Summary of Contents for PEUGEOT BIPPER

  • Page 1 Handbook...
  • Page 2 If the "MyPeugeOt" function is not available on the PeugeOt public website for your country, you can find your handbook at the following address: http://public.servicebox.peugeot.com/ddb/...
  • Page 3 PeugeOt may result in a failure of your vehicle's electronic system. Contact a PeugeOt PeugeOt thanks you for your confidence and wishes you very dealer to be shown the recommended equipment and happy motoring.

  • Page 4: Table Of Contents

    Contents OVERVIEW SAFETY READY TO SET EASE OF USE and TECHNOLOGY on 4-21 111-136 25-63 COMFORT 64-82 BOARD 83-110 Trip computer exterior Instrument panels Front seats Parking brake Vehicle configuration Interior Warning lamps Folding front passenger Hazard warning Rear parking sensors seat lamps Instruments and...
  • Page 5 Contents ACCESSORIES CHECKS QUICK HELP TECHNICAL DATA 137-140 141-151 152-173 174-183 towing a trailer, Filling with fuel Battery Dimensions Engines caravan, etc... Opening the bonnet Changing a wheel Weights Roof rack and Diesel engine temporary puncture roof bars repair kit Identification Petrol engine Other accessories...

  • Page 6: Exterior

    Location EXTERIOR (LIGHT VAN) Dimensions ......174-175 Right-hand side: Accessories ......139-140 fuel filler cap, fuel tank ....142 Roof rack ........139 fuel cut-off .......142-143 load space .........77-78 Key, remote control, battery ..36-38 Rear doors ......36, 42-45 Central locking .....36, 42, 44 Opening/Closing to 180° ...42, 44 Opening/Closing front windows ..37 Confidential card......39 Alarm ..........40...
  • Page 7 Location EXTERIOR (COMBI) Dimensions ..... 176-177, 178-179 Right-hand side: Accessories ......139-140 fuel filler cap, fuel tank ....142 Roof bars ........139 fuel cut-off .......142-143 Rear fittings ........80-81 Key, remote control, battery ..36-38 Rear doors ......36, 42-45 Central locking .....36, 42, 44 Opening/Closing to 180°...

  • Page 8: Interior

    Location INTERIOR (LIGHT VAN) Battery (+), charging, starting .........152-154 Rear view mirror ......51 Front courtesy lamp ......82 Seat belts........ 118-119 Changing a courtesy lamp Airbags ........120-123 bulb ..........163 Deactivating the passenger's front airbag ......122, 127 Folding seat ........66 Seats, adjustments .....64-65 Child seats ....124, 126-131, 133 tools, jack ........155 12 V socket ........76...
  • Page 9 Location INTERIOR (LIGHT VAN) Battery (+), charging, starting .........152-154 Seat belts........ 118-119 Rear view mirror ......51 Airbags ........120-123 Front courtesy lamp ......82 Deactivating the passenger's front airbag ......122, 127 Changing a courtesy lamp bulb ..........163 Folding seat ........66 Seats, adjustments .....64-65 Child seats ....124, 126-131, 133 tools, jack ........155 12 V socket ........76...
  • Page 10 Location INTERIOR (COMBI) Battery (+), charging, Rear view mirror ......51 starting .........152-154 Front courtesy lamp ......82 Changing a courtesy lamp Front seat belts ....... 118-119 bulb ..........163 Airbags ........120-123 Deactivating the passenger's front airbag ........122, 127 Folding seat ........66 Bench rear seat ......67-68 Rear seat belts .......
  • Page 11 Location INTERIOR (COMBI) Battery (+), charging, starting .........152-154 Front seat belts ....... 118-119 Airbags ........120-123 Rear view mirror ......51 Deactivating the passenger's Front courtesy lamp ......82 front airbag ......122, 127 Changing a courtesy lamp bulb ..........163 Folding seat ........66 Bench rear seat ......67-68 Rear seat belts .......
  • Page 12 Location INTERIOR (COMBI) Battery (+), charging, Rear view mirror ......51 starting .........152-154 Front courtesy lamp ......82 Changing a courtesy lamp Front seat belts ...... 118-119 bulb ..........163 Airbags ........120-123 Deactivating the passenger's airbag ........122, 127 Folding seat ........66 Bench rear seat ......69-70 Rear seat belts .......
  • Page 13 Location INTERIOR (COMBI) Battery (+), charging, starting .........152-154 Front seat belts ....... 118-119 Airbags ........120-123 Rear view mirror ......51 Deactivating the passenger's front Front courtesy lamp ......82 airbag ........122, 127 Changing a courtesy lamp bulb ..........163 Folding seat ........66 Bench rear seat ......69-70 Front seats, adjustments ....64-65 Rear seat belts .......

  • Page 14: Instruments And Controls

    Location INSTRUMENTS AND CONTROLS Instrument panels, screens, dials ..25 Steering wheel, adjustments ...53 Warning lamps, indicator lamps ..26-33 Horn ..........112 Indicators, gauge ......34-35 Dashboard / Centre console ..18-19 lighting controls ......46-47 guide-me-home lighting ....47 Parking lamps ........46 Front/rear wipers ......48 Screenwash ........48 Cruise control ......49-50 trip computer ........83...
  • Page 15 Location Audio system, CD/MP3 ....89-92 Audio steering mounted controls / Hands-free kit ....90, 93-110 Stop & Start ........61-63 Hazard warning lamps ....111 gear shift indicator ......58 Demisting/defrosting ......71 locking the load space ....43-44 gearboxes ......53, 54-57 Rear parking sensors ......88 Front fittings ........76-77 ●...
  • Page 16 Location INSTRUMENTS AND CONTROLS Instrument panels, screens, dials ..25 Steering wheel, adjustment .....53 Warning laps, indicator lamps ..26-33 Horn ..........112 Indicators, gauge ......34-35 Dashboard / Centre console ..20-21 gear shift indicator ......58 Audio steering mounted controls / Hands-free kit ....90, 93-110 Front/rear wipers ......48 lighting controls ......46-47 Screenwash ........48...
  • Page 17 Location Audio system, CD/MP3 ....89-92 Stop & Start ........61-63 Hazard warning lamps ....111 Demisting/defrosting ......71 locking the load space ....43-44 Heating, ventilation, air conditioning ......72-75 gearboxes ......53, 54-57 Opening the bonnet .......144 Rear parking sensors ......88 Front fittings ........76-77 ●...

  • Page 18: Technical Data - Maintenance

    Location TECHNICAL DATA - MAINTENANCE levels ........147-148 Changing a wiper blade ....166 ● dipstick, ● power steering fluid, ● brake fluid, ● coolant, ● screenwash. engine fuses ....167, 170-171 Checks........149-151 Bulbs, lighting, changing ● battery, bulbs ........161-165 ● air/passenger compartment filter, ●...
  • Page 19 Location...

  • Page 20: Dashboard And Centre Console

    Presentation Dashboard / Centre console 1. Door mirror controls. 2. Front door glass demisting vent. 3. Adjustable side vent. 4. lighting and direction indicator control stalk. 5. Instrument panel. 6. Steering mounted audio system controls. Bluetooth hands-free system. 7. Wash / Wipe / trip computer control stalk. 8.
  • Page 21 Presentation Centre control panel Side control panel A. Passenger's front airbag deactivated 1. Front foglamps. warning lamp. 2. Rear foglamps. B. Deactivation of Stop & Start. 3. Intelligent traction control C. Hazard warning lamps. D. Heated rear screen and door mirrors. Wheel anti-slip regulation (ASR).
  • Page 22 Presentation Dashboard / Centre console 1. Front door glass demisting vent. 2. Adjustable side vent. 3. Passenger's front airbag. 4. Adjustable centre vents. 5. Audio system. 6. Windscreen demisting vent. 7. lighting and direction indicator control stalk. 8. Instrument panel. 9.
  • Page 23 Presentation Centre control panel Side control panel 1. Vehicle configuration (access to menus, A. Passenger's front airbag deactivated confirmation, quit menus). warning lamp. B. Deactivation of Stop & Start. 2. Adjust headlamps up / Vehicle configuration (angle up, increase a value). C.

  • Page 24: Environment

    Motoring & Environment ENVIRONMENT With you, PeugeOt acts to protect the As the driver, you also can contribute to Refer to information on eco-driving at the environment. protecting the environment by following certain end of this section. We invite you to visit the www.peugeot.co.uk rules: website.

  • Page 25: Eco-Driving

    Motoring & Environment ECO-DRIVING eco-driving is a range of everyday practices that allow the motorist to optimise their fuel consumption and CO emissions. Optimise the use of your gearbox Control the use of your electrical equipment With a manual gearbox, move off gently and change up without Before moving off, if the passenger compartment is too warm, ventilate it waiting.
  • Page 26 Motoring & Environment Limit the causes of excess consumption Observe the recommendations on maintenance Spread loads throughout the vehicle; place the heaviest items in the Check the tyre pressures regularly, when cold, referring to the label in bottom of the boot, as close as possible to the rear seats. the door aperture, driver's side.

  • Page 27: Off

    Instruments and controls Instrument panel with level 1 screen Instrument panel with level 2 screen INSTRUMENT PANELS Instrument panel level 1 screen 1. Distance recorder in miles / kilometres. time. Miles / Kilometres travelled. Modes and gear engaged on the 2.

  • Page 28: Warning Lamps

    "Do not ignore these warnings." Warning lamp indicates Solution - action Contact a PeugeOt dealer or a qualified on temporarily. minor faults. workshop.
  • Page 29 "Quick help - Battery" section. Battery charge continuously on, in an ignition or injection Contact a PeugeOt dealer or a qualified spite of the checks. fault. workshop. that a door is not closed Check that the front, rear and side doors are...
  • Page 30 Instruments and controls Warning lamp indicates Solution - action Have the system checked by a PeugeOt dealer or a Front airbag flashing or qualified workshop without delay. the failure of an airbag. lateral airbag continuously on. "Safety - Airbags" section.
  • Page 31 (ASR). "Safety - Driving safety" section. a fault with the Stop & Have the system checked by a PeugeOt dealer or a Stop & Start qualified workshop as soon as possible. Start. Have the brake pads replaced by a PeugeOt Brake pads front brake pads worn.
  • Page 32 "Checks" section. message in the screen. on, accompanied by Have the filter bled by a PeugeOt dealer or a Presence of water in water in the Diesel fuel a message in the qualified workshop.
  • Page 33 Instruments and controls Warning lamp indicates Solution - action turn the ring on the lighting control stalk to the Sidelamps a manual selection. first position. Dipped beam turn the ring on the lighting control stalk to the a manual selection. headlamps first position.
  • Page 34 Instruments and controls Warning lamp indicates Solution - action activation of the cruise Manual selection. Cruise control control. "Ready to set off - Steering mounted controls" section. Intelligent traction activation of the intelligent Manual selection. control traction control section. "Safety - Driving safety" section.
  • Page 35 Instruments and controls Display displays indicates Solution - action engine StOP mode As soon as you want to move off, the invoked following a stop of warning lamp goes off and the engine starts the vehicle. automatically in StARt mode. Stop &...

  • Page 36: Fuel Gauge

    When the pressure has dropped, check the level and remove the cap to top up. If the needle remains in the red zone, contact a PEUGEOT or a qualified workshop. Refer to the "Checks - levels" section. FUEL GAUGE COOLANT TEMPERATURE...

  • Page 37: Indicator

    Stop as soon as it is safe to do so: park, switch off the ignition and contact a PEUGEOT dealer or a qualified workshop. Oil deterioration (1.3 HDi 75 hp engine only) the warning lamp flashes,...

  • Page 38: Remote Control

    Access Deadlocking Press this button twice to change locking to deadlocking. Deadlocking renders the exterior and interior door opening handles inoperative. Do not leave anyone inside the vehicle when it is deadlocked. Deadlocking is confirmed by a flash of the direction indicators.
  • Page 39 Access Opening the windows with the remote When closing the windows using the control remote control you must ensure that Pressing and holding this button nothing prevents their correct closing. the for more than 3 seconds starts anti-pinch function does not operate when opening of the windows.

  • Page 40: Key

    Only use batteries which are identical or of with a thin tip, an equivalent type to those recommended by a PeugeOt dealer. take used batteries to an approved collection point.

  • Page 41: Confidential Card

    It contains the identification code necessary and the key has been recognised, card, for any work carried out by a PeugeOt the engine can be started. have the keys memorised by a PeugeOt dealer on the electronic immobiliser system.

  • Page 42: Alarm

    Access ALARM Signalling of attempted intrusion Good practice this provides: to quickly deactivate the siren following When you return to your vehicle, exterior perimeter protection by means of unwanted triggering, unlock the vehicle flashing of the electronic engine detectors on the doors and bonnet and using the remote control.

  • Page 43: Opening

    Access If your vehicle is parked on a slope, guide the side door as it slides. the door could open or close more quickly due to the incline of the ground, risking injury. As a safety precaution and to guarantee correct operation, do not drive with the sliding side door open.
  • Page 44 Access Side-hinged rear doors Opening to 180° OPENING FROM THE INSIDE Press the catch while opening the door to the 60/40 type asymmetrical hinged rear Driver's door increase the opening angle of the door. doors have four closing points, including a Pull the interior handle to unlock.
  • Page 45 Access Sliding side door (Combi) Good practice Load space When opening, take care not to obstruct the Pull the handle A towards the rear, slide the Press once to unlock the sliding guide space on the floor to allow the door to door fully to pass the point of resistance in side doors and the rear doors slide correctly.

  • Page 46: Closing

    Access Load space CLOSING FROM INSIDE Press to lock the sliding side Central locking Closing from 180° doors and the rear doors (light van) from the driving position. the check strap will re-attach automatically Push the interior handle to lock the entire when the hinged doors are closed, the small vehicle or the door concerned.
  • Page 47 Access Sliding side door (Combi) Child safety CLOSING FROM THE OUTSIDE use the grab handle to pass the point of this prevents either of the rear doors being Sliding side door resistance and start the movement. then opened from inside. Pull the handle towards you then towards F turn the switch on each rear door a use the handle to guide the door closed.

  • Page 48: Lighting Stalk

    Steering mounted controls Dipped / main beam headlamps on "Motorway" function System which indicates a change of lane on high-speed roads. Press the lighting stalk up or down once, without passing the point of resistance; the corresponding direction indicators will flash turn the ring into position.
  • Page 49 Steering mounted controls Guide-me-home lighting Headlamp beam the temporary maintaining of the dipped You are advised to adjust the height of the headlamp beams in accordance with the beam headlamps, after switching off the load in your vehicle. vehicle's ignition, makes the driver's exit this function can only be accessed in easier when the light is poor by illuminating the main beam headlamps and dipped...

  • Page 50: Wiper Stalk

    Steering mounted controls WIPER STALK Windscreen wipers Windscreen wash Rear wiper Wiping is only active when the ignition key is Push the stalk down, the windscreen wash this is positioned on the window in the RUNNING position. alone is activated. of the large rear door.

  • Page 51: Cruise Control

    Steering mounted controls When the system is activated, the "Cruise Temporarily exceeding of the speed control" warning lamp comes on in the instrument panel. It is possible to accelerate and drive momentarily at a speed greater than the programmed speed (for example to overtake another vehicle).

  • Page 52: Fixed Speed Limiter

    In the event of an operating fault, turn the each brief press increases ring to the OFF position and contact a the speed by 1 mph (km/h). PeugeOt dealer or a qualified workshop. A maintained press increases the speed gradually. Good practice...

  • Page 53: Mirrors

    Mirrors and windows Select the mirror to be adjusted by turning the control to the right or to the left, then move the control in the direction of the adjustment required. to defrost the mirrors, press the heated rear screen button. REAR VIEW MIRROR DOOR MIRRORS the lever located on the lower edge moves...

  • Page 54: Electric Windows

    Mirrors and windows One-touch control An extended press on the control for the driver's window raises or lowers the window completely. Press the control again to stop the window. Press the control briefly to start the movement of the window. Manual controls ELECTRIC WINDOWS turn the window winder located on the door...

  • Page 55: Steering Wheel Adjustment

    Gearbox and steering wheel Good practice to change gear smoothly, always press the clutch pedal fully down. to prevent the mat from becoming caught under the pedal: ensure that the mat is positioned correctly, never fit one mat on top of another. Avoid leaving your hand on the gear knob as the force exerted, even if slight, may cause wear of the internal components of the...

  • Page 56: Electronic Gearbox

    Gearbox and steering wheel A: automated mode. Move the lever downwards to select this mode. E: economy programme. Press this button to activate or deactivate it. ELECTRONIC GEARBOX Gear lever gate the five-speed electronic gearbox offers a All movements of the gear lever are given choice between the comfort of automated from the middle position.
  • Page 57 Gearbox and steering wheel the AutO or sequential mode used Automated mode before switching off the ignition remains Once you have moved off, you can switch to in memory when the vehicle is restarted. automated mode by selecting position A/M. It is also possible to move off in "AUTO"...
  • Page 58 Gearbox and steering wheel Temporarily changing gear Sequential mode Stopping the vehicle in AUTO mode After using the automated mode, you can to switch off the engine, with your foot on You can also request a gear change using return to the sequential mode by selecting the brake pedal, you should: the gear lever.
  • Page 59 If the problem persist, have the system Have it checked by a PeugeOt dealer or a circumstances: checked by a PeugeOt dealer or a qualified workshop.

  • Page 60: Gear Shift Indicator

    Gearbox and steering wheel GEAR SHIFT INDICATOR* example: the information appears in the form of the word SHIFT in the instrument panel screen, You are in third gear. accompanied by an up arrow to changing System which reduces fuel consumption by You press the accelerator pedal recommending the most suitable gear.

  • Page 61: Starting And Stopping

    "winter" type fuel suited If this warning lamp comes to low or minus temperatures. on, use another key and have the faulty key checked by a PeugeOt dealer. Diesel pre-heating warning lamp Door or bonnet open warning lamp With the parking brake applied...

  • Page 62: Hill Start Assist

    In StOP mode of Stop & Start, hill start the instrument panel. Contact a assist is inactive. PeugeOt dealer or a qualified workshop to have the system After 2 seconds, if the vehicle has not checked.

  • Page 63: Stop & Start

    Starting and stopping STOP & START Automatic stopping of the engine is Special cases: STOP mode unavailable only possible after the vehicle has the StOP mode is not invoked when: the Stop & Start system puts the engine exceed a speed of about 6 mph (10 km/h), the driver's door is open, temporarily into standby - StOP mode - to avoid repeated stopping of the engine...
  • Page 64 Starting and stopping Going into engine START mode Special cases: START invoked Good practice automatically the "S" warning lamp goes off and With a manual gearbox in StOP mode, if a the StARt mode is invoked automatically the engine starts: gear is engaged without fully depressing the when: clutch pedal, restarting may not take place.
  • Page 65 (active or inactive) after switching of (reference numbers available from a and restarting the engine with the key. PeugeOt dealer or a qualified workshop). Fitting a battery not listed by PeugeOt introduces the risk of malfunction At any time, press the "S - OFF" switch to of the system.

  • Page 66: Front Seats

    Seats FRONT SEATS Head restraints Head restraint height adjustment: to raise or lower the head restraint, slide it by pressing the lug. the adjustment is correct when the upper edge of the head restraint is level with the top of the head. to remove the head restraint, release the base of the rod to press the tab and raise the head restraint to the highest position.

  • Page 67: Comfort

    Seats Lumbar support Armrest Forwards-backwards adjustment lift the control bar and slide the seat turn the control. the driver's seat may be fitted with an forwards or backwards to the required armrest on the centre console side. position. Raise or lower completely the armrest to obtain the most comfortable driving position.

  • Page 68: Folding Front Passenger Seat

    Seats FOLDING FRONT PASSENGER SEAT Table position Folded position After placing the seat back in the table Press the head restraint to place it in the Only move the seat when the rear position, pull the seat's rear strap while lowest position.

  • Page 69: Rear Bench Seat

    Seats ONE-PIECE REAR BENCH SEAT Table position Removing the bench seat Press the head restraint and its lug After placing the bench seat in the fully simultaneously to place the head restraint in folded position, lower the transverse bar to the low position.
  • Page 70 Seats Returning the bench seat to its position Returning the bench seat to the sitting Rear head restraints position Put the bench seat in place in its front the rear head restraints can be removed lift the bench seat back. anchorages in the fully folded position.
  • Page 71 Seats SPLIT REAR BENCH SEAT Removing the bench seat the left-hand side (2/3) or right-hand After placing the bench seat in the fully side (1/3) of this bench seat can be folded to folded position, lower the corresponding adapt the load space in the boot. transverse bar to unlock the front feet of the seat.
  • Page 72 Seats Returning the bench seat to its position Returning the bench seat to the sitting position Put the bench seat in place in its front lift the bench seat back. anchorages in the fully folded position. take care not to trap the seat belts. Fold the bench seat to the table position, lock the seat back by pushing it fully the front and rear feet of the seat lock...

  • Page 73: Demisting And Defrosting

    Ventilation DEMISTING AND DEFROSTING Windscreen Manual mode Rear screen and mirrors defrosting the vents located at the base of the turn the control to this air this function only operates when windscreen and the side vents for the side distribution setting. the engine is running.
  • Page 74 Ventilation VENTILATION Recommended interior settings Heating or Manual air conditioning I require... Air recirculation/ Air distribution Air flow Temperature Manual AC Intake of exterior air COLD DEMISTING DEFROSTING...

  • Page 75: Air Conditioning

    If the system does not produce cold air, do the air conditioning is useful in all seasons not use it and contact a PeugeOt dealer or as it eliminates condensation and air a qualified workshop. humidity.
  • Page 76 Ventilation Air flow the air flow fan setting varies from 1 to the strongest 4. Adjust this control in order to reach the desired level of comfort. to switch off the fan, place the control in position 0. Air distribution the air distribution is varied by turning the control turned towards:...
  • Page 77 Ventilation Intake of exterior air this is the preferred operating position. Recirculation of interior air this position should only be temporary. used with the air conditioning switched on and using the appropriate air fan setting (from 1 to 4), recirculation enables you to obtain the desired level of comfort with either hot or cold settings.

  • Page 78: Front Fittings

    Practical information FRONT FITTINGS Smoker's kit Folding writing table located at the base of the centre console, (Light van) this consists of a cigarette lighter and an ashtray. this is located in the centre of the dashboard. In the absence of a table, the vehicle is fitted with a storage compartment.
  • Page 79 Practical information Glove box Sun visor Spectacles storage (Combi) to open it raise the handle. to avoid glare from ahead, fold and direct there is a spectacles storage compartment It can accommodate a laptop computer. the sun visor down. on the driver's side, above the door. It provides storage for the handbook pack.

  • Page 80: Load Space Fittings

    Practical information the torch's storage batteries recharge automatically while driving. An additional lamp is fitted in the middle LOAD SPACE FITTINGS Storage pocket of the torch housing (refer to the "Interior lighting" section). A storage pocket is provided at the rear left Carrying passengers in the load space of the load space.
  • Page 81 Practical information Modular vertical grille A two-part partition grille is available. Operations: Associated with the folding front passenger 1. Place the passenger seat in the folded 3. lift the catch, located at the lower part of seat, the grille increases the driver's safety position.

  • Page 82: Rear Fittings

    Practical information Rear shelf unfold the shelf to conceal the contents of the boot from view. Fold the shelf back on itself for easier access to the contents of the boot. Stow the shelf behind the rear bench seat when loading bulky items vertically. Removing the shelf Fold the shelf back on itself.

  • Page 83: Torch

    Practical information Retaining straps Torch there are two retaining straps on the left- A magnetic torch is provided on the right- hand side of the boot. hand side of the boot. they secure the tool kit. Remove the torch from its base by pressing the button then pivoting the torch downwards by 90 degrees.

  • Page 84: Interior Lighting

    Practical information Rear courtesy lamp Boot lamp this is located on the upper part of the rear this is located in the centre of the torch right side. base. INTERIOR LIGHTING Press the side of the courtesy lamp lens to the lamp operates in accordance with the switch it on or off.

  • Page 85: Trip Computer

    Trip computer TRIP COMPUTER using the TRIP button, located at the end of If tRIP B is activated in the vehicle Press the SET / Back button for more than the wiper stalk, you can display the following configuration menu: two seconds to return to the home screen.

  • Page 86: Vehicle Configuration

    Vehicle configuration CONFIGURATION / PERSONALISATION OF THE VEHICLE Level 1 screen Level 2 screen Control panel - Speed (speed beep). Refer to the corresponding line of the the side control panel located beside the configuration - personalisation table on the steering wheel provides access to screen - time (Setting the time).
  • Page 87 Vehicle configuration This button enables you to: This button enables you to: - scroll up through a menu, - access the menus and - increase a value. sub-menus, - confirm your selections within a menu, - exit from the menus. This button enables you to: - scroll down through a menu, A long press enables you to return to the...
  • Page 88 Vehicle configuration Confirm Menu... Press... Sub-menu... Press... Select... Enables you to... and exit Display the name of the station. 5 See radio Display the CD track number. Activate/Deactivate the 6 Autoclose While moving automatic locking of the doors above 12 mph (20 km/h) Select the distance display Distances unit.
  • Page 89 Vehicle configuration Confirm Menu... Press... Sub-menu... Press... Select... Enables you to... and exit Display the miles/kilometres remaining before the next oil change. (Km/Miles before 11 Service oil change) Display the engine oil level. Activate the passenger's front airbag. 12 Bag p Deactivate the passenger's front airbag.

  • Page 90: Rear Parking Sensors

    An object, such as a stake, a roadworks signal becomes continuous. screen, contact a PeugeOt dealer or a cone or any other similar object may be this function will be deactivated qualified workshop.

  • Page 91: Audio Equipment

    Audio equipment Requires a FIRST STEPS Selection of the AM waveband. long press. use the left/right arrows for an automatic station search. Control panel use the up/down arrows for a manual station search. Setting the audio options: bass, treble, fader (front/rear), balance (left/right), loudness, eQ Preset (equaliser).

  • Page 92: Steering Mounted Controls

    Audio equipment FIRST STEPS RADIO: select the next preset station down. Steering CD: select the previous track. mounted Increase volume. controls CD MP3: select the previous folder. Mute On / Off. Change audio source: RADIO / CD / CD MP3. Select waveband: FM1 / FM2 / FMt / MW / lW.
  • Page 93 Audio equipment The volume of the traffic information is "AUDIO FUNCTIONS" MENU "MP3" appears on the display if the function independent of the volume of the other sources. is activated and the CD contains tracks in Press the MENU button You can adjust it using the volume button during the MP3 format.
  • Page 94 Audio equipment PLAYING A CD OR AN MP3 COMPILATION the MP3 format, an abbreviation of MPeg 1.2 & 2.5 Audio layer 3, is an audio compression standard which permits the Insert circular compact discs only. recording of several tens of music files on a single disc. Some anti-pirating systems, on original discs or CDs copied using a personal recorder, may cause faults which are no reflection on the...

  • Page 95: Bluetooth Hands-Free System

    Bluetooth hands-free system BLUETOOTH HANDS-FREE SYSTEM INTRODUCTION this system allows you to: ® - send and receive calls via the Bluetooth connection with your mobile telephone, - display the names of your contacts and numbers from the directory of your mobile phone in the instrument panel screen, - use voice commands to make a call and manage your contacts while keeping both hands on the steering wheel, - hear your text messages via the voice synthesiser built into the system, - listen to MP3, WMA, AAC, M4A, MP4 and WAV audio files from a uSB storage device,...
  • Page 96 Bluetooth hands-free system PRESENTATION Display, USB port, controls...
  • Page 97 Bluetooth hands-free system PRESENTATION Description of the steering mounted controls - Activate the main menu. - Confirm the current menu option. Display of the menus and directories of the files - Accept the incoming call. being played (uSB storage device). - Switch one telephone conversation to another.
  • Page 98 Bluetooth hands-free system PRESENTATION Description of voice commands By pressing this button and saying "Help", you have access to the list of voice commands available at any time or by saying "Help" after a system message. You can access the main menu of the system via the voice command by pressing this button. the main voice commands for navigating in the menu are the following: lASt CAllS HeNRY BRIDgeS...
  • Page 99 Bluetooth hands-free system MOBILE TELEPHONE WITH HANDS-FREE FUNCTION Pairing a mobile telephone When prompted by the telephone, enter the "Settings"\wait for a PIN displayed in the instrument panel. Pairing consists of setting your vehicle's response\"Pairing". If the pairing has been successful, the Bluetooth ®...
  • Page 100 Bluetooth hands-free system Downloading your phonebook Calling a contact recorded in the "Call [Name of the person]"\ phonebook wait until the information relating There are 2 options: to the person (name, tel. n°, ...) Your telephone's phonebook must first be 1 - Following the pairing procedure, the downloaded into the system.
  • Page 101 Bluetooth hands-free system Making a call by dialling a number Ending a call Incoming call If the person is recorded in Press and hold. By means of the voice commands only the phonebook, his name is displayed. "Dial/Dial a number"\ Say the number character by Press to accept the call.
  • Page 102 Bluetooth hands-free system Transferring an active call Call list "Callback" for the last person who There are 2 options: this enables you to call the number of one called you, or 1 - From the mobile telephone to the hands- of the last 10 calls received, of one of the "Redial"...
  • Page 103 Bluetooth hands-free system VOICE COMMANDS Settings/pairing the key words which can be recognised by the system are organised into three levels (levels 1, 2 and 3). When you say a level 1 command, the system makes the level 2 commands available; when you say a level 2 command, the system makes the level 3 commands available.
  • Page 104 Bluetooth hands-free system VOICE COMMANDS Mobile telephone with hands-free function the key words which can be recognised by the system are organised into three levels (levels 1, 2 and 3). When you say a level 1 command, the system makes the level 2 commands available; when you say a level 2 command, the system makes the level 3 commands available.
  • Page 105 Bluetooth hands-free system TEXT READER Only on mobile telephones with this Read the last text received List of text messages function the system can hold around 20 text Activate the main menu. If your mobile telephone includes this messages. If the list is full, reception of a function, every time a text message is new text message causes the deletion of the received, the system produces an audible...
  • Page 106 Bluetooth hands-free system Deleting all text messages Information settings Select the desired text message. Activate the main menu. Activate the main menu. Confirm to read the text message. Select MeSS. ReADeR. Select Delete All. Confirm. "Message reader" then after the Confirm.
  • Page 107 Bluetooth hands-free system VOICE COMMANDS Message reader the key words which can be recognised by the system are organised into three levels (levels 1, 2 and 3). When you say a level 1 command, the system makes the level 2 commands available; when you say a level 2 command, the system makes the level 3 commands available.
  • Page 108 Bluetooth hands-free system Level 1 Level 2 Level 3 Actions Activation of the MeSS. ReADeR menu. Deactivation of the info settings function. Deactivate reader / Reader not active / Deactivates the reading of text messages. Reader off Read messages / type of info / Info Visual and audible Messages...
  • Page 109 Bluetooth hands-free system PORTABLE AUDIO DEVICE PLAYER Audio tracks in .mp3, .wma, .wav format Autoplay Selecting tracks and playlists with the extension .wpl are Activate the main menu. Activate the main menu. recognised by the system. USB port Select MeDIA PlAYeR. Select SettINgS then MeDIA Connect the device to the PlAYeR then tRACK PlAY.
  • Page 110 Bluetooth hands-free system Previous track Changing the sound source Confirm. Pressing: Press to select the audio source (Radio, CD, Media player). - within 3 seconds following the start of Select the file. play enables you to play the previous track. - after 3 seconds enables you to listen to the current track again.
  • Page 111 Bluetooth hands-free system VOICE COMMANDS Portable audio device the key words which can be recognised by the system are organised into three levels (levels 1, 2 and 3). When you say a level 1 command, the system makes the level 2 commands available; when you say a level 2 command, the system makes the level 3 commands available.
  • Page 112 Bluetooth hands-free system Level 1 Level 2 Level 3 Actions Activation of the MeDIA PlAYeR menu. Advanced uSB options/Other options Activation of playback options. Folder/explore folders/Consult list of Activation of FOlDeRS menu. folders Player/Multimedia Artists/list of artists Activation of ARtIStS menu. player/Media player / Player genres/list of...

  • Page 113: Parking Brake

    Driving safely PARKING BRAKE HAZARD WARNING LAMPS Applying Pull on the parking brake lever, only with Press this button, the two direction the vehicle stationary. indicators flash. Pull the parking brake lever up to immobilise In the exceptional case of use of the parking they operate with the ignition off.

  • Page 114: Horn

    You must stop as soon as it is safe to do so. Activation the anti-lock braking system comes into In either case, contact a PeugeOt dealer operation automatically when there is a risk or a qualified workshop. of wheel lock.

  • Page 115: Trajectory Control Systems

    ASR system, so that the deactivated automatically. wheels can spin freely and regain grip. Have it checked by a PeugeOt dealer or a qualified workshop. * Depending on country of sale.
  • Page 116 ASR the correct functioning of this system system, which is deactivated automatically. depends on observation of the Have the system checked by a PeugeOt manufacturer's recommendations regarding dealer or a qualified workshop. the wheels (tyres and rims), the braking components, the electronic components and assembly and repair procedures.
  • Page 117 Driving safely Intelligent Traction Control Deactivation Press this button, located in the side control System to improve traction on slippery panel alongside the steering wheel to surfaces (snow, black ice, mud...) deactivate the system. this system checks for situations of difficult the warning lamp in the instrument panel surface adhesion that could make it difficult goes off and the ASR system is active again.

  • Page 118: Tyre Under-Inflation Detection

    Driving safely TYRE UNDER-INFLATION DETECTION the under-inflation detection system Under-inflation alert does not replace the vigilance or the This is given by fixed System which automatically checks the responsibility of the driver. illumination of this warning lamp, pressure of the tyres while driving. this system does not avoid the need to accompanied the display of a the system monitors the pressures on the...
  • Page 119 Before reinitialising the system, ensure tyres is no longer assured. that the pressures of the four tyres Have the system checked by a PeugeOt are correct for the use of the vehicle and in dealer or a qualified workshop. line with the recommendations on the tyre F With the ignition on and the vehicle pressure label.

  • Page 120: Seat Belts

    Seat belts Driver's seat belt not fastened warning FRONT SEAT BELTS Inertia reel seat belts lamp the front seats are fitted with pre-tensioners these are fitted with a device which locks When the vehicle is started, this and force limiters. automatically in the event of a collision or warning lamp comes on if the emergency braking.

  • Page 121: Seat Belts

    Have the seat belts checked regularly (even be tightened as close to the body as after a minor impact) by a PeugeOt dealer possible. or a qualified workshop: they must not show the upper part of the seat belt should be...

  • Page 122: Airbags

    Airbags Airbags only operate when the ignition is switched on. this equipment only operates once. If a second impact occurs (during the same or a subsequent accident), the airbag will not operate. the deployment of an airbag or airbags is accompanied by a slight discharge of smoke and some noise, due to the activation of the pyrotechnic cartridge incorporated in the...
  • Page 123 Airbags Operating fault If this warning lamp comes on in the instrument panel, contact a PeugeOt dealer or a qualified workshop without delay to have the system checked. the airbags may no longer be deployed in the event of a serious impact.
  • Page 124 If the two airbag warning lamps are on continuously, do not install a rearward facing child seat. Have it checked by a PeugeOt dealer or a qualified workshop.

  • Page 125: Airbags

    Never remove or pierce the steering wheel systems checked. or hit it violently. All work on the airbag systems must be carried out by a PeugeOt dealer or a qualified workshop. Lateral airbags even if all of the precautions mentioned are...

  • Page 126: Child Seats

    Child safety GENERAL POINTS RELATING TO CHILD SEATS PEUGEOT recommends that children Although one of PeugeOt main criteria when designing your vehicle, the safety of should travel on the rear seats of your your children also depends on you. vehicle: "rearward-facing"...
  • Page 127 Child safety CHILD SEAT AT THE REAR (COMBI) "Rearward facing" "Forward facing" When a "rearward facing" child When a "forward facing" child seat is installed on a rear seat is installed on a rear passenger seat, move the passenger seat, move the vehicle's front seat forwards vehicle's front seat forwards and straighten the backrest so that the...
  • Page 128 Child safety CHILD SEAT IN THE FRONT* "Rearward-facing" "Forward-facing" When a "rearward-facing" child When a "forward-facing" child seat is installed on the front seat is installed on the front passenger seat, adjust the passenger seat, adjust the seat vehicle's seat to the intermediate to the intermediate longitudinal and highest position, with the backrest longitudinal and highest position with...

  • Page 129: Deactivating The Passenger'sfront Airbag

    Passenger airbag OFF the child seat function is shared by For information on deactivating the the entire PeugeOt range. However, passenger's front airbag, refer to the each individual model has its own special "Airbags" section.
  • Page 130 Child safety Bg НИКОГА НЕ инсталирайте детско столче на седалка с АКТИВИРАНА предна ВЪЗДУШНА ВЪЗГЛАВНИЦА. Това може да причини СМЪРТ или СЕРИОЗНО НАРАНЯВАНЕ на детето. CS NIKDY neumisťujte dětské zádržné zařízení orientované směrem dozadu na sedadlo chráněné AKTIVOVANÝM čelním AIRBAGEM. Hrozí nebezpečí...
  • Page 131 Child safety NIEKADA neįrenkite vaiko prilaikymo priemonės su atgal atgręžtu vaiku ant sėdynės, kuri saugoma VEIKIANČIOS priekinės ORO PAGALVĖS. Išsiskleidus oro pagalvei vaikas gali būti MIRTINAI arba SUNKIAI TRAUMUOTAS. lV NEKAD NEuzstādiet uz aizmuguri vērstu bērnu sēdeklīti priekšējā pasažiera sēdvietā, kurā ir AKTIVIZĒTS priekšējais DROŠĪBAS GAISA SPIlVeNS.
  • Page 132 Child safety CHILD SEATS RECOMMENDED BY PEUGEOT PeugeOt offers a range of recommended child seats which are secured using a three point seat belt. Group 0+: from birth to 13 kg "RÖMeR Baby-Safe Plus" Installed in the rearward facing position.
  • Page 133 Child safety INSTALLING CHILD SEATS ATTACHED USING THE SEAT BELT (LIGHT VAN) In accordance with european regulations, this table indicates the options for installing child seats secured using a seat belt and universally approved in accordance with the weight of the child and the seat in the vehicle: Weight of the child and indicative age Under 13 kg From 9 to 18 kg...
  • Page 134 Child safety INSTALLING CHILD SEATS ATTACHED USING THE SEAT BELT (COMBI) In accordance with european regulations, this table indicates the options for installing child seats secured using a seat belt and universally approved in accordance with the weight of the child and the seat in the vehicle. Weight of the child and indicative age Under 13 kg From 9 to 18 kg...
  • Page 135 Remember to fasten the seat belts or the installing a child seat with a backrest on the PeugeOt recommends the use of a child seat harnesses keeping the slack passenger seat. booster seat which has a back, fitted with a...

  • Page 136: "Isofix" Mountings

    Child safety "ISOFIX" MOUNTINGS Your vehicle has been approved in the ISOFIX child seats are fitted with two the incorrect installation of a child seat accordance with the latest ISOFIX latches which are secured easily on the two in a vehicle compromises the child's regulation.
  • Page 137 Child safety ISOFIX CHILD SEAT RECOMMENDED BY PEUGEOT AND APPROVED FOR YOUR VEHICLE (COMBI) RÖMER BabySafe Plus ISOFIX (size category E) Group 0+: up to 13 kg It is installed in the rearward facing position using an ISOFIX base which attaches to the rings A.
  • Page 138 Child safety LOCATIONS FOR THE INSTALLATION OF ISOFIX CHILD SEATS (COMBI) In accordance with european regulations, this table indicates the options for the installation of ISOFIX child seats on the vehicle seats fitted with ISOFIX mountings. In the case of the universal and semi-universal ISOFIX child seats, the child seat's ISOFIX size category, determined by a letter from A to G, is indicated on the child seat next to the ISOFIX logo.
  • Page 139 Towing a trailer TOWING A TRAILER, CARAVAN, ETC... Driving advice A towed vehicle must free wheel: gearbox in As the fan is electrically controlled, its In all cases, pay attention to the coolant neutral. cooling capacity is not dependent on the temperature.
  • Page 140 PeugeOt dealer or a qualified workshop. Rear parking sensors: the sensors will be If this equipment is not fitted by a PeugeOt deactivated automatically when an genuine dealer, it is essential that it is fitted using PeugeOt towbar is used.

  • Page 141: Roof Rack And Roof Bars

    Please note this specific warning. You tested and approved both for reliability and are advised to contact a representative for safety. of PeugeOt to be shown the range of they all benefit from PeugeOt's recommended equipment and accessories. recommendation and warranty.

  • Page 142: Accessories

    "Transport solutions": "Protection": By going to a PeugeOt dealer, you can also obtain cleaning and maintenance boot liner, rear door net, set of transverse rubber mats, over-carpets, 3D mats, seat products (interior and exterior) - and longitudinal roof bars, roof boxes...
  • Page 143 Research and Development and PeugeOt teams work together to develop high quality lubricants that meet the requirements of PeugeOt vehicles. For you, this is the assurance that the performance of your engine is optimised while also ensuring its durability.

  • Page 144: Battery

    Fuel FILLING WITH FUEL FUEL CUT-OFF Capacity of the fuel tank: approximately 45 litres. In the event of a serious collision, a device automatically cuts off the fuel supply to the Low fuel level engine and the vehicle's electrical supply. It also automatically unlocks the doors When the minimum fuel tank level and switches on of the courtesy lamps.
  • Page 145 Diesel engines; however, this use is subject to strict application of the special servicing conditions indicated in the warranty and maintenance record. Contact a PeugeOt dealer or a qualified workshop. the use of any other type of (bio)fuel (vegetable or animal oils, pure or diluted, domestic fuel...) is strictly prohibited (risk of...

  • Page 146: Opening The Bonnet

    Opening the bonnet OPENING THE BONNET On the inside On the outside Pull the release lever below the dashboard Raise the bonnet slightly, placing your hand towards you. flat under the bonnet to make the operation easier. Push the safety catch lever to the left, then open the bonnet fully.

  • Page 147: Diesel Engine

    Under the bonnet DIESEL ENGINE take care when doing anything under the bonnet. 1. Screenwash reservoir. 2. Fusebox. 3. engine coolant header tank. 4. Brake and clutch fluid reservoir. 5. Air filter. 6. Dipstick. 7. engine oil filler cap. 8. Power steering fluid reservoir.

  • Page 148: Petrol Engine

    Under the bonnet PETROL ENGINE take care when doing anything under the bonnet. 1. Screenwash reservoir. 2. Fusebox. 3. engine coolant header tank. 4. Brake and clutch fluid reservoir. 5. Air filter. 6. Dipstick. 7. engine oil filler cap. 8. Power steering fluid reservoir.
  • Page 149 Ask for advice from a PeugeOt dealer or a use fluids recommended by the manufacturer's servicing schedule. Ask qualified workshop or refer to the warranty...
  • Page 150 PeugeOt dealers (France) or at an Screenwash fluid level stopped before carrying out any work. authorised waste disposal site.

  • Page 151: Brakes, Pads

    At the start of winter, have your battery Brake pad wear depends on the type of Bleeding water from the Diesel filter checked by a PeugeOt dealer or a driving, in particular for vehicles which are qualified workshop. used in town, over short distances. It may...
  • Page 152 In order to optimise the operation of units as important as the braking system, PeugeOt selects and offers specific products. In order to avoid damaging the electrical units, high pressure washing to clean the engine compartment is strictly prohibited.

  • Page 153: Particle Filter

    / particle filter system. accumulated and the driving conditions this alert tells you that the Have it checked by a PeugeOt dealer or a of the vehicle. During this phase, you particle filter is starting to fill up (in qualified workshop.

  • Page 154: Battery

    Battery Starting using another battery Connect the red cable to the positive battery terminal A on your vehicle then to the positive (+) terminal of the slave battery B. Connect one end of the green or black cable to the negative (-) terminal of the slave battery B.
  • Page 155 Battery Follow the instructions for use provided by the battery charger manufacturer. Check that the battery posts and terminals are clean. If they are covered with sulphate (white or greenish deposit), disconnect them and clean them. Reconnect connector F of the check sensor G.
  • Page 156 E to systems to be initialised. If difficulties are disconnect connector F, experienced after this, contact a PeugeOt the presence of this label, in particular disconnect connector F of check dealer or a qualified workshop.

  • Page 157: Changing A Wheel

    Changing a wheel CHANGING A WHEEL Tools Taking out the spare wheel the tools required are stored in a tool kit the spare wheel retaining bolt is located on Parking the vehicle located behind the driver's seat (light van) the rear left part of the loading sill. As far as possible, park the vehicle on level, or behind the rear bench seat (Combi).
  • Page 158 Changing a wheel Removing a wheel 1. Park the vehicle on level, stable and non- 4. Position the jack underneath the body, slippery ground. Apply the parking brake. in accordance with the illustration, at the Switch off the ignition and engage first mark A (on the sill) as close as possible gear or reverse, depending on the slope.
  • Page 159 PeugeOt dealer or a qualified workshop without delay. Also, have the original wheel repaired and refitted by a PeugeOt dealer or a qualified workshop as soon as possible. Fitting a wheel 1. Put the wheel in place using the centre 6.

  • Page 160: Temporary Puncture 146 Repair Kit

    Start the engine. passenger compartment. It consists of: available from PeugeOt dealers. Insert the connector G in the nearest a repair cartridge A, containing the It is provided for the repair of holes of 12 V accessory socket in the vehicle.
  • Page 161 Checking and correcting the pressure Replacing the repair cartridge be repaired, ● contact a PEUGEOT dealer or a qualified For checking and correcting the pressure of Disconnect the pipe I. workshop. a tyre, use the compressor as follows:...

  • Page 162: Snow Chains

    (50 km/h). F Stop your vehicle and check that the snow chains are correctly tightened. For more information on snow chains, contact a PeugeOt dealer or a qualified It is recommended that before you workshop. leave, you practise fitting the snow chains on a level and dry surface.

  • Page 163: Changing A Bulb

    Changing a bulb CHANGING A BULB Types of bulb Various types of bulb are fitted on your vehicle. to remove them: 1. Type A entirely glass bulb: pull gently as it is fitted by pressure. 2. Type B Bayonet bulb: press on the bulb then turn it anticlockwise.
  • Page 164 Type D, H4 - 55 W Type D, H4 - 55 W Type E, H1 - 55 W Remove the cover by turning it Remove the cover by turning it Contact a PeugeOt dealer or a qualified anticlockwise. anticlockwise. workshop. Disconnect the electrical connector.

  • Page 165: Side Repeater

    Changing a bulb Direction indicator side repeaters Front/rear courtesy lamps Type A, WY 5 W - 5 W amber Type C, 12 V 10 W - 10 W Push the repeater rearwards and release it. Release the courtesy lamp using a screwdriver.

  • Page 166: Number Plate Lamps

    Changing a bulb Identify the faulty bulb then open the rear doors. unscrew the two screws using the screwdriver supplied in the tool kit (behind the driver's seat) and extract the bulb holder. Release the lamp unit. Disconnect the electrical connector. Remove the support by moving aside the tabs.
  • Page 167 Remove the bulb holder by squeezing the Remove the bulb holder by squeezing the two tabs. two tabs. Remove the faulty bulb. Remove the faulty bulb. Change the bulb. Change the bulb. If you encounter any difficulty, consult a PeugeOt dealer or a qualified workshop.

  • Page 168: Changing A Wiper 151 Blade

    Changing a wiper blade CHANGING A WIPER BLADE Changing a front or rear wiper blade Instructions for removing the blade: Instructions for fitting the blade: lift the wiper arm A off the windscreen. Fit the pivot C in the hole in the central part turn the blade B 90°...

  • Page 169: Changing A Fuse

    If a fuse fails again soon after replacement, Access to fuses in the engine have the electrical system of your vehicle compartment checked by a PeugeOt dealer or a For access to the fuses in the engine qualified workshop. compartment, remove the left hand front headlamp connector, then unclip the fusebox cover.
  • Page 170 Changing a fuse Table of dashboard fuses, driver’s Marking Rating Functions side 7.5 A Right-hand dipped beam headlamp supply left-hand dipped beam headlamp supply - headlamp height 7.5 A adjuster engine control unit supply switch 7.5 A Front lamp - front courtesy lamp - rear courtesy light lamp Audio system - mobile telephone pre-equipment - 10 A air conditioning control panel - eODB diagnostic socket...
  • Page 171 Changing a fuse Marking Rating Functions 7.5 A Door mirror demisting. 15 A Cigar lighter. 15 A 12 V accessory socket. 10 A Heated seat, driver’s side. 10 A Heated seat, passenger’s side.
  • Page 172 Changing a fuse Table of fuses in the engine Marking Rating Functions compartment 60 A Control unit. 40 A Passenger compartment fan. 20 A Starter motor supply. 40 A ABS hydraulic block pump supply. 30 A Single speed cooling fan control. 40 A High speed cooling fan control.
  • Page 173 Changing a fuse Marking Rating Functions engine management control unit - electronic gearbox control unit and gear lever - 7.5 A t20 relay coil 15 A Supply for ignition coil - injectors - engine management control unit (1.3 HDi) Engine management control unit (1.3 HDi) - T09 relay coil 7.5 A 7.5 A Air conditioning compressor...

  • Page 174: Towing The Vehicle

    Being towed or towing General recommendations Observe the legislation in force in your country. ensure that the weight of the towing vehicle is higher than that of the towed vehicle. the driver must remain at the wheel of the towed vehicle and must have a valid driving licence.

  • Page 176: Dimensions

    Dimensions...
  • Page 177 Dimensions DIMENSIONS the light van "l1" is the standard model, the "l2 - Worksite Pack" version is a model sold according to country. Light van (in mm) l2 (Worksite Pack) 3 864 3 881 Overall length Overall height 1 721 1 742 1 782 1 803...
  • Page 178 Dimensions...
  • Page 179 Dimensions Combi (in mm) Standard All-terrain 3 959 3 970 Overall length Overall height 1 721 1 742 1 782 1 803 Height with roof bars Wheelbase 2 513 Front overhang Rear overhang 2 019 Overall width 1 816 Width (with mirrors folded) Width of front track 1 464 Width of rear track...
  • Page 180 Dimensions...
  • Page 181 Dimensions Combi (in mm) Standard All-terrain 3 959 3 970 Overall length Overall height 1 721 1 742 1 794 1 803 Height with roof bars Wheelbase 2 513 Front overhang Rear overhang 2 019 Overall width 1 816 Width (with mirrors folded) Width of front track 1 464 Width of rear track...

  • Page 182: Engines

    Engines DIESEL ENGINES 1.4 litre HDi 70 hp 1.3 litre HDi 75 hp Gearboxes Manual Manual Electronic gears eu standard maximum power (kW)* 1 399 1 248 Cubic capacity (cc) 73.7 x 82 69.6 x 82 Bore x stroke (mm) Max power engine speed (rpm) 4 000 3 750...
  • Page 183 Engines PETROL ENGINE 1.4 litre 75 hp Gearbox Manual gears eu standard maximum power (kW)* Cubic capacity (cc) 1 360 Bore x stroke (mm) 75 x 77 Max power engine speed (rpm) 5 200 eu standard max torque (Nm) Max torque engine speed (rpm) 2 600 Fuel unleaded petrol...

  • Page 184: Weights

    (comply with the legislation in force in For information on the maximum trailer weight without tools). your country). for your vehicle, contact a PeugeOt dealer or a qualified workshop. GVW: gross vehicle weight, the maximum authorised vehicle weight. GTW: gross train weight, the maximum...

  • Page 185: Identification Markings

    Identification markings IDENTIFICATION MARKINGS A. Manufacturer's plate B. Serial number on the body 1. VF type serial number. C. Paint code 2. gross vehicle weight (gVW). D. Serial number on the dashboard 3. gross train weight (gtW). 4. Maximum weight on front axle. E.
  • Page 191 PeugeOt dealer is able to provide. the descriptions and illustrations are Automobiles PeugeOt declares, by given without any obligation. Automobiles application of the provisions of the european...
  • Page 192 Anglais AN. 14BIP.0041 www.peugeot.com...

Table of Contents
