- Page 1 OWNER’S MANUAL Welcome to the future of hot water. VOLT SS/X6/OP RAPID SS/X4/OP DYNAMIC SS/X8/OP...
- Page 2 However, in order to perform optimally it is important to ensure that your Hydrotherm is installed and operated inline with the instruction found in this manual. Once operational there is little you need to do, except enjoy plenty...
-
Page 3: Table Of Contents
CONTENTS Symbols used in these instructions 1.0 PARTS & CONSTRUCTION SCHEMATIC....Observe the following safety instructions: 1.1 Heat Pump Schematic 1.2 Heat Pump Tank Schematic Please Note: Warning about possible dangers. 2.0 INSTALLATION INSTRUCTIONS..........2.1 Delivery Note: 2.2 Location Important information and tips. 2.3 Airflow 2.4 Noise Note: Carefully read these... -
Page 4: Parts & Construction Schematic
1.0 PARTS & CONSTRUCTION SCHEMATIC SCHEMATIC VOLT-SS/X6/OP Top cover Si d e cover Front cover Back cover Screen panel Electric board Compressor Evaporator Condensate drain Host chassis Faceplate Hot water outlet Safety valve outlet Tank cover Hand grip Insulation layer Condenser coil Cold Water Inlet Supporting frame... - Page 5 SCHEMATIC DYNAMIC-SS/X8/OP AND RAPID-SS/X4/OP Cover lid Top cover Control panel Electrical inlet Aluminum channel Foam dampener Fan housing Compressor Evaporator Condensate collector Condensate outlet Faceplate Hot water outlet Safety valve outlet Tank cover Hand grip Insulation layer Condenser coil Cold water Inlet Supporting frame...
-
Page 6: Installation Instructions
2.0 INSTALLATION INSTRUCTIONS All Hydrotherm heat pumps are designed for installation by a licensed plumber in accordance with standards set out in AS/NZS 3500.2 “National Plumbing and Drainage Code Hot Water Supply Systems - Acceptable Solutions” DELIVERY • The Hyrdrotherm heat pump must be stored and transported in a near vertical position at all times with a tilt ratio of no more than 30°. -
Page 7: Airflow
• Always maintain optimum perimeter from all structures. NOISE Noise levels • The Hydrotherm range has been designed with the lowest possible running noise level (>49db) to 49bB ensure optimum comfort and minimum impact on living areas. • Select a location that is removed from bedrooms if possible as it is likely the unit will function for a period of time during the night. -
Page 8: Plumbing Schematics
3.0 PLUMBING SCHEMATICS The following instructions and schematics have taken into account standards AS4324, AS4020, AS1056.1, AS/NZS2712, AS/NZ3350.240/30/30.2, AS3498 and represents an optimum installation procedure for this unit however to ensure minimum requirements are met all local regulations should be adhered too. 3.1 VOLT CONNECTION DIMENSIONS AND COMPONENTS Cold water supply outlet... - Page 9 3.2 DYNAMIC AND RAPID CONNECTION DIMENSIONS AND COMPONENTS Cold water supply outlet (3/4” female thread) Hot water outlet (3/4’’ female thread) Condensate drain (3/4” female thread) P&T relief valve (3/4’’ female thread 700Kpa) Electrical cable Tempering valve (High performance) Expansion control valve (If required by council 600Kpa) Pressure reduction valve (500Kpa)
-
Page 10: Plumbing Installation
4.0 PLUMBING INSTALLATION PLUMBING CONNECTIONS 1. Cold Water Supply Outlet • The cold water supply connection is a 3/4” female thread. • The cold water supply should be connected to RP 3/4” socket. • The cold water supply outlet can also act as a drainage point for emptying the system. 2. - Page 11 • The non-return valve can be combined with a PRV valve to form a duo valve as shown in the above schematic. Filling The System • Once the Hydrotherm has been connected to the properties plumbing as per instructions the tank can be filled and pressurised.
-
Page 12: Electrical Connections
5.0 ELECTRICAL CONNECTION Only qualified electricians must carry out the installations of the Hydrotherm heat pump to main power accordance with the following instructions. ELECTRICAL SCHEMATIC C1/2 C1/2 C3/4 N02 No3 No4 C3/4 Tx/Rx GND B4 Key/spv C1/2 C1/2 C3/4... -
Page 13: Pre-Connection & Regulations
• Before any work can commence ensure that the heater is isolated from the power supply at the control panel. • The Hydrotherm heat pump is designed for permanent fixed wiring to a - CONTINUOUS TARIFF, single phase 240 volt AC supply - Tariff 33 (QLD only) single phase 240 volt AC supply. -
Page 14: Commissioning The System
6.0 COMMISSIONING SYSTEM PRE-START PROCEDURES AND CHECKS • Once both the electrical and plumbing connections have been completed by qualified trades person, the system is now ready for operation. • Before turning the system on it is essential that you ensure the Heat Pump storage tank is full and the device thoroughly flushed. - Page 15 CHECKBOX Make sure the unit is level. Ensure the condensate and PTR lines are separate to the drain. Ensure the condensate and PTR lines running down to allow the water to run off. Ensure the unit is connected to Tariff 1 1 or 33 in QLD. Ensure there is 600mm above the Dynamic to allow the lid to be removed for maintenance.
-
Page 16: Operation Panel Instructions
CONTROL / DISPLAY INTERFACE Located on the front of the Hydrotherm is the unit interface. It houses all controls and displays necessary to operate your new Hydrotherm Hot Water System. The legend below indicates all components referred to in this manual. -
Page 17: Display Panel
All functions and settings of the Hydrotherm are displayed on the DISPLAY PANEL. When a function is active, it is lit up in either blue or red. Below, you can find the description of each function of the Hydrotherm and its location on the panel. -
Page 18: Setting The Clock
SETTING THE CLOCK The correct time is necessary for the unit to operate in ‘ECON MODE’. It is displayed in 24 hour format. TO SET THE CLOCK: 1. Press ‘CLOCK’. The hour digits will flash indicating they can be changed. CLOCK 2. - Page 19 When considering the tariffs, the shoulder tariff ensures you will receive 18 hrs of electricity minimum a day. However, it can be during peak periods such as 7 - 9 am and 4 - 8 pm that the electricity is cut off. Therefore if your usage peaks during this period and you set a timer preventing the unit from switching on during the evening there is potential that the unit will run out of hot water the following morning following another peak.
- Page 20 3. The second clock represents the time you want the unit to shut off. To adjust the hours, use the ‘ARROW’ buttons. Select ‘TIMER’ to switch from hours to minutes and use the ‘ARROW’ buttons again to adjust. Once you have input your desired ‘OFF’...
-
Page 21: F1 1 Maximum Temperature Setting
F1 1 MAXIMUM TEMPERATURE SETTING F1 1 is used to set the tank’s maximum temperature. It MUST be set at 60°C to ensure legionella control is met. TO SET F1 1: 1. Hold down ‘MODE’ until the word ‘PASS’ appears on the display. -
Page 22: F12 Temperature To Activate The Heat Pump
5. To exit settings press ‘UP ARROW’ until ‘END’ appears on the screen, then press ‘TIMER’. The clock will reappear on the screen. TIMER TEMPERATURE TO ACTIVATE THE HEAT PUMP The F12 setting allows you to set a value to which the water temperature can drop before the heat pump will automatically start heating. -
Page 23: Other Settings
OTHER SETTINGS (extra large hot water demand) F19 - If there is an extra-large demand, Hydrotherm can heat water to 65°C. This means less hot water has to be taken for each shower and the tank will deliver between 20 - 40 litres of extra hot water. -
Page 24: Error Handling
8.0 ERROR HANDLING ERROR CODE ERROR STATUS REASONS ERROR HANDLING Thermal sensor alarm Water temperature 1. Check the water temp. sensor sensor open circuit or connection. short circuit. 2. Change the water temp. Sensor. Condenser coil sensor Condenser coil temp. 1. -
Page 25: Trouble Shooting
9.0 TROUBLE SHOOTING Pressure & Temperature Relief Valve System Maintenance It is not unusual for the PTR to allow a small quantity of The heat pump water heater is designed to eliminate water to escape during the heating cycle. The amount system maintenance other than that detailed in this of discharge will depend on the hot water usage. -
Page 26: Service Representative Maintenance
10. SERVICE REPRESENTATIVE MAINTENANCE Cleaning the evaporator • To ensure the optimum efficiency the system evaporator should be cleaned regularly. • Clean evaporator using water and a soft brush only. Draining the System • Close the shutoff valve in the cold water supply •... - Page 27 1 1. WARRANTY - AUSTRALIA ONLY Aquatech Solar Technologies Australia warrants all models under the Hydrotherm branding as per the following terms and conditions. The obligation of Aquatech or its service agents under this warranty is limited to Aquatech either repairing or replacing any defects/parts at its discretion within the specified warranty period as stated.
- Page 28 WARRANTY - AUSTRALIA & NEW ZEALAND TERMS OF MANUFACTURER’S WARRANTY Each unit is supplied with a PTR Valve, all other valves (see 4.0 plumber schematics) have to be supplied by the installer in accordance with State and local regulations, failing to use new valves when installing any Aquatech system will cancel all warranties.
- Page 29 NOTES...
- Page 30 info@hydrothermhotwatersystems.com.au www.hydrothermhotwatersystems.com.au TOLL-FREE 1300 769 904...
