Changing a fuse
PASSENGER'S SIDE DASHBOARD FUSES
-
Remove the bolts and tilt the box to access the fuses.
Fuses
A (amps)
12
7.5
Right-hand dipped beam headlamp
13
7.5
Left-hand dipped beam headlamp
31
7.5
Relay supply
32
10
Cab lighting
33
15
Rear 12 V socket
34
-
Not used
Reversing lamps - Water in Diesel fuel sensor
35
7.5
36
15
Central locking control - Battery
37
7.5
Brake lamps switch - Third brake lamp - Instrument panel
38
10
Central locking
Audio system - Diagnostic socket - Alarm siren - Programmable additional heating controls - Air conditioning
39
10
controls - Tachograph - Battery
40
15
Heated: rear screen (left hand), driver's side mirror
41
15
Heated: rear screen (right hand), passenger's side mirror
42
7.5
ABS control unit and sensor - ASR sensor - ESP sensor - Brake lamps switch
43
30
Windscreen wiper motor
44
20
Cigarette lighter - 12 V socket
45
7.5
Door controls
46
-
Not used
47
20
Driver's electric window motor
48
20
Passenger electric window motor
Audio system - Instrument panel controls - Driver's electric window
49
7.5
50
7.5
Airbags and pre-tensioners unit
51
7.5
Tachograph - Cruise control - Air conditioning controls
52
7.5
Optional relay supply
53
7.5
Instrument panel - Rear foglamp
Allocation
