Summary of Contents for Caple BXI910
-
Page 2: Table Of Contents
Contents Introduction Safety precaution Installation Installing the charcoal filter Control panel operation Care and maintenance Troubleshooting Guarantee Environmental protection... -
Page 3: Introduction
To ensure that you get the best results from your new extractor, we strongly suggest that you read this instruction manual thoroughly before use..If treated with care, your Caple extractor should give you years of trouble-free use. - Page 4 A damage supply cord must be replaced by qualified service personnel only. Please contact the Caple service department. If the room where the hood is to be used contains a fuel burning appliance such as a central heating boiler then its flue must be of the sealed or balanced flue type.
-
Page 5: Installation
Installation Prepare for the installation: C. If you have an outlet to the outside, your cooker hood can be connected as per the below picture by means of an extraction duct with an interior diameter of 150mm) B. Before installation, turn the unit off and unplug it from the outlet. C The cooker hood should be placed at a minimum distance of 65-76cm above the hob. - Page 6 Installation – ducted Attent Attention! Obs Attent Attent ion! Obs ion! Observe the warning ion! Obs erve the warning erve the warning concerning the operation of the appliance erve the warning concerning the operation of the appliance concerning the operation of the appliance concerning the operation of the appliance when air is discharged from the room.
- Page 7 4) If your cooker hood is going to be used in extraction mode, then you should connect the ducting hose to the ceiling adaptor at this point. Fix the upper chimney section to the hanging plate, using the 4 x self tapping screws.
- Page 8 6) Lift the main body of the cooker hood onto the angle bars and then fix it into position using the 16 x M5 screws. IMPORTANT: This stage of the installation process MUST be completed by two people. IMPORTANT: The 16 x M5 screws MUST be securely tightened. 7) If you are using the hood in extraction mode, you should fix the ducting hose to the ceiling.
- Page 9 Use a stainless steel cleaner and polish on the stainless steel sections of the appliance. If you are using the appliance in recirculation mode, then you should now fit the charcoal filter. See the “fitting the charcoal filter" section on page 9. Fix the one-way-valve to the air outlet of the cooker hood.
-
Page 10: Installing The Charcoal Filter
Installation – recirculation mode If you do not have an outlet to the outside, the exhaust pipe is not required (as shown in the section “Installation - ducted”). Fitting the charcoal filter Activated charcoal filter can be used to trap odours. In order to install the activated charcoal filter, the grease filter should be detached first. -
Page 11: Control Panel Operation
Control panel operation Low Speed button Low Speed button Low Speed button Low Speed button Is suitable for simmering and cooking which does not produce much odour. Medium Speed button Medium Speed button Medium Speed button Medium Speed button Airflow speed is ideal for extracting with standard cooking. High Speed button High Speed button High Speed button... -
Page 12: Care And Maintenance
Care and maintenance IMPORTANT: Before cleaning or maintenance please switch off the electricity supply and remove the plug from the wall. Regular Regular c c c c leaning leaning Regular Regular leaning leaning Use a soft cloth moistened with lukewarm mildly soapy water or household cleaning detergent. -
Page 13: Troubleshooting
‘Care and maintenance’ section. The filter requires cleaning performance is Replace the charcoal filter (if in not good recirculation mode) If the above table has not solved the problem please contact Caple Service by phone on 0844 800 3830 or by email service@caple.co.uk... -
Page 14: Guarantee
Guarantee Caple undertake that if within twelve months of the date of the purchase this appliance or any part thereof that is proved to be defective by reason only of faulty workmanship or materials, we will at our option repair or replace the same free of... -
Page 15: Environmental Protection
CE Declarations of Conformity This appliance has been manufactured to the strictest standards and complies with all applicable legislation, Low Voltage Directive (LVD) and Electromagnetic Compatibility Directive (EMC). Caple Fourth Way Avonmouth BS11 8DW www.caple.co.uk...
