Page 1: User Manual
Fat Shark RC Vision Systems ATTITUDE V3 MODEL FSV1045 USER MANUAL Revision A 09/10/2015 For more product information, please visit: www.fatshark.com All Rights Reserved... -
Page 2: Table Of Contents
Trouble Shooting ....................12 Introduction Congratulations on purchasing Fat Shark Attitude V3 FPV video goggle integrated with modular receiver bay, interlaced 3D solution and head tracking. To ensure your continued enjoyment, please take the time to thoroughly read through this operating manual before using. -
Page 3: Product Contents
Fat Shark RC Vision Systems Product Contents Carry Case Attitude V3 Headset 5G8 Receiver Module (32ch with RaceBand) SpiroNET Circular Polarized Antenna 1000mAh Battery (and discharge lead) Manual... -
Page 4: Controls Diagram
Fat Shark RC Vision Systems Controls Diagram Channel Selection / Display Control Head Tracker Reset Power in Antenna SMA AV in/out IPD adjustment PS/2 Data Port (Head Tracker) RX on/off Earphone jack... -
Page 5: Controls
Channel select: Rocking the channel select switch forward and back will cause the channel to incrementally increase/decrease. Audio beep sounds on channel change. A long beep sounds on channel top and bottom limits. Note: Fat Shark only guarantees compatibility with Fat Shark or ImmersionRC transmitters. Name Fat Shark/IRC... -
Page 6: Head Tracking Menu Navigation
For a complete and up to date list of compatible RC radios and their setup, a head tracking sticky thread is maintained at www.FPVlab.com under SPONSORS GATE/FAT SHARK Operation Notes: Head tracker analog tracking is always on. Depressing button re centers head tracker. -
Page 7: Av In/Out Port
Fat Shark RC Vision Systems AV in/out Port Ground Video AudR RCA Connector: Yellow: Video, White: Audio Left, Red: Audio Right Recording Video Connect AV cable to AV out port on right side of headset. Connect recording device to cables and set up as per manufacturer directions. -
Page 8: Adjustable Earphones (Fsv1605)
This 3 RCA Male to 4-pole Right Angle Cable allows you output the wireless signal from your Fat Shark headset to an external monitor or recording device. It can also be used to connect and display alternative video sources in the goggles. -
Page 9: Specifications
Fat Shark RC Vision Systems Specifications Headset Specifications Optics: FOV (field of view): 32°diagonal (Image size: 1.3m @ 2m) Type: Plastic optic module Interpupillary Distance(IPD): 59 to 69 mm (adjustable) Optional Diopter Lens Inserts: -2, -4, -6 dpt Display: Full color LCD polarized LED backlit... - Page 10 Fat Shark RC Vision Systems 5G8 RaceBand Receiver Specifications: Electrical: Supply Power: 3.3~5 V ≤ -90 dB RX Sensitivity: RF Input Level: -90 dBm~+5 dBm Video Format: NTSC/PAL Operation: Operating Temperature: -10~65 ° Mechanical: Size: 42 x 25 mm Weight: 10.8 g...
-
Page 11: Operational Advice
Fat Shark RC Vision Systems Operational Advice • For best performance, select a channel that has the least amount of interference. While the transmitter is turned OFF, turn on the video headset and look at the screen as you check each channel. -
Page 12: Trouble Shooting
If your problem can’t be solved here, please visit our support forum at www.FPVLAB.com under SPONSORS GATE/ FAT SHARK RC VISION SYSTEMS. Any direct support enquires will be first directed to this forum for the benefit of all customers. Observation...
