Vehicle Belts - Safety 1st Alpha Elite 65 Manual

E-4 Install Rear-Facing with

Vehicle Belts

Do not use the LATCH system along with the
vehicle lap or lap/shoulder belt. Secure LATCH
belts when using the vehicle belts.
Check the vehicle belt before each use. Use only
if the belt is tightened properly and securely.
Attach the top anchorage hook (tether) to the
base when used rear-facing.
Failure to follow these warnings can result in
serious injury or death.
1.
2.
43
4358-6549 Elite 65 S1.indd 45-46 4358-6549 Elite 65 S1.indd 45-46
Secure LATCH Belts
You MUST fasten the LATCH
belt connectors to the side
of shell as shown when
using the vehicle seat belts.
Store Top Anchorage
Hook (Tether)
Attach the top anchorage
hook (tether) to the base as
shown. Tighten tether to
remove the slack.
NOTE: Review your vehicle's owner manual for vehicle belt
use.
3. Fully Recline and Place
Child Restraint in the
Back Seat Rear-Facing
For children between
5-22 lbs (2.3-10 kg),
the bottom level to ground
line MUST be level to the
ground.
For children 22-40 lbs
(10.1-18 kg) and can sit
up unassisted, rotate the
child restraint between the
2 level to ground lines. Start
by making the bottom level to
ground line level, then rotate
seat up. DO NOT rotate past
the top most upright level to
ground line.
Adjust child restraint if
needed.
You may need to place a
large rolled towel(s) or foam
pool noodle(s) (A) under the
A
front of the child restraint
to help achieve the correct
recline. Check often to be
sure padding is still in place
and the vehicle belt is tight.
44
continued on next page.
