press the ENTER button. Pressing the REPEAT button continuously selects from three types of repeat play modes: REP-ONE: Plays one song continuously.
  • Page 15: Initial Setup

    – INITIAL SETUP – GENERAL SETUP SPEAKER SETUP AUDIO SETUP PREFERENCES EXIT SETUP 1. Press SETUP in the stop mode. (Press the stop button twice to ensure the player in the STOP mode.) 2. The initial SETUP menu is displayed. 3.
  • Page 16: General Setup

    TV DISPLA Y PIC MODE ANGLE MARK OSD LANG CAPTIONS SCR SAVER MAIN PAGE PIC Mode Setup • Select AUTO, the player PIC mode will depend on DVD disc. • Select HI-RES format for best image resolution. • Select N-FLICKER mode format if image or picture has noise.
  • Page 17: Audio Setup

    – GENERAL SETUP PAGE – TV DISPLA Y PIC MODE ANGLE MARK OSD LANG CAPTIONS SCR SAVER MAIN PAGE SCR Saver Setup Select the SCR SAVER output ON or OFF. – SPEAKER SETUP – DOWNMIX LT/RT STEREO MAIN PAGE SPEAKER Setup This activates the audio output from DOLBY AC3 5.1 DOWNMIX to 2-Channel mode.
  • Page 18: Audio Setup

    – AUDIO SETUP – AUDIO OUT OP MODE DYNAMIC LPCM OUTPUT MAIN PAGE DYNAMIC RANGE CONTROL Select DYNAMIC and adjust the dynamic range of the Dolby Digital encoded pro- gram. There are 8 compression steps between FULL and OFF. – AUDIO SETUP – AUDIO OUT OP MODE DYNAMIC...
  • Page 19 TV TYPE AUDIO SUBTITLE ENGLISH DISC MENU FRENCH PARENT AL SPANISH PASSWORD CHINESE DEFAULTS JAPANESE SMART NAV MAIN PAGE SUBTITLE LANGUAGE Setup Select the preferred SUBTITLE language by using the CURSOR buttons. TV TYPE AUDIO SUBTITLE DISC MENU ENGLISH PARENT AL FRENCH PASSWORD SPANISH...
  • Page 20: Smart Nav

    – PREFERENCES SETUP – TV TYPE AUDIO SUBTITLE DISC MENU PARENT AL PASSWORD DEFAULTS RESET SMART NAV MAIN PAGE DEFAULTS Select RESET to capture initial factory settings. – PREFERENCES SETUP – TV TYPE AUDIO SUBTITLE DISC MENU PARENT AL PASSWORD DEFAULTS SMART NAV MAIN PAGE...
  • Page 21: Troubleshooting

    If it appears that your DVD unit is faulty, first consult this checklist. Only qualified service personnel can remove the cover or service this player. Otherwise the warranty will become invalid. No Power: • Check to see if the player is set to "On". •...
  • Page 22: Replacement Parts

    9 a.m. and 5 p.m. weekdays. If UPS is unable to deliver, your order will be Replacement Parts Order Form We Accept Checks, Money Orders, Visa and Master Card Make Checks Payable to: Magnadyne Corporation FIRST NAME STATE MASTER CARD EXP.
  • Page 23: One (1) Year Limited Warranty

    DVD Remote Control Magnadyne Corporation or its authorized agents will within 1 year from the date of sale to you, repair, replace or refund the retail sales price of said product or any part thereof, at the option of the...
  • Page 24 © Copyright 2004 MV-DVD-PL3 Magnadyne Corporation REV. C 6-9-04...
