  • Page 1 Q-SERIES Power ® BAQ-UP (QRED) Redundancy Switch ™ with Backup Amplifier Installation & Operation Manual...
  • Page 2 Specifications subject to change without notice. Q-Series is a registered trademark of ATX in the United States and/or other countries. Products or features contained herein may be covered by one or more U.S. or foreign ® patents. Other non-ATX product and company names in this manual are the property of their respective companies...
  • Page 3: Table Of Contents

    2.1. Functional Schematic ........................2-2 SET-UP PROCEDURE ..........................3-1 SPECIFICATIONS ............................. 4-1 SERVICE & SUPPORT ..........................5-1 5.1. Contact ATX Networks ........................5-1 5.2. Warranty Information ......................... 5-1 Q-Series Power – BAQ-UP™ (QRED) Redundancy Switch with Backup Amplifier – Installation & Operation Manual...
  • Page 4 This page left intentionally blank. Q-Series Power – BAQ-UP™ (QRED) Redundancy Switch with Backup Amplifier – Installation & Operation Manual ®...
  • Page 5: Description Of Interfaces

    CHAPTER 1: DESCRIPTION OF INTERFACES DESCRIPTION OF INTERFACES Description of Interfaces BAQ-UP™ Front View The BAQ-UP™ system (the system) has three compartments: the amplifier compartment, the power supply compartment, and the RF switch compartment. Power Supply Compartment: (Located in the center portion of the chassis) Rear: 24 VAC Input 24 VDC Input...
  • Page 6 CHAPTER 1: DESCRIPTION OF INTERFACES Alarms: Alarm 1 (form C) for the primary amp Alarm 2 (form C) for the secondary amp Switch: Remote control switch contacts Description: The form C contacts may be used to switch any warning device that can provide a notification in case either amplifier has failed.
  • Page 7: Description Of Operation

    CHAPTER 2: DESCRIPTION OF OPERATION DESCRIPTION OF OPERATION Description of Operation RF output levels of both the primary and the secondary amplifiers are sampled and this sample is converted to a voltage value. At initial power on, the system is switched to run on the primary amp. The yellow LED will flash slowly indicating the reference levels need to be set.
  • Page 8: Functional Schematic

    In addition to the wiring backup protection. This typically is used in the signal path where an amplifier method, the microprocessor is programmed at ATX to failure is not acceptable. The QRED switch is programmed to switch to the...
  • Page 9: Set-Up Procedure

    CHAPTER 3: SET-UP PROCEDURE SET-UP PROCEDURE Set-up Procedure Remove the cover. Connect input signal to the “Input” of the RF switch compartment. Connect the “Output to Secondary Amp” of the RF switch compartment to the “Input” of the amplifier compartment. Connect the “Output”...
  • Page 10 CHAPTER 3: SET-UP PROCEDURE This page left intentionally blank. Q-Series Power – BAQ-UP™ (QRED) Redundancy Switch with Backup Amplifier – Installation & Operation Manual ®...
  • Page 11: Specifications

    CHAPTER 4: SPECIFICATIONS SPECIFICATIONS Specifications Q-Series Power – BAQ-UP™ (QRED) Redundancy Switch with Backup Amplifier – Installation & Operation Manual ®...
  • Page 12 CHAPTER 4: SPECIFICATIONS This page left intentionally blank. Q-Series Power – BAQ-UP™ (QRED) Redundancy Switch with Backup Amplifier – Installation & Operation Manual ®...
  • Page 13: Service & Support

    Please contact ATX Technical Support for assistance with any ATX products. Please contact ATX Customer Service to obtain a valid RMA number for any ATX products that require service and are in or out-of-warranty before returning a failed module to the factory.
  • Page 14 1-501 Clements Road West, Ajax, ON L1S 7H4 Canada Tel +1 (905) 428-6068 Toll Free +1 (800) 565-7488 Fax +1 (905) 427-1964 Toll Free Fax +1 (866) 427-1964 www.atxnetworks.com support@atxnetworks.com Page 4 of 4 Printed in Canada Rev. 07/15 (ANW0849)
