Sony SED-E1 Startup Manual

Smarteyeglass.
Hide thumbs


Advertising

Advertising

Eyewear
Accelerometer, Gyroscope,
Electronic compass
Start Here
Brightness sensor
Nose pad
SmartEyeglass
Developer Edition
Supplied items
• Micro USB cable
Startup Guide
• Carrying case
• Dark filter
For use by developers in testing and creation of applications for
• Camera cover sheet
SmartEyeglass platform.
• Nose pad (small)
4-541-088-12(1)
• Warranty
• Startup Guide (this document)
• Reference Guide
SED-E1
Controller
(CAMERA) button
BLUETOOTH indicator
Noise suppression
WLAN indicator
sub microphone
BACK button
POWER switch 
Strap hole
Speaker
Rotary clip
Micro USB port
(N mark)
Touch sensor 
CHARGE indicator
TALK button
Microphone
Camera indicator
A
To turn on/off the power
Camera
Slide and hold the POWER switch to ON/
OFF for 4 seconds or more.
When only sliding the switch without
holding it, the image display turns on /
off.
B
To operate the touch sensor
Tap
Swipe from side to side.
Switches the item on the display.
Selects/enters the item.
STEP
STEP
Installing the Applications
1
2
Charging the Battery
into a Smartphone
Connect the controller to a computer with the supplied
Scan the 2 codes below, and install two applications into
micro USB cable to charge the built-in lithium-ion battery.
your smartphone. Use a smartphone with Android™ 4.4 or
The CHARGE indicator lights up in orange during charging
later.
and turns off when the charging completes.
 Install "Smart Connect".
https://play.google.com/store/apps/details?id=com.
sonyericsson.extras.liveware
CHARGE indicator
If "Smart Connect" is already installed, update it to the
latest version.
 After installing "Smart Connect", select [Open] on the
"Smart Connect" screen in Google Play to start "Smart
Connect".
 Install "SmartEyeglass".
https://play.google.com/store/apps/details?id=com.
sony.smarteyeglass
Tip
It takes about 2 hours to completely charge a fully-discharged
battery.
STEP
Wearing/Adjusting the
3
Eyewear
Wear the eyewear. If the eyewear does not fit, adjust the
angle or width of nose pad.
Tips
• If the eyewear does not fit by adjusting the nose pad, replace it
with the supplied nose pad (small). For details on how to replace
the nose pad, refer to the Help Guide.
• We recommend that you attach the controller to your clothing, etc.,
using the rotary clip.
• You cannot put on the eyewear while wearing glasses.
SED-E1
4-541-088-12(1)
