- Page 1 Installation guide...
-
Page 2: Table Of Contents
Index momit Home System Products presentation Characteristics Possible configurations Installation Additional content Gateway Thermostat Extension Kit Customise your device... -
Page 3: Momit Home System
Home System... -
Page 4: Products Presentation
Products presentation The momit Home system is made up of 3 devices: - Gateway - Thermostat - Extension Kit* Gateway Thermostat Extension Kit *Sold separately... -
Page 5: Characteristics
Home - LED status display devices. The Gateway makes it possible for you to control - Ethernet interface momit Home from your smartphone, tablet or computer - CE by means of the momit App. - RoHS... - Page 6 - Boiler control is to remove the current thermostat and - Temperature up/down, boiler on/off buttons fit the momit Home Thermostat. - iOS, Android, Windows Phone and Blackberry mobile APP - Platform registration by means of QR code - Power input 2 alkaline AA batteries - Wireless: IEEE 802.15.4...
- Page 7 Extension Kit Characteristics: This device enables momit Home Thermostat to control - An On/Off boiler button a boiler or underfloor heating wirelessly. - Platform registration by means of QR code - 110V/230V 50/60Hz power input - Wireless: IEEE 802.15.4 - 12A relay...
-
Page 8: Possible Configurations
Boiler heating systems: Gateway + Thermostat: This combination enables you to control your home heating at all times no matter where you are. The Gateway connects your heating system to Internet. Accordingly, you can control your thermostat by means of the momit App over your smartphone, tablet or computer. -
Page 9: Installation
Installation Warning! Read these instructions carefully before starting the installation. momit devices must be installed in accordance with current regulations. If you are going to install an Extension Kit, make sure that the power has been cut off before proceeding... -
Page 10: Additional Content
Additional content Gateway Thermostat Ethernet cable USB cable Power 2 AA 1.5V 2700 2 M3x30 2 raw plugs adapter mAh alkaline screws batteries Extension Kit 2 M3x30 2 raw plugs screws... -
Page 11: Gateway
On/Off Connect it to the mains by means of the USB cable (3). Connect the Ethernet cable (4) to the router in your home. Wait until the 3 status LEDs are on before continuing with the installation. -
Page 12: Thermostat
Thermostat Remove the connection box at the back of the Screw the connection box to the wall. Use the thermostat (part B). two screws that come in the pack to do so. Fit the connection wires as shown in the diagram: Connection diagram Insert the boiler connection wires through the gap in the part. - Page 13 If the wire is rigid you can insert it directly. Insert two AA batteries. When it is a flexible wire you may need the help of a punch or pen tip. Press as indicated in the drawing (1) and insert the wire (2). AA batteries 0.5-1.5mm 6-8mm...
- Page 14 Buttons Thermostat placement Raise the set temperature Lower the set temperature On/off mode Brightness mode 1.5 m Status LEDs Fit 1 m away 1.5 m high Away from on both sides sources of cold and heat Update in progress Gateway connection indicator Heating consumption indication...
-
Page 15: Extension Kit
Extension kit Connection diagram Insert the installation wires. You can do so in two ways: Case A: Case B: If the power wires If the power wires come come from the wall, from the boiler, insert insert them as follows: them as follows: 12A relay: Power input:... - Page 16 How to connect the wires: You are recommended to connect the power wires at the end. Take safety measures when working with electricity. Cut off the current in the area where you are working until you have completed the installation. - Extension Kit requires 110 to 230 VAC input.
- Page 17 Identify Power Make sure the power has been The Extension Kit requires 110 to 230 VAC cut off to the boiler when input. undertaking these operations. The power terminals from the boiler usually have L/N or P/N tags. Identify the thermostat LS-LR terminals in the boiler manual.
- Page 18 Buttons Status LEDs Device On/Off Manual boiler control whenever there is no Internet connection Reset Device connection indicator The device connection LED will be on if everything is working properly. The Extension Kit is connected to Gateway as of that moment.
-
Page 19: Customise Your Device
Customise your device momit Home Thermostat has interchangeable frames. Follow these steps to change the frame: Remove the cover and take out Insert a pen into the hole under Exert pressure until the front casing the batteries. the batteries. comes away and pull it out. - Page 20 Press the body of the thermostat backwards Position the new frame and, while in the while bringing the frame forward until it same position as in the previous step, push comes out. the frame until it fits flush. Put the front casing back by placing the bottom Push until it fits flush.
- Page 21 You can use momit Home over your smartphone, tablet or computer from the following URL: http://home.momit.com Download the momit App free of charge at: To begin to use it, follow the instructions in the User Manual you can find on our web site: www.momit.com...
- Page 22 CE Declaration of conformity Green momit, S.L. hereby declares that these devices are in compliance with the basic requirements and other relevant provisions of Directive 1999/5/EC. Safety Precautions These devices must be installed in accordance with current regulations. Only use with the power socket adapter supplied.
- Page 23 Copyright Green momit all rights reserved. Reproduction and distribution without the written permission of the company is prohibited.
