  • Page 1 SIMPLY CLEVER OWNER'S MANUAL OWNER'S MANUAL Amundsen and Bolero infotainment systems...
  • Page 2  3V0012720EB...
  • Page 4 Preface This manual is intended for the Bolero and Amundsen infotainment systems (hereinafter referred to only as Device). Please read these Operating Instructions carefully, because the operation in accordance with these instructions is a prerequisite for proper use of the unit.

  • Page 5: Table Of Contents

    Introductory information Important information about this manual ™ Android Auto Notes Apple CarPlay Abbreviations MirrorLink Introductory information Navigation (Amundsen) Important notes Navigation description Equipment overview New destination Device operation and settings My destinations Device operation Voice control Import my destinations...

  • Page 6: Important Information About This Manual

    This Owner's Manual is valid for the different versions of the Infotainment Bo- lero and Amundsen (hereinafter referred to only as device). The device may dif- fer depending on the vehicle model, in which it is installed in both its appear- ance and in the arrangement of the controls.

  • Page 7: Notes

    Information search Notes When searching for information in the Operating Instructions, we recommend using the Index at the end of the manual. Structure of these Operating Instructions The Operating Instructions are hierarchically divided into the following areas. Main chapters (e.g. Introductory information) - the title of the main chapter is ■...

  • Page 8: Abbreviations

    Abbreviation Definition Abbreviations a program identification of the radio station, which allows a PI code Abbreviation Definition group sort of radio stations planar map display personal identification number spatial map display a system for the transmission of additional information for FM radio reception ®...

  • Page 9: Introductory Information

    Information on use, updating and compatibility  Read and observe on page 6 first. Refer to the ŠKODA Internet pages http://infotainment.skoda-auto.com for information on the compatibility of external devices as well as software up- dates and navigation data. Component protection ...

  • Page 10: Equipment Overview

    - Unit menus display » page 8  Touch screen External module Fig. 2 External module: Bolero / Amundsen The external module is located in the storage compartment on the front pas- senger side. Fig. 1 Device Overview (Amundsen) SD1 card slot SD2 card slot ...
  • Page 11 With the ignition off, the device will automatically turn off after about 30 mi- Menu Telephone » page 30  nutes. Display of TMC traffic reports Traffic (Amundsen) » page 60  The device turns off automatically under certain circumstances. The device in- Menu SmartLink »...

  • Page 12: Device Operation And Settings

    Adjusting the volume Device operation and settings Every change in volume is displayed on the screen. Device operation Increase volume ›  Introduction Turn the control to the right.  This chapter contains information on the following subjects: Decrease volume ›...

  • Page 13: Fig. 5

    Slider - Position and movement in the menu (movement is possible by Alphanumeric with keyboard moving the slider down / up with the finger or by turning the control dial  left or right) Fig. 5 Menu item with “Checkbox”    Example of the keyboard display Open a submenu of the menu item with the “pop-up window”...

  • Page 14: Voice Control

    By pressing the function key  a list of matching entries opens . If less than 5 Function requirements entries were found, a list of the found entries opens automatically.  Read and observe on page 11 first. Voice control Function requirements for voice control.

  • Page 15: Multimedia Database - Information And Function Keys » Fig

    Activation of voice control is indicated by an acoustic signal and the device For example, the function button Dial number can be selected with the voice screen will display a collection of basic voice commands for the current menu. command “Dial number”. After switching on the voice control, the function buttons that can be selected Switching off voice control with a voice command are highlighted in green.
  • Page 16 Menu Radio Correction of a voice command input Voice command Operation  Read and observe on page 11 first.  Nearest station in the selected fre- Next station quency range A voice command can be corrected, modified or re-entered by pressing the button or the icon key ...

  • Page 17: Device Settings

    Voice command Operation Device Settings Show road signs on map Switch the traffic sign display in the  Introduction screen on/off Turn off road signs on map This chapter contains information on the following subjects: Show favourites Show or hide favourites icons in the Turn off favourites Sound Settings Screen settings...
  • Page 18 Press the key →  → Time and date. ■  volume) with activated parking aid Clock time source: - Time of the clock time source: Manual / GPS (Amundsen) ■ Off - Fading is not active ■ Time: - Time settings ■...
  • Page 19 ŠKODA Internet pages. Voice control session start tone - Switch on/off the audible signal when ■ http://infotainment.skoda-auto.com turning on the voice control ■ Voice control session end tone - Switch on/off the audible signal when voice...

  • Page 20: Radio Operation

    Main Menu - Information and function keys » Fig. 6 Radio The selected radio station (description or frequency) Radio Text (AM, FM) / Description of the group (DAB) Operation Preset station buttons for favourite channels  Introduction Choice of radio range (FM / AM / DAB) Choice of storage group for the preferred station This chapter contains information on the following subjects: Changing the station...

  • Page 21: List Of Available Stations

    › Alphabet - alphabetical order according to station name List of available stations › Group - Sort according to program identification of the broadcast program › Genre - Group sorting of stations according to genre (visible when RDS and AF functions are turned on »...

  • Page 22: Store Preferred Station

    Remove station logo Store preferred station › In the Radio menu, press the function key  → Station logos.  Read and observe on page 17 first. A menu with preset buttons for stations is displayed. › For each broadcasting range there are 15 preset buttons to store the preferred Press the preset button for the station, which a logo is to be removed from.

  • Page 23: Settings

    Radio DAB text and image presentation Settings › In the Radio menu, press the function key  . Fig. 8 Sound - Sound settings Station information ■ Scan - Auto-play all available stations in the current frequency band, each ■ station for around five seconds Arrow buttons: - Setting the function of the station change (function keys ...
  • Page 24 Auto-save station logos- Automatic storage of the station logos ■ DAB traffic announcements - Switch on/off DAB traffic announcements ■ Other DAB announcements - Switch on/off other announcements (e.g., ■ warnings, regional weather, sports reports, financial news) DAB - DAB station tracking - Switch on/off automatic DAB station tracking ■...

  • Page 25: Media Operation

    Depending on the audio source type:  Media › Folder / Title list › Multimedia database Operation Menu settings Media   Introduction Note This chapter contains information on the following subjects: Information concerning the given title appears on the screen, if they are stor- ■...

  • Page 26: Playback

    Playback Folder / track list The unit will play the contents of the connected audio source according to the Fig. 11 alphabetically sequenced directory and file name. Folder / Title list Operating modes Operation Action Play / Pause Press from  Press from ...

  • Page 27: Audio Sources

    ■ Sound - Sound settings Multimedia database Mix/repeat including subfolders - Switching the title display including sub- ■ directory Fig. 12 ® ■ Bluetooth - Settings for the Bluetooth function Multimedia database Remove safely: - safe removal of the audio source ■...

  • Page 28: Sd Card

    CAUTION SD card When using an SD card with an adapter, vehicle vibrations might cause the card to fall out of the adapter. Fig. 13 Insert the SD card (not applicable USB input for the Fabia model) Fig. 15 USB input Fig.

  • Page 29: Bluetooth Player

    Some connected audio sources may not be recognised and cannot be charged. AUX - input CAUTION Fig. 16 USB extension cords, or reducers may impair the function of the connected au- AUX input dio source. Note We recommend that you use extension cords from ŠKODA Original Accesso- ries.

  • Page 30: Supported Audio Sources And File Formats

    Supported audio file formats Supported audio sources and file formats Maximum  Codec type Max. bit Multi- Read and observe on page 24 first. File suffix sampling Play lists (File formats) rate channel rate Supported audio sources Windows Media File sys- Source Interface Type...

  • Page 31: Pictures

    Display the initial image size while retaining the aspect ratio   Introduction Guidance to GPS coordinates (Amundsen; the display only occurs if the im-  age contains GPS coordinates) This chapter contains information on the following subjects: Home Page...
  • Page 32 The GPT standards (GUID partition table) method structured image sources ■ is continued from start to finish. are not supported by the device. Image with GPS coordinates (Amundsen) Settings The device enables the guidance to the GPScoordinate data stored in the im- ›...

  • Page 33: Telephone

     Read and observe on page 30 first. Telephone › Press the key  Introductory information Main Menu - Information and function keys » Fig. 18  Introduction Name of the telephone service provider (with active roaming, the symbol appears before the name ) This chapter contains information on the following subjects: Function keys of preferred contacts Telephone...

  • Page 34: Pair And Connect

    ■ User profile - User profile settings Message Meaning Manage favourites - Setting the function keys for your favourite contacts ■ Telephone not available. Mailbox number: Enter here - Enter the telephone number of the mailbox ® ■ A problem with the Bluetooth unit in Telephone is currently not available.
  • Page 35 Please refer to the compatibility of telephones as well as updates which are ® available for the Bluetooth device, and are available on the ŠKODA Internet Coupling - connected telephone pages. › http://infotainment.skoda-auto.com Press the key →  → Find telephone.  ® A search for available Bluetooth devices takes place.
  • Page 36 Select the Bluetooth device unit. Version 2 The device is displayed in the telephone to be connected to as SKODA BT ..› Enter the 4 - 16 digit PIN code into the telephone..is replaced with the last four symbols of the vehicle identification number ›...

  • Page 37: Telephone Functions

    Display list of blocked coupled devices Telephone functions › Press in the menu Telephone the function key  → Bluetooth → Paired de- vices .  Introduction ® In the list displayed the following symbol of the Bluetooth profile » Fig. 19 - ...

  • Page 38: List Of Telephone Contacts

    Start of the connection with the prefix (the symbol is displayed only with  active preset function in the settings) Opens the menu for editing the telephone number of the contact before  dialling Start the route guidance to the contact address (Amundsen)   Telephone...

  • Page 39: Manage Preferred Contacts

    Searching for a contact in the contact list The function keys » Fig. 22 allows an immediate selection of the preferred › Press the function key Find. contact telephone number. › Search for the contact. There are 10 pre-set keys in two memory groups. Import list Assign the preferred contact After the first connection of the main tel.

  • Page 40: Text Messages (Sms)

    › All - List of all calls Conference › Missed calls - list of missed calls › Dialled nos. - list of numbers dialled The conference is a shared call with between three and six participants. › Received calls - list of received calls Start a conference/invite additional participants ›...
  • Page 41 Main menu Fig. 24 Main menu text messages Fig. 26 Contact list / recipient list › Press in the main menu the Telephone function key  . Creating and sending the message › In the main menu of the text messages press the function key  »...

  • Page 42: Introductory Information

    Contact list / recipient list SmartLink After the list has been opened the following functions can be executed » Fig. 26 - . Introductory information Insert a contact in the recipient list   Introduction Contact search Enter the telephone number ...
  • Page 43 Main Menu - function Keys CAUTION List of connected devices  ŠKODA is not responsible for damage to the unit or to the vehicle by the use ■ Disconnection (appears with active connections) of faulty or incorrectly programmed applications in the connected device. ...

  • Page 44: Android Auto

    The change of the preferred connection type takes affect only after reconnect- Some applications require that the data connection in the connected device is ing the external device. turned on. ™ ® By establishing the Android Auto connection all existing Bluetooth connec- Disconnection ®...

  • Page 45: Apple Carplay

    Main menu - function keys and information Start the application › ™ Navigation applications In the main menu of the Android Auto connection select the desired appli-  cation in the field » Fig. Telephone applications  Overview regarding current applications, telephone calls, accepted text ...
  • Page 46 A list of devices, supported regions and applications that the Apple CarPlay Main menu - function keys and information connection supports, can be obtained from the Apple website. Push - Return to the main menu of the Apple CarPlay connection / Hold - ...

  • Page 47: Mirrorlink

    ™ ™ Return to the main menu of the MirrorLink connection from another device The list of available applications and devices, which support the MirrorLink function, can be seed in the ŠKODA Internet pages www.infotainment.skoda- menu › ™ auto.com. To return to the main menu of the MirrorLink connection (e.g.
  • Page 48 Masking the function keys  Operation Displays the function keys right / left / lower  Fig. 32 - Using the connected device, as well as the running application Example of a running application Depending on the type of the connected device, as well as the current running application, various function keys of the connected device can be displayed (at the most three at the same time).
  • Page 49 Message Meaning The app is unavailable while the vehicle is in motion. The application is only available when the vehicle is stationary. App während der Fahrt nicht verfügbar. The app is not certified or the certifi- cation restricts use while the vehicle is in motion. App is not compatible.

  • Page 50: Navigation (Amundsen) Navigation Description

    If the original SD card should be damaged or lost, a new original SD card can be Navigation (Amundsen) purchased from the ŠKODA Original Accessories. Navigation description With a Non-original SD Card, the navigation does not work. Finding out the version of the navigation data ...

  • Page 51: New Destination

    Enter POI displayed with a list of the places » Fig. 35. This map can also be shown by Enter destination on the map pressing the function key  .  Navigation (Amundsen)
  • Page 52 Move the destination onto the cross line position on the map. must be confirmed by pressing the function key Start in addition to confirming › Press the function key  → Start. in the following menu that appears. Navigation (Amundsen)

  • Page 53: My Destinations

    Favourites (max. 50 entries). The favourite position is displayed in the map  by the symbol  . Telephone contacts of the connected telephone containing an address. If  the address is in an unsupported format, then a menu for editing is dis- played.  Navigation (Amundsen)

  • Page 54: Poi

    This chapter deals with the selection options for a POI using the function key › Press in the Navigation menu the function key  → Manage memory → De- . lete user data → Home address. › Press the function key Delete and confirm the deletion. Navigation (Amundsen)
  • Page 55 Press in the Navigation menu the function key  → Other POIs. must be confirmed by pressing the function key Start in addition to confirming in the following menu that appears.  The following menu is displayed » Fig. Selection of the search area Selection of the search area Navigation (Amundsen)

  • Page 56: Import My Destinations

    52 → My Points of Interest (Per- Route guidance sonal POI). › Press in the Navigation menu the function key  → Destinations →  → › Select the desired category of own destinations.  . › Press the function key Start.  Navigation (Amundsen)

  • Page 57: Map

    Night-time map display On / off of the split screen display The following information and function keys can be displayed in the map. On / off of the selected POI categories display  Vehicle position Destination position Route Navigation (Amundsen)
  • Page 58 Map view in reduced scale  » Fig. 41 on page 54. Current elevation  Turn on / off the display traffic signs » page Manual change of scale Map scale can be change in the following ways.  Navigation (Amundsen)

  • Page 59: Route Guidance

    The navigation announcements provided may vary from the actual situa-  play - ) tions, e.g. due to out-of-date navigation data. Alignment to the destination position (in the destination position display -  ) Route alignment (in the route display - ) Navigation (Amundsen)

  • Page 60: Destination Management

    If no route selection is made within 30 s after the calculation of all routes, the By pressing the function key Edit the following menu is displayed for the desti- route guidance is automatically started according to the set route type nation processing. » page 62, Route options. Navigation (Amundsen)

  • Page 61: Most Common Routes

     shown » Fig. Street name and street number of the current vehicle position Up to the three next driving recommendations with street names and road numbers, with the distance and travel time to the recommended destina- tion Navigation (Amundsen)

  • Page 62: Tour

    This chapter contains information on the following subjects: Tour setting Edit tour Tour memory management If the time of arrival to the final destination or remaining travelling time greater than 24 hours,  is dis- played inside the symbol. Navigation (Amundsen)

  • Page 63: Traffic Reports

    Estimated arrival time at destination  Dynamic route Distance to destination  Enter / remove traffic conditions on your route manually Destination management › Press the function key for the desired destination, the following menu is dis- played. Navigation (Amundsen)
  • Page 64 › Route - Display the traffic reports on the route the route. Depending on the context, the symbol for the obstruction is displayed in one of the following ways.  Navigation (Amundsen)

  • Page 65: Settings

     Avoid tunnels - Switch on/off use of tunnels for the route calculation ■  › Set the length value of the traffic obstruction by touching the scale and us- ing the function keys /  or turning the knob  set. Navigation (Amundsen)
  • Page 66 No navigation sound during call - Enable / disable the playback of navigation ■ prompts during a telephone conversation Flagged destination - Delete the flagged destination ■ ■ Most frequent routes - Deletion of the most travelled routes Navigation (Amundsen)

  • Page 67: Vehicle Systems

    Vehicle systems Main menu CAR - vehicle setting Fig. 50 Function keys in the main menu  Introduction This chapter contains information on the following subjects: Main menu Convenience consumer Driving data DriveGreen Vehicle condition Function keys in the main menu »...

  • Page 68: Driving Data

    Driving data Vehicle condition Fig. 51 Fig. 52 Driving data Vehicle condition › › Press the key →  → Driving data. Press the key →  → Vehicle status.   In the screen, information regarding vehicle condition or function of the tyre Screen display »...

  • Page 69: Assistance Systems

    ■ Tyre Pressure Loss Indicator - Tyre pressure monitoring function ■ Blind Spot Monitor - Activation / deactivation of the assistant “Blind Spot SET  - Storing the tyre pressure values Monitor” ■ Winter tyres - Setting an alarm on reaching the speed limit for winter tyres Dynamic Road Sign Display - Settings for the Dynamic Road Sign Display ■...

  • Page 70: Light

    › Press the key →  → Background lighting.  Light Description of the function keys » Fig. 53 › Press the key →  → Light.  Selecting the illumination colour (or switching off the lighting) Light assistance - Setting of outdoor lighting ■...

  • Page 71: Seats

    ■ Automatic locking - Activate/deactivate automatic locking when starting Time, date and unit setting › “Easy Open” - Activation/deactivation of the contactless opening of the Press → Time and date. ■  boot lid Description of the time and date settings »...

  • Page 72: Adjustment Of The Heating And Cooling System

    Switching on / off and adjusting the fan speed, cooling system, air Adjustment of the heating and cooling system distribution and the air recirculation a)b)  Introduction Setting the rear temperature Colour representation of the air flow from the air vents at the front ...
  • Page 73 Note Auxiliary heating and ventilation In the selection of the day in the preset time, there is an option between ■ Sunday and Monday without the specified day. If this position is selected, the vehicle will be ready for use at the selected time, regardless of the current day. If a different time is set »...

  • Page 74: Index

    Index Blind spot monitoring Additional information Bluetooth Radio text and image presentation Settings Abort route guidance Settings Switch on/off Update Date Additional keyboard languages Visibility Daytime running light Address 48, 49 Bluetooth Player Daytime running light when raining Administering paired devices Bluetooth profile Delete destination Air conditioning...
  • Page 75 Device Menu Extra window Home Page Pictures Manoeuvre Android Auto SmartLink Pictures Sound Telephone Factory settings 16, 68 Device operation Images Favourite Device screen Display File formats device screen File formats Images keyboard Operation Prerequisites and restrictions Device screen Requirements and limitations Finish route guidance Areas safe removal of the data source...
  • Page 76 Language characters Operation Multi-media Orientation LEAVING HOME POI display Multimedia Light Representation Light assistance Road sign Multimedia database Light sensor - switch-on the lights Media Mute List Audio source My destinations 50, 53 connected SmartLink devices of available stations My Destinations Bluetooth Audio of telephone contacts My POI categories...
  • Page 77 Last destinations Opening Preferred contacts Main menu Operation Principles of device operation Manage memory Images Proactive occupant protection 49, 63 Media Map alignment MirrorLink Map Orientation Radio Radio Map scale Telephone Broadcasting sector Most common routes DAB settings My destinations 50, 53 FM - settings Navigation announcements...
  • Page 78 System information ŠKODA Surround Safe removal of the data source Telephone Satellite data telephone Time and date conditions for coupling Screen Units see device screen User profile Telephone Vehicle Bluetooth profile Screen display Virtual Subwoofer Breakdown service SD card Voice control Call list Seats Volume...
  • Page 79 Telephone Search Text messages 37, 38 vCard Vehicle - settings received Vehicle condition Time Vehicle identification number Vehicle systems Detail of the traffic report dynamic route Ventilation List of the traffic reports VIN number Requirements Voice control TMC (Traffic reports) commands Touch screen Function requirements...
  • Page 80 Index...
  • Page 81 Index...
  • Page 82 Index...
  • Page 83 Reprinting, duplicating, translating and any other use, either in whole or in Issued by: ŠKODA AUTO a.s. part, is not permitted without the written consent of ŠKODA AUTO a.s. © ŠKODA AUTO a.s. 2015 ŠKODA AUTO a.s. expressly reserves all rights relating to copyright laws. Subject to change.
  • Page 84 Amundsen and Bolero: Fabia, Rapid, Rapid Spaceback, Octavia, Superb anglicky 05.2015 S00.5614.37.20 3V0012720EB  3V0012720EB...
