MAINTAINING YOUR VEHICLE

FUSES

Interior Fuses
• The interior fuse panel is part of the Body Control Module (BCM) and is located on
the driver's side under the instrument panel.
Vehicle Fuse
Cavity
Number
1 F12
2 F32
3 F53
4 F38
5 F36
6 F43
7 F48
8 F13
9 F50
10 F51
11 F37
12 F49
13 F31
14 F47
NOTE:
The fuse for the heated mirrors (5 Amp Tan) is located behind the access panel on the
front of the Instrument Panel. This fuse is a single fuse attached directly to the wire
harness.
Underhood Fuses
• A second fuse panel is located on the driver' s side of the engine compartment, next to
the battery. To access the fuses, press the release tabs and remove the cover.
• The ID number of the electrical component corresponding to each fuse can be found
on the back of the cover.
Cavity Maxi Fuse
F01 60 Amp Blue
F02 20 Amp Yellow
F03 20 Amp Yellow
84
Mini Fuse
7.5 Amp Brown
5 Amp Tan
5 Amp Tan
20 Amp Yellow
10 Amp Red
20 Amp Yellow
20 Amp Yellow
7.5 Amp Brown
7.5 Amp Brown
5 Amp Tan
5 Amp Tan
5 Amp Tan
5 Amp Tan
20 Amp Yellow
Mini Fuse
Description
Right Low Beam
Front and Rear Ceiling Lights Trunk
and Door Courtesy Lights
Instrument Panel Node
Central Door Locking
Diagnostic Socket, Car Radio, Climate
Control System
Bi-Directional Washer
Passenger Power Window
Left Low Beam, Headlamp Leveling
Airbag
Car Radio Switch, Climate Control
System, Stop Light, Clutch
Stop Light Switch, Instrument Panel
Node
Exterior Mirror, GPS, Electric Mirror,
Parking Sensor
Ignition, Climate Control
Driver Power Window
Description
Body Controller
Audio Amplifier
Ignition Switch
