GE-DS-82 and GE-DS-82-PoE
Managed Switch Installation
Sheet

Package Contents

Thank you for purchasing the GE Security 8-Port Fast Ethernet + 2-Port Gigabit
TP/SFP Combo Managed PoE Switch.
The following Managed Switch model numbers are covered in this sheet:
•
GE-DS-82
•
GE-DS-82-PoE
Open the box of the Managed Switch and carefully unpack it. The box should
contain the following items:
•
The Managed Switch x 1
•
User manual CD x 1
•
This Installation Sheet x 1
•
RS232 cable x 1
•
Rubber feet x 4
•
Two rack-mounting brackets with attachment screws x 1
•
Power Cord x 1
If any item is found missing or damaged, please contact your local reseller for
replacement.
1 of 11
P/N 1069669-EN • REV 1.01 • ISS 24MAR10
© 2010 GE Security, Inc.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GE-DS-82 and is the answer not in the manual?

Questions and answers

Related Manuals for GE Security GE-DS-82

Summary of Contents for GE Security GE-DS-82

  • Page 1: Package Contents

    GE-DS-82 and GE-DS-82-PoE Managed Switch Installation Sheet Package Contents Thank you for purchasing the GE Security 8-Port Fast Ethernet + 2-Port Gigabit TP/SFP Combo Managed PoE Switch. The following Managed Switch model numbers are covered in this sheet: • GE-DS-82 •...

  • Page 2: System Requirements

    To configure the system, connect a serial cable to a COM port on a PC or notebook computer and to the serial (console) port of the GE-DS-82 Managed Switch. The console port of the Managed Switch is DCE already, so that you can connect the console port directly through PC without the need of Null Modem.
  • Page 3 Serial Port A terminal program is required to make the software connection to the GE-DS- 82 and the GE-DS-82-PoE Managed Switch. Window’s Hyper Terminal program is a good choice. The Hyper Terminal program can be accessed from the Start menu.
  • Page 4 Logon to the Console Once the terminal has connected to the device, Supply power to the GE-DS- 82 and the GE-DS-82-PoE Managed Switch, the terminal will display that it is running testing procedures. The following message asks for the login username and password. The factory default password for the login screen is: •...

  • Page 5: Telnet Setup

    Telnet Setup 1. Connect an RJ-45 cable from the PC to a Switch port on the Managed Switch. Figure 4: RJ-45 connection diagram Managed Switch PC / Workstation with IE Browser IP Address: 192.168.0.100 RJ-45/UTP-Cable IP Address: 192.168.0.x 2. Launch the Hyper Terminal program. A terminal program is required to make the software connection to the Managed Switch.
  • Page 6 3. The following screen will appear. Input a new connection name. You should use something like the model name of your switch. Figure 5: The New Connection dialog window 4. Change the Connect using drop-down menu to TCP/IP (Winsock) then input the Host address.
  • Page 7 Log on to the Console Make sure the device has finished booting. Once telnet has connected to the device, the Hyper terminal will display the login request. The following message asks for the login username and password. The factory default password username and password is: User name: admin Password: admin Figure 7: The Login request window...

  • Page 8: Web Browser Setup

    Web Browser Setup Start Web Management The following shows how to start up the Web Management of the GE-DS-82 Managed Switch. Please note that the Managed Switch is configured through an Ethernet connection, make sure the manager PC must be set on the same IP subnet address.
  • Page 9 Login to the managed Switch 1. Enter the IP address http://192.168.0.100 (the factory-default IP address or one you have previously changed in the console) in the Web Browsers Address Field 2. The following dialog box appears. Please enter the default password “admin”...

  • Page 10: Resetting The Ip Address

    3. After entering the username and password, the main screen appears as shown in Figure 10. Figure 10: Main Screen of the GE-DS-82 4. You can use the Web Management interface to continue the Switch management. Please refer to the user manual for more information.

  • Page 11: Contact Information

    Thank you for purchasing GE Security products. You can browse our online FAQ resource at the GE Security website first to check if it could solve you issue. If you need more support information, please contact GE Security support team.
