Changing a fuse
FUSES IN THE ENGINE COMPARTMENT
-
Remove the nuts and tilt the box to
access the fuses.
Fuses
A (amps)
1
40
ABS pump supply
2
50
Diesel pre-heater unit
3
30
Ignition switch
4
20
Programmable additional heating
5
20
Cab ventilation with programmable additional heating
6
40/60
Cab fan max speed
7
40/50
Cab fan min speed
8
40
Cab fan unit
9
20
Screenwash pump
10
15
Horn
14
7.5
Right hand main beam
15
7.5
Left hand main beam
20
30
Headlamp wash pump
21
15
Fuel pump supply
23
30
ABS electrovalves
30
15
Front foglamps
Allocation
