Connecting your PTZ Camera (cont.)
1)
Connect the PTZ connection on the camera to
the PTZ connection on the video & power cable
(the connection is keyed so it connects in one
orientation). Connect the video output and power
input on the camera to the corresponding connec-
tions on the video & power cable.
2)
Connect the video output on the video & power
cable to a spare video input on the DVR.
3) Disconnect the PTZ module on your DVR. Using
a flat-head screwdriver, attach the PTZ wires (red
& black) to the PTZ module. The red cable con-
nects to "A" and the black cable connects to "B"
(as illustrated). Ensure the wires are held firmly
then tighten (don't use too much force). Recon-
nect the PTZ module to the DVR when finished.
4)
Connect the power input on the video & power
cable to the provided power adapter. Connect the
power adapter to a spare power connection.
When the camera is turned on, it will initialise
a self-test then display some information about
itself on-screen -
S/N: 201504031002
VERSION
MODEL
PROTOCOL :
DOME ID
BAUDRATE :
The DVR's default PTZ settings should allow you
to use the camera without any configuration.
However, there are many options that can be ac-
cessed using the DVR's menu as well as the on-
screen menu on the camera. Download our com-
prehensive user manual available at our website.
: V1.22AN
: DOME
PELCO
: 001
9600
