- Page 1 B u i l t - U n d e r H o o d I n s t r u c t i o n M a n u a l BU5 21 Contact Caple on 0117 938 7420 for spare parts or www.caple.co.uk...
- Page 2 C O N T E N T S Warnings Environmental Protection Uses Installation Control Panel Timing Cleaning and Maintenance Caple Contact Details Instruction manual BU521 Please keep this instruction manual for future reference...
- Page 3 0.04 mbar, in order to avoid the suck of exhausts deriving from the heat source. Therefore the room should be provided with air-intakes to allow a constant flow of fresh air. Instruction manual BU521 Please keep this instruction manual for future reference...
- Page 4 - This appliance complies with all relevant local and national safety requirements. Inappropriate use can, however, lead to personal injury and damage to property. Instruction manual BU521 Please keep this instruction manual for future reference...
- Page 5 These are a fire hazard and do not guarantee the required safety of the appliance. - The cooker hood can get very hot during cooking due to heat rising from the hob. Instruction manual BU521 Please keep this instruction manual for future reference...
- Page 6 › Staff kitchen areas in shops, offices and other working environments. › Farm Houses. › By clients in hotels, motels and other residential type environments. › Bed and breakfast type environments. Instruction manual BU521 Please keep this instruction manual for future reference...
- Page 7 Registration can also be completed online by visiting www.caple.co.uk. Ensure you keep your warranty card safe, you may need to show it to Caple Service together with proof of purchase. If you fail to show your warranty card you will incur all repair charges.
- Page 8 This appliance conforms to all current and applicable energy regulations. To view the Technical Fiche that supports the energy labelling data, please visit the product page on our website www.caple.co.uk. Instruction manual BU521 Please keep this instruction manual for future reference...
- Page 9 › In ducted mode (Fig.2), fumes are directly conveyed outside, through an evacuation duct connected from the extractor to the outside. Both charcoal filter and air deflector are not necessary in this case. Fig.1. Fig.2. FIG.3 Instruction manual BU521 Please keep this instruction manual for future reference...
- Page 10 (Fig.3). FIG.3 FIG.6 FIG.6 NOTE: BU521 only requires 1 grease filter N OT E : BU521 only requires 1 grease filter 10 Instruction manual BU521...
- Page 11 Before connecting the flexible exhausting pipe to the motor, make sure the stop valve, which is on the air outlet of the motor, can open and close freely. FIG.6 Instruction manual BU521 Please keep this instruction manual for future reference D U C T E D V E R S I O N...
- Page 12 › Connect the flange with appropriate ducting to convey the air to the top of the cabinet. › Connect the appliance to the electrical mains through the supply cord. 12 Instruction manual BU521 Please keep this instruction manual for future reference...
- Page 13 C: Motor switch - speed 2 C. Motor switch - speed 2 D: Motor switch - speed 3 D. Motor switch - speed 3 E: Warning light E. Warning light Instruction manual BU521 Please keep this instruction manual for future reference...
- Page 14 › If the appliance is working at 3rd speed, it is automatically switched to 2nd speed, after 7 minutes operation. Operation speeds can also be changed during operation. The energy consumption of the appliance in standby mode is lower than 0.5W. 14 Instruction manual BU521 Please keep this instruction manual for future reference...
- Page 15 Reinsert the charcoal filter by performing the opposite operation. › The active charcoal filter will need replacing depending on the use, but at least every six months. To purchase a replacement charcoal filter please visit www.caple.co.uk. Instruction manual BU521 Please keep this instruction manual for future reference...
- Page 16 (inside the appliance) with the necessary force to unhook the appliance from the cabinet. FIG.6 FIG.7 FIG.7 FIG.3 NOTE: BU521 only requires 1 charcoal filter NOTE: BU521 only requires 1 grease filter N OT E : BU521 only requires 1 grease filter FIG.8 FIG.8...
- Page 17 Instruction manual BU521 Please keep this instruction manual for future reference...
- Page 18 N OT E S : 18 Instruction manual BU521 Please keep this instruction manual for future reference...
- Page 19 N OT E S : Instruction manual BU521 Please keep this instruction manual for future reference...
- Page 20 Caple Service Fourth Way Avonmouth T: 0117 938 1900 Bristol E: service@caple.co.uk BS11 8DW www.caple.co.uk...
